• Use only replacement parts or accessories recommended for this tool that are distributed by Sears or a Craftsman outlet. Use of any replacement parts or accessories purchased elsewhere may be hazardous, and will also void your warranty.
If this Craftsman® product fails due to a defect in material or workmanship within two years from the date of purchase, return it to any Sears store, Parts and Repair Service Center, or other Craftsman® outlet in the United States for free repair (or replacement if repair proves impossible).
KNOW YOUR TRIMMER Spark Plug Muffler Shaft Grip On/Off Stop Control Starter D-Handle Rope Grip Craftsman® Throttle Convertible™ Control Coupler Shaft Housing Line Cutting Blade Trimmer Attachment Attachment Shield HassleFree™ Oil Fill Plug ADJUSTING THE D-HANDLE 1. Loosen the screws on the D-handle (Fig. 1).
WARNING : OVERFILLING OIL CRANKCASE MAY CAUSE SERIOUS PERSONAL INJURY. Check and maintain the proper oil level in the crank case; it is important and cannot be overemphasized. Check the oil before each use and change it as needed. See Changing the Oil.
WARNING : Operate this unit only in a well- ventilated outdoor area. Carbon monoxide exhaust fumes can be lethal in a confined area. WARNING : Avoid accidental starting. Make sure you are in the starting position when pulling the starter rope (Fig.
• Cutting from right to left improves the unit's cutting efficiency. Clippings are thrown away from the operator. • Slowly move the trimmer into and out of the cutting area at the desired height. Move either in a forward-backward or side-to-side motion.
This may lead to serious personal injury or damage to the unit. Always use Craftsman® Hassle-Free™ XTRA QUIET Spiral Line. Choose the line size best suited for the job at hand. Red colored line is designed for cutting grass and small weeds. Black colored line is designed for cutting larger weeds and light brush.
Page 10
CHECKING THE OIL LEVEL The importance of checking and maintaining the proper oil level in the crankcase cannot be overemphasized. Check oil before each use: 1. Stop the engine and allow oil to drain into the crankcase. 2. Place the engine on an elevated, level surface with the cutting head shield hanging off the surface to get a proper oil level reading (Fig.
Page 11
AIR FILTER MAINTENANCE WARNING: To avoid serious personal injury, always turn the unit off and allow it to cool before you clean or service it. Cleaning the Air Filter Clean and re-oil the air filter every 10 hours of operation. It is an important item to maintain.
ROCKER ARM CLEARANCE This requires disassembly of the engine. If you feel unsure or unqualified to perform this, take the unit to a Sears or other qualified service dealer NOTE: Inspect the valve to rocker arm clearance with a feeler gauge after the first 10 hours of operation and every 25 hours of operation.
Page 13
• Drain the gas tank before transporting. • Tighten gas cap before transporting. WARNING: To avoid serious personal injury, always turn your unit off and allow it to cool before you clean or service it. cylinder before attempting to start the trimmer after storage.
Page 14
ENGINE WILL NOT START C A U S E Empty fuel tank Primer bulb wasn't pressed enough Old fuel Fouled spark plug Plugged spark arrestor ENGINE WILL NOT IDLE C A U S E Air filter is plugged Old fuel Improper idle speed ENGINE WILL NOT ACCELERATE C A U S E...
Page 15
Fuel Tank Capacity ... 14 oz (414 ml) DRIVE SHAFT AND CUTTING ATTACHMENT* Drive Shaft Housing ... Steel Tube (Craftsman® Convertible™) Throttle Control... Finger-Tip Trigger Approximate Unit Weight (No fuel, with Hassle Free lll™, shield & D-handle)... 11.5-13.0 lbs (5.2-5.9 kg) Cutting Mechanism ...
• In order to file a claim, go to your nearest Authorized Sears Service Center. Warranty services or repairs will be provided at all Authorized Sears Service Centers. • Any manufacturer approved replacement part may be used in the performance of any warranty maintenance or repair of emission related parts and will be provided without charge to the owner.
Page 18
INDICE DE CONTENIDOS Normas para una operación segura ....E2 Garantía ......... .E4 Conozca su unidad .
Page 19
• Utilice solamente piezas o accesorios de reemplazo recomendados para esta herramienta que sean distribuidos por Sears o por un establecimiento comercial de Craftsman. El uso de cualquier pieza de reemplazo o accesorio adquirido en cualquier otro lugar puede resultar peligroso, y también anulará su garantía.
Page 20
Si este producto de Craftsman® falla debido a un defecto en el material o en la mano de obra dentro de un período de tres años a partir de la fecha de compra, devuélvalo a cualquier tienda o Centro de Servicio de Piezas y Reparaciones Sears u otro establecimiento de Craftsman®...
Page 21
CONOZCA SU UNIDAD Bujía de encendido Silenciador Traba del regulador Control de encendido y apagado Manija en D Gatillo del Craftsman® regulador Convertible™ acoplador Bastidor del eje Cuchilla de corte de línea Accesorio de corte Protección accesoria HassleFree™ Tapón del aceite AJUSTE DE LA MANIJA EN D 1.
Page 22
ADVERTENCIA : EL LLENAR DEMA- SIADO EL CÁRTER PUEDE CAUSAR LESIONES PERSONALES GRAVES No podemos exagerar la importancia del control y mantenimiento del nivel correcto de aceite en el cigüeñal. Verifique el aceite antes de cada uso y cámbielo cuando sea necesario según se indica en la sección de Cambio del aceite.
Page 23
ADVERTENCIA : Use esta unidad sólo en un área exterior bien ventilada. Los gases de escape de monóxido de carbono pueden ser letales en un área cerrada. ADVERTENCIA : Evite los arranques accidentales. Colóquese en posición de inicio cuando tire de la cuerda de arranque (Fig.
Page 24
Gire toda la unidad a modo de que el accesorio de corte se ubique a un ángulo de 30° con el suelo (Fig 11). USO DE LA FUNCIÓN CRAFTSMAN® CONVERTIBLE™ ADVERTENCIA: Antes de comenzar a usar este accesorio, lea y comprenda el manual que viene con el accesorio.
Page 25
Use siempre la Línea Espiral Hassle-Free™ XTRA QUIET de Craftsman®. Seleccione el tamaño de la línea que mejor se adapte al trabajo que se propone realizar. La línea de color rojo está...
Page 26
INSTRUCCIONES DE MANTENIMIENTO Y REPARACIÓN INSPECCION DEL NIVEL DE ACEITE No podemos exagerar la importancia de verificar y mantener el nivel correcto de aceite en el cárter del cigüeñal. Inspeccione el nivel de aceite antes de cada uso: 1. Apague el motor y permita que el aceite drene dentro del cárter del cigüeñal.
Page 27
INSTRUCCIONES DE MANTENIMIENTO Y REPARACIÓN MANTENIMIENTO DEL FILTRO DE AIRE ADVERTENCIA : Para evitar graves lesiones personales, apague siempre su recortador y espere que se enfríe antes de limpiarlo o realizar todo tipo de mantenimiento. Limpieza del filtro de aire Limpie y vuelva a aceitar el filtro de aire cada 10 horas de operación.
Page 28
INSTRUCCIONES DE MANTENIMIENTO Y REPARACIÓN HUELGO DEL BRAZO OSCILANTE Esto requiere el desarmado del motor. Si usted siente que no está seguro o que no está calificado como para realizar esto, lleve la unidad a un centro de servicio autorizado. NOTA: Inspeccione el huelgo de la válvula del brazo oscilante con una galga después de las primeras 10 horas de operación y luego cada 25 horas de operación en lo sucesivo.
Page 29
INSTRUCCIONES DE MANTENIMIENTO Y REPARACIÓN 5. Instale una bujía de encendido con la separación correcta en la cabeza del cilindro. Ajuste girando la llave de casquillo 16 mm (5/8 de pulgada) en sentido horario hasta que esté ajustada sin huelgo. Si usa una llave de torsión, ajuste a: 110-120 pulg.•libras (12.3-13.5 N•m) No ajuste demasiado.
Page 30
EL MOTOR NO ARRANCA C A U S A El tanque de combustible está vacío La bombilla de cebado no fue oprimida lo suficiente El combustible es viejo La bujía de encendido está arruinada Parachispas obstruido EL MOTOR NO FUNCIONA EN MINIMA C A U S A El filtro de aire está...
Page 31
Capacidad del tanque de combustible ... 414 ml (14 onzas) EJE IMPULSOR Y ACCESORIO DE CORTE* Bastidor del eje impulsor ... Tube en acier (Craftsman® Convertible™) Control del regulador ... Gatillo para el dedo Peso de la unidad (sin combustible, con Hassle Free lll™, el protector y el accesorio de corte) ...5,2 - 5,9 kg (11,5 -13 libras) Mecanismo de corte ...
Page 32
• Para presentar una reclamación, vaya a su Centro de Servicio Sears Autorizado más cercano. Los servicios o reparación por motivo de garantía se realizarán en todos los Centros de Servicio Sears Autorizados. • Cualquier pieza de reemplazo aprobada por el fabricante se puede usar al realizar cualquier mantenimiento o reparación de piezas bajo garantía relacionadas con emisiones y se proporcionarán sin cargo alguno para el propietario.
Page 33
PARTS LIST REPLACEMENT PARTS - MODEL 316.791940 4-CYCLE GAS TRIMMER...
Page 35
791-153597 Lower Clamp Assembly (includes 22) 791-145569 Anti-Rotation Screw 753-05050 Bushing Housing Assembly 753-05034 Adapter 753-05035 Cutting Head Assembly 753-05036 Glide Plate 753-05038 Tube of Precut Line Items Not Shown PARTS LIST REPLACEMENT PARTS - MODEL 316.791940 4-CYCLE GAS TRIMMER...
