GENERAL BEST PRACTICES FOR ASSEMBLY: Determine you have adequate space for assembly. Assembly by two adults is recommended. Assemble on soft surfaces to prevent damage to product finish. Keep children away during assembly. This item contains small parts which can be swallowed by children. -
Page 3: Parts List
PARTS LIST Top Panel Center Crossbar Top Left side Panel Bottom Right Middle Panel Top Left Middle Panel Bottom Right Side Panel Top Crossbar Door Top Right Middle Panel Side Back Panel Top Right side Panel Adjustable Shelves Center Back Panel Bottom Crossbar Center Middle Panel Bottom Panel... -
Page 4: Hardware List
HARDWARE LIST Bolt Ø1/4"*32mmL Spring Washer Ø1/4" Flat Washer Ø1/4" Allen Key 4mmL Wood Dowel Ø8*30mmL Plastic Block Screw Ø7*19mmL Screw Ø7*15mmL Hinge Flat Head Screw Ø7*16mmL Handle Bolt Ø5-32"*25mmL Door Handle Knob Bolt Ø5/32"*35mmL Knob Shelf Pin Anti-Tipping Strip 25*230mmL Wall Anchor Ø8.5*30mmL Screw Ø8*28mmL Door Stopper... - Page 5 STEP 1 Hardware needed With assistance, place the Bottom Panel (S) upside down on a smooth surface. Attach the Bottom Crossbar (R) to Bottom Panel (S) with Flat Washer (3), Spring Washer (2) and Bolts (1) using Allen Key (4). Fully tighten all bolts. Return Bottom Panel (S) to upright position.
- Page 6 STEP 2 Hardware needed Insert Wood Dowel (5) into Bottom Panel (S). Align the holes in Bottom Right Side Panel (N) and slide to place. Make sure all the latches are in open position so the pins are aligned with their corresponding holes before inserting them.
- Page 7 STEP 3 Hardware needed Insert Wood Dowel (5) into holes of Bottom Middle Panels as shown. Align the holes in Center Crossbar (L) with the inserted dowels and lower into place. Insert one Side Back Panel (P) down along the groove of Bottom Left Side Panel (I) and Bottom Left Middle Panel (J).
- Page 8 STEP 4 Hardware needed Place the Door Stop (19) on the bottom of Center Middle Panel (H) as shown. Secure with Screw (20) using Phillips Screwdriver. Fully tighten screws. Repeat steps for the remaining Door Stopper (19). Return panel upright position with assistance. Insert Wood Dowel (5) into hole of Bottom Right Side Panel (N), Bottom Right Middle Panel (M), Bottom Left Middle panel (J) and Bottom Left Side Panel (I).
- Page 9 STEP 5 Hardware needed Insert Wood Dowel (5) into hole of Top Cross Bar (D). Align the hole of Top Left Middle panel (C) and Top Right Middle Panel (E) with the inserted dowels and slide into place as shown. Insert Wood Dowel (5) into hole of Center Middle Panel (H), align the holes in the Top Left Side Panel (B), Top Right Side Panel (F) and the assembled parts with the inserted dowles as shown and slide into place.
- Page 10 STEP 6 Hardware needed Insert Center Back Panel (G) down along the groove of Top Left Side Panel (B), Top Left Middle Panel (C), Top Right Middle Panel (E) and Top Right Side Panel (F). Insert Wood Dowel (5) into holes of Top Left Side Panel (B), Top Left Middle Panel (C), Top Right Middle Panel (E) and Top Right Side Panel (F).
- Page 11 STEP 7 Hardware needed Attach Hinge (9) to Door (O) with Flat Head Screw (10) using Phillips Screwsdriver. Fully tighten screws. With assistance, center the Door (O) along the edge of Bottom Right Side Panel (N). Attach Hinge (9) to Bottom Right Side Panel (N) with Screw (10).
- Page 12 STEP 8 Insert Shelf Pin (15) in to the pre-drilled holes as shown in diagram. Place Adjustable Shelf (Q) onto the shelf pins. You can adjust the position of shelf as needed. Page 11 of 16...
- Page 13 STEP 9 Hardware needed Attach Knob (14) to Right Drawer (U) with Knob Bolt (13) using Phillips Screwdriver. Fully tighten bolts. Repeat the process to attach Knob (14) to Left Drawer (T). Attention: before assembly, please make sure to adjust the metal piece/ball bearing to the front of the drawer glide for both left and right side slider.
- Page 14 STEP 10 Hardware needed Place the Plastic Block (6) into the corner of Side back panel as shown, insert Screw (7) into the pre-drilled holes and secure with Phillips Screwdriver. Fully tighten screws. Repeat the step for the remaining Plastic Block (6). Insure all Plastic Blocks are used to secure both side back panels in place.
- Page 15 STEP 11 Hardware needed Attach the Anti-tipping strips (16) to the back top of the mantel with Screw (18) and Flat Washer (3). With assistance, place the Mantel in the desired location and mark the wall just below the spot where the Aniti-tipping Strips are attached to the mantel.
- Page 16 WARNING The maximum diagonal Plasma/LCD television screen size is 65inch (165.10cm). For use with televisions weighing 135 lbs. (61.23 kg) or less. Using larger or heavier televisions may cause instability or tip-over which lead to serious injury or even death. WARNING - Death or serious injury may occur when children climb on audio and/or video equipment furniture.
- Page 17 ASSEMBLY IS COMPLETED PRINTED IN VIETNAM Page 16 of 16...
