- Page 1 X-PLOR Portable Oxygen Concentrator USER-MANUAL Live Life. Breathe Easy. Go X-PLO ® ®...
-
Page 2: Table Of Contents
Table of Contents X-PLOR Checklist ......1 Quick Start Guide ......2 SECTION 1. -
Page 3: X-Plor Checklist
X-PLOR Quick Start Guide Checklist Ensure the following X-PLOR components have arrived in your package: Cartridge found in Mylar bag X-PLOR Unit 8-Cell Battery Cartridge Air filter AC Power Supply DC Power Supply Carry Bag Carry Bag Carry Bag Handle Shoulder Strap WARNING: Do not use the X-PLOR or any accessory if they show any sign... -
Page 4: Quick Start Guide
Quick Start Guide It is quick and easy to get your X-PLOR started, but please read the entire User Manual before using your X-PLOR. DO NOT TURN ON X-PLOR UNTIL STEP 4. 1. REMOVE DUST CAP & INSERT CARTRIDGE • Remove cartridge from mylar bag. -
Page 5: Introduction
1. Introduction This user manual serves as a reference for users of the X-PLOR and should be read in its entirety before operating the X-PLOR. The term “POC” (Portable Oxygen Concentrator) may be used to refer to the X-PLOR. “Patient” and “User” are used interchangeably. X-PLOR enables patients who need a POC to be treated at home according to a clinician’s prescription. -
Page 6: Safety Information
Consult your equipment provider for type of back-up system recommended. WARNING: It is the responsibility of the patient to make back-up arrangements for alternative oxygen supply when traveling. Belluscura assumes no liability ® for persons choosing not to adhere to manufacturer recommendations. -
Page 7: Warnings
• Use of unauthorized parts and accessories could cause injury, invalidate the warranty, or result in costly damage. • Use of accessories other than those approved by Belluscura could result in increased electromagnetic emissions or decreased electromagnetic immunity of X-PLOR. -
Page 8: Cautions
WARNINGS CONTINUED • For proper operation, the POC requires unobstructed ventilation. Always make sure any openings in the case are not obstructed by items which may impede ventilation. Do not place the POC in a small closed space (such as a closet). The POC should not be used adjacent to or stacked with other equipment. -
Page 9: Operating The X-Plor
3. Operating the X-PLOR The X-PLOR is a pulse mode POC. Normal Pulse Dose Mode: Pulse dose is designed to work with a patient’s inhaling and exhaling patterns. It senses a change in air pressure and releases a pulse of air, also known as a bolus, through a nasal cannula. -
Page 10: Audible Alarm
AUDIBLE ALARM BUTTON • Pressing this button during an active alarm will acknowledge and mute the audible alarm. This will not remove the visual icon on the POC display. For more information on the Alarms see Chapter 8. FLOW SETTING CONTROL BUTTONS The X-PLOR provides both Pulse Dose and No Breath Detected Mode to provide oxygen when the user needs it most. -
Page 11: Battery
Up to 4.5 hours of battery life with the 8-cell battery. WARNING: Use only with Belluscura X-PLOR. Use only the power supply listed in the manual. There is a risk of fire, burns, explosion, and release of toxic material if the battery and the power supply are not used properly. - Page 12 The following alarm messages are accompanied by a sound and a yellow BATTERY INDICATOR ON LCD SCREEN • When POC is turned on, the battery indicator will show the level of the battery charge. • Each of the five horizontal yellow bars represents approximately 20% of the total battery charge.
-
Page 13: Charging The Battery
STEPS TO CHARGING THE BATTERY Connect the power supply to the X-PLOR power receptacle on the front of the battery. (Image 1) Plug the other end of the AC power supply (Image 2) into a power outlet, or start the car and plug in the DC (Image 3) power supply into the car's DC outlet. -
Page 14: User-Replaceable Cartridge
5. User-Replaceable Cartridge A cartridge will arrive in a Mylar bag in the box with your X-PLOR. You have to insert the cartridge into the unit before using the X-PLOR. Do not remove the dust cap until it is time to install the cartridge. To insert the cartridge, first ensure the POC is powered off and then disconnect the battery (See Chapter 4). - Page 15 CARTRIDGE REPLACEMENT Turn off the X-PLOR by pressing the power button to shut down the POC. Remove the X-PLOR from the carrying bag, if applicable. Remove the battery from the X-PLOR. (See chapter 4) Place the X-PLOR on its side to access the underside of the POC. (See image 1) Remove the cartridge by pulling on the handle.
-
Page 16: Nasal Cannula
6. Nasal Cannula The proper placement and positioning of the nasal cannula in the nose is critical to the consistent operation of the X-PLOR. The length of the cannula should not exceed 25 feet in length. Tubing lengths greater than 25 feet may impede proper flow. Take care that any hose lying on the floor is not trapped under heavy items or allowed to kink. -
Page 17: Troubleshooting
7. Troubleshooting The table below lists common problems and corrective actions you can take. If you are unable to resolve a problem, please contact your equipment provider. PROBLEM POSSIBLE CAUSE WHAT YOU SHOULD DO Use the AC or DC power cord to operate the device (With the battery inserted) to recharge Battery charge is depleted the battery. -
Page 18: Alarms
8. Alarms NOTIFICATIONS The X-PLOR has only one type of alarm (an icon on the display combined with an audible tone): that arises when monitored equipment functions indicate that the user’s attention is required. Alarm notifications are audible at levels ranging from 65 dB(A) to 85 dB(A), depending on the equipment condition and the user’s position. - Page 19 MESSAGE DISPLAY & TEXT ICONS CONDITION/ACTION/EXPLANATION When the X-PLOR has not detected a breath for 45 seconds, this alarm will alert the user. If the X-PLOR is left idle, the alarm will continue for another 45 seconds before transitioning into No No breath detected Breath Detected Mode (Auto pulse 15 BPM at current setting).
-
Page 20: Accessories & Replacement Parts
9. Accessories and Repleacement Parts X-PLOR accessories available to order: PICTURE # ACCESSORY NAME MODEL # 8-Cell Battery 50188 Cartridge 50073-1 Air filter 50351-1 Carry Bag 52191-1 AC Power Supply 53011-1 DC Power Supply 53021-1 Backpack 52291-1 8-Cell Battery Cartridge Air filter Carry Bag AC Power Supply... -
Page 21: Maintenance & Cleaning
DISPOSAL Belluscura expects end users to dispose of the POC in an environmentally friendly way and in accordance with local laws and regulations. Electrical and electronic equipment is labeled with the crossed-out wheeled bin symbol indicating that the equipment should be disposed of by the end user separate from other types of waste. - Page 22 X-PLOR & RECHARCHEABLE BATTERY The X-PLOR exterior shell and rechargeable battery should be cleaned as needed. X-PLOR To clean the exterior: wipe the outside surface of the case with a cloth dampened in a mild liquid detergent and water solution at room temperature. BATTERY To clean the exterior: wipe the outside surface of the case with a cloth dampened in a mild liquid detergent and water solution at room temperature.
-
Page 23: Labeling Symbols
11. Labeling symbols SYMBOLS MEANING SYMBOLS MEANING Refer to instruction manual/ Do Not Disassemble (Contact booklet. your equipment provider for servicing by authorized personnel). A warning indicates that the personal safety of the patient WARNING may be involved. Disregarding Do Not Dispose of In Unsorted a warning could result in Municipal Waste. - Page 24 USER INTERFACE LABEL SYMBOLS MEANING ON/OFF Button Increase Flow Setting Decrease Flow Setting Audible Alarm Enable / Disable Button POWER STATUS ICONS SYMBOLS MEANING Battery charge level is 0-19%. The actual percentage will be displayed next to the icon. Battery charge level is 20-39%. The actual percentage will be displayed next to the icon.
-
Page 25: Specifications
12. Specifications CONCENTRATOR Dimensions: L / W / H : 7.3 in. (18.5 cm.) / 2.9 in. (7.4 cm.) / 7.6 in. (19.3 cm.) With 8-cell battery Weight of unit with: Without battery: 3.25 lbs; with 8-cell battery: 3.75 lbs Warm-Up Time: Less than 2 minutes Flow Settings:... -
Page 26: Flow Settings & Pulse Volume
CLASSIFICATIONS MODE OF OPERATION CONTINUOUS DUTY Type of Protection Against Class II Electrical Shock: Degree of Protection to Concentrator Components Type BF Against Electrical Shock: IP22 - Vertically falling drops of water shall have no harmful effects when enclosure is tilted at any angle up to 15˚on Degree of Protection to either side of the vertical. -
Page 27: Electromagnetic Interference
13.Electromagnetic Interference X-PLOR provides supplemental oxygen, and it will display an alarm message if there is a condition that interferes with its function. It is designed for use in environments that are within a public low-voltage power supply network used for homes and businesses, in which radio frequency (RF) disturbances are controlled. - Page 28 IEC 60601 TEST COMPLIANCE ELECTROMAGNETIC ENVIRONMENT- TEST/STANDARD LEVEL LEVEL GUIDANCE Mains power quality should be that Immunity to Surges AC Mains Line to AC Mains Line to of a typical residential, commercial or IEC 61000-4-5 Line ±0.5kV, ±1kV Line ±0.5kV, ±1kV hospital environment.
-
Page 29: Traveling With The X-Plor
14. TRAVELING WITH X-PLOR When you travel with your X-PLOR, make sure you pack the following: • Fully charged battery • Enough fully charged batteries to last at least 150% of the length of your flight or the period of time when you will not be able to charge your battery. •... - Page 32 To contact customer service, reorder accessories, or more: Please visit XPLOROxygen.com or call (877)-GO-XPLOR. Belluscura Company Address: 15 Fetter Lane - London, United Kingdom EC4A 1BW 5504 Democracy Drive, Plano TX, 75024 ® ©2023 Belluscura LLC. All rights Reserved LBL 200-05-10-0040.C...
