Shark StainStriker PX200 Series - Floor Cleaner Manual

PARTS

PARTS * Tools sold with the Pet model PX200UKT (or sold separately)

CarpetXpert Tank
Dirty Water Tank
StainStriker Tank
Crevice Tool
Tough Stain Tool
Hose Cleaning Tool
2x Reversible Bristles
177ml Deep Clean Pro Formula

355ml OXY Multiplier Formula
Spray Trigger
Power Button
Detach Button
Wide Tough Stain Tool*
Pet Stain Trapping Tool*

NOTE: Not all accessories come with all units. Tools may vary by model. For additional accessories available, please visit sharkaccessories.co.uk

GETTING STARTED

Detach the CarpetXpert Tank from the unit. Turn the tank over, unscrew cap and remove.

Add water to the CarpetXpert Tank up to the Water fill line. Then add CarpetXpert formula to the Concentrate fill line.

Replace the cap, then reinstall the tank until it clicks into place.

Detach the StainStriker tank from the unit and turn over. Unscrew the cap and pour the StainStriker formula into the tank.

Replace the cap and reinstall the tank until it clicks into place.

Unwrap the power cable and plug into a power socket. Turn ON unit to begin cleaning.

Vacuum with traditional vacuum cleaner first before using Stain Striker.
Use ONLY Shark branded cleaning solutions, CarpetXpert/Oxy Multiplier.

WET STAIN CLEANING

For Wet Stains, follow the Stain Guide located on the hand tool. Turn ON using the power button and vacuum up the liquid mess. Spray the stain area. Scrub with the bristles, then tilt hand tool forward and drag across the stain area to extract liquid. Repeat if needed. To avoid longer dry times, do not over spray.

DRY STAIN CLEANING

For Dry stains, follow the Stain Guide located on the hand tool. Turn ON using the power button. spray the stain area. Scrub stain again, then tilt hand tool forwards and drag across the stain area to extract liquid. Repeat if needed. To avoid longer dry times, do not over spray.

Note: For hard to reach areas, tool can be used without a hand tool attachment using only the crevice tool set up. Tip: Choosing the bristles - The rubber bristles are best suited for more delicate surfaces and upholstery. The tough bristles are ideal for stubborn agitation on hard wearing surfaces.

PET STAIN TRAPPING TOOL

The Shark Pet Stain Trapping Tool is included with select models. This extracts unhygienic messes, preventing the mess from reaching the hose and the interior of the unit. DO NOT use the tool to remove pet hair. To use, spray the wet mess, then extract it as advised above. To avoid oversaturating, do not over spray. DO NOT exceed the MAX FILL line on the Pet Tool Cup.
Keep the tool level, without tipping to prevent the mess from reaching the hose. After use, turn off the power of the main unit and empty the tool cup where appropriate. Wash the cup, filter, and the rest of the tool thoroughly with soap and water after each use.
PET STAIN TRAPPING TOOL

MAINTENANCE

Detach the dirty water tank. keeping the tank upright and set down on a level surface. Push the handle all the way back until it clicks, then lift off the lid.

Clean the float valve and make sure it can move freely. Remove the foam filter from the unit whilst cleaning.

Suitably pour away the dirty liquid from the dirty water tank, tapping off any loose debris. Clean off any other debris on the hand tools, bristles, lid and float valve. Rinse all parts thoroughly with soap and water and allow to air-dry completely before reinstalling.

Detach the hand tool by pressing the release button. Remove the cover from the hand tool to clean the air path. Wash the bristles on the hand tool thoroughly.

To clear any clogged debris, remove the connecting clip on the bottom of the unit. Clear all debris, then close the door.

CLEANING THE HOSE

Make sure the unit is turned off. Remove the solution tank and fill tank with water up to the water fill line.

Securely attach the hose cleaning tool to the crevice tool

Hold the crevice tool in a horizontal position and turn ON the unit. Press and hold the spray trigger for one minute. Repeat the process as needed to remove all dirt and debris from hose.

STORAGE

Unplug the unit and place it near a sink, toilet, or drain to empty the remaining liquid from the attached Tool. Clean the unit and all parts (See Maintenance and Cleaning the Hose sections).

When cleaning is complete and all parts have dried, reattach all the tools. Wrap up the power cord, then store the hose cleaning tool on the unit. Wrap the hose around the base of the unit and store the hand tool in its holder.

CLEANING & DRYING GUIDE

CLEANING:

When applying the cleaning solution, only cover the stain at the beginning of the cleaning process. Avoid oversaturating the area, or continual spraying during cleaning.
For older and tougher stains, allow between 5-20 minutes for the cleaning solution to settle into the stain and get to work.
For fresh stain cleaning, these can be cleaned immediately after spraying.
Always agitate the area thoroughly to break up the stain. Brush in multiple directions for best results.
Always ensure to use the correct solution dilution measures when setting up the unit for cleaning.

DRYING:

When extracting the liquid, pass over the cleaning area in a uniform pattern, applying downward pressure throughout.
Angle the hand tool to engage the suction vents parallel to the cleaning surface for optimum suction.
Continue to pass over the cleaning area until liquid is no longer extracting through the hand tool window.

NOTE: Clean unit after every use to avoid odours, bacteria, and mould.

TROUBLESHOOTING

Problem	Solution
Inconsistent spray or no spray	Ensure there is cleaning solution In both of the solution tanks. Make sure the CarpetXpert Tank is installed correctly. Make sure the unit is plugged in and the power is on.
Low suction or no suction	Make sure the dirty water tank is not overfilled and is installed correctly. Check the clog access point underneath the unit and clear any debris trapped inside at the end of the hose. If a cleaning tool is attached, make sure it is connected correctly. Remove any debris from the cleaning attachments.
Unit not turning on	Make sure the unit is plugged in completely. Try a different socket. Ensure On/Off button was pressed.
Liquid leaking from unit	The dirty water tank may be overfilled. Make sure the dirty water tank and the CarpetXpert Tank are both installed correctly. Make sure the float valve in the dirty water tank is not stuck. Make sure the unit is on a stable, flat surface.
Solution tanks leaking	Make sure the caps on the solution tanks are tightened full. Make sure both tanks are installed correctly and the caps have clicked into place.

CLEANING FORMULAS

Shark Deep Clean Pro

Deep carpet cleaning pro formula for removing dirt & grime.

Shark OXY Multiplier

Tough stain eliminating formula for those stubborn stains & odours.

To order refills of Shark® Deep Clean Pro and Shark OxyMultiplier, scan the QR code.

TECHNICAL SPECIFICATIONS

PX200 Series: =220V - 240V, 60 Hz, 450W

IMPORTANT SAFETY INSTRUCTIONS

FOR HOUSEHOLD USE ONLY
READ CAREFULLY BEFORE USE – SAVE THESE INSTRUCTIONS. FOR HOUSEHOLD USE ONLY; READ ALL INSTRUCTIONS BEFORE USING THIS SPOT CARPET/UPHOLSTERY CLEANER

To reduce the risk of fire, electric shock, Injury, or property damage:

Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the socket is properly grounded.
DO NOT modify the plug provided with the appliance.
DO NOT force into socket or try to modify it.
DO NOT pull, close door, or wrap around sharp edges or corners on the cord. To unplug, grasp the plug, not the cord. Keep cord away from heated surfaces.
To reduce the risk of fire or electric shock due to internal component damage, use ONLY Shark CarpetXpert/StainStriker formula in the correct tanks, as intended for use with this appliance. See instructions within this guide.
The areas around where you are cleaning may become wet, use care to avoid slipping and falling.
Use care when removing and reattaching the hand tool to the Spot Cleaner to avoid accidental activation of the cleaning solution.
DO NOT spray solution on your skin or in your eyes.
DO NOT fill solution tanks while installed on the appliance. Remove before filling.
DO NOT operate if there is any wetting of the exterior surfaces of the appliance. If the appliance is wet, dry with a cloth before use.
To reduce the risk of shock and unintended operation, turn off and unplug Spot Cleaner before any adjustment, cleaning, maintenance, or troubleshooting.
Before each use, carefully inspect each part for damage or wear. If a part is damaged or worn out, immediately discontinue use. DO NOT use if any part is damaged or if Spot Cleaner is not working as it should, has been dropped, left outdoors, or dropped into water.
DO NOT immerse or spray water on the body of the Spot Cleaner. To clean the surface, wipe with a dry cloth.

DO NOT allow to be used by children or as a toy. Close supervision is necessary when used near children.
DO NOT handle plug or Spot Cleaner with wet hands.
DO NOT use without the dirty water tank, clean solution tank, or filter in place.
Use only a identical Shark® replacement parts. Only use Shark® branded filters and accessories.
If plugging unit into extension cord, ensure cord is no more than 15m to prevent damage to the motor.
DO NOT place Spot Cleaner on uneven surfaces.
DO NOT use to pick up:
1. Large objects
2. Hard or sharp objects (glass, nails, screws, or coins)
3. Large quantities of dust (e.g., drywall dust).
4. Smoking or burning objects (hot coals, cigarette butts, or matches)
5. Flammable or combustible materials (lighter fluid, petrol, or kerosene)
6. Toxic materials (chlorine bleach, ammonia, or drain cleaner)
DO NOT use in the following areas:
1. Poorly lit areas
2. Outdoor areas
3. Spaces that are enclosed and may contain explosive or toxic fumes or vapors (lighter fluid, petrol, kerosene, paint, paint thinners, mothproofing substances, or flammable dust).

DO NOT: Engage spray trigger unless pointing at the affected area.

May still spray when the unit is powered off.

© 2023 SharkNinja Operating LLC.
SharkNinja Europe Limited, 3150 Century Way, Thorpe Park, Leeds, LS15 8ZB, UK.
0800 862 0453
sharkclean.co.uk
SharkNinja Germany GmbH, Rotfeder-Ring 9, 60327 Frankfurt am Main, Germany.
SHARK is a registered trademark In the United Kingdom of SharkNinja Operating LLC. STAINSTRIKER is a pending trademark application in the United Kingdom of SharkNinja Operating LLC.
Illustrations may differ from actual product.

Scan QR to view HOW-TO VIDEOS and more.
