Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
1-800-986-3460
Scan for text based
customer support
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
MAKENNA 52-INCH CEILING FAN
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
HOMEDEPOT.COM/HOMEDECORATORS
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
improvement needs. Thank you for choosing Home Decorators Collection!
THANK YOU
Item #xxxx xxx xxx
UL Model #52-MAKDN
Scan for online product
warranty information
Model #51235
Advertisement
Related Manuals for Home Decorators Collection MAKENNA
Summary of Contents for Home Decorators Collection MAKENNA
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................13 Warranty ................3 Care and Cleaning ............. 14 Pre-Installation ..............3 Troubleshooting ..............14 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as flanges) during assembly or after installation. -
Page 3: Warranty
Warranty The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The supplier also warrants that all other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Blade attachment screws Plastic wire connecting nut Blade arm screws Decorative frame screws Frame brace screws Hanger pin Locking pin Pull chain extension...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blade arm (inside canopy) Blade Ball/downrod assembly Blade arm bracket Canopy with canopy ring attached Decorative frame piece Decorative motor collar cover Switch cup Fan-motor assembly Switch cup cover IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock or proper blade clearance when installing on a steep, sloped personal injury, mount to outlet box marked “Acceptable ceiling. The maximum angle allowable is 20° away from for fan support of 35 lbs (15.9 kg) or less”, and use horizontal. -
Page 7: Assembly
Assembly - Standard Ceiling Mount Preparing for mounting □ Remove the magnetic canopy bottom cover (II) from the canopy (C) by pulling it off. □ Loosen the two canopy screws (SS) located in the bottom of the mounting bracket (A). □... - Page 8 Assembly - Standard Ceiling Mount (continued) Assembling the fan CAUTION: To ensure wobble-free operation and to avoid damage to the fan, the downrod (B) and the setscrew (JJ) must be completely tightened. WARNING: Failure to properly install the locking pin (GG) could result in the fan becoming loose and possibly falling.
- Page 9 Assembly - Hanging the Fan (continued) Hanging the fan Note: If the fan is too heavy to lift on a ladder, seek the assistance of a second person to hang the fan. □ Carefully lift the fan-motor assembly (E) up to the slide-on mounting bracket (A).
- Page 10 Assembly - Hanging the Fan (continued) Wrapping the extra wire NOTE: Follow this step ONLY if you did not cut the extra length from the wires coming from the ceiling fan. □ Gently wrap the excess wire around the mounting bracket (A). □...
- Page 11 Assembly - Attaching the Fan Blades Attaching the blades to the blade brackets □ Attach a blade (G) to the blade arm (F) by aligning the holes on the blade arm bracket (H) with the holes on blades (G) and blade arms (F), inserting the screws (AA) into the holes in the blade arm (F) and through the blade (G), blade arm (F) and blade arm bracket (H).
- Page 12 Assembly - Attaching the Switch Cup Attaching the switch cup □ Remove one screw (TT) from the support plate, and loosen, but do not remove, the other two screws. □ Push the switch cup (J) up to the support plate so that the two loosened screw heads fit into the keyhole slots.
-
Page 13: Operation
Operation Warm weather Operating you fan Turn on the power and check the operation of the fan. The fan pull chain controls the fan speed as follows: 1 pull - High 2 pulls - Medium 3 pulls - Low 4 pulls - off The appropriate speed settings for warm or cool weather depends on factors such as the room size, ceiling height, and number of fans. -
Page 14: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 15 Questions, problems, missing parts? Before returning to the store, call Home Depot Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
