Black & Decker FUSIONBLADE BL1120 - 12-Speed Blender Manual

Product may vary slightly from what is illustrated.

1. † Lid cap (Part# BL1130-01)
2. † Lid (Part# BL1130-02)
3. †3. Blending jar (Part# BL1130-03)
4. Handle
5. † Blade assembly
   (Part# BL1130-04)
6. † Jar base (Part# BL1130-06)

7. Speed buttons
8. Base
9. PULSE/OFF button

Note: † indicates consumer replaceable/removable parts

CONTROL PANEL

POLARIZED PLUG (120V MODELS ONLY)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

ELECTRICAL CORD

The cord of this appliance was selected to reduce the possibility of tangling in or tripping over a longer cord. If more length is needed, use an extension cord rated no less than 15-amperes. (For 120 volts rated products, use an extension cord rated no less than 6-amperes). When using an extension cord, do not let it drape over the working area or dangle where someone could accidentally trip over it. Handle cord carefully for longer life; avoid jerking or straining it at outlet and appliance connections.

TAMPER-RESISTANT SCREW

This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside. Repair should be done only by authorized service personnel.
Note: If the power supply cord is damaged, it should be replaced by qualified personnel; in Latin America, by an authorized service center.

HOW TO USE

This unit is for household use only.

GETTING STARTED

• Remove all packing material and any stickers from the product.
• Please go to www.prodprotect.com/applica to register your warranty.
• Wash all removable parts as instructed in CARE AND CLEANING section of this manual.

BLENDER JAR ASSEMBLY

1. Turn blending jar upside down and place flat on counter top or work surface.
2. Place the blade assembly in bottom opening of the jar with blades down.
3. Place jar base onto jar and rotate clockwise until it is tight (A).

4. Turn assembled jar right side up.
5. Place lid with lid cap on blender jar.
6. Uncoil power cord from storage area under the base.
7. Place jar assembly on base. (B).

8. Blender is now ready for use.

USING YOUR BLENDER

Appliance should always have lid in place when in use.

Do not place blender jar onto base when motor is running.

1. Make sure appliance is OFF.
2. Place foods to be blended into jar.
3. Place lid on jar; make sure lid cap is in place.
4. Plug power cord into outlet.
   Note: When in use, do not leave blender unattended. When using hard foods, such as ice or cheese, keep one hand on the lid to keep blender in place.
5. Select the speed that best suits your desired task. (See SPEED CHART)
6. For blending tasks – or when blending thick mixtures – use the PULSE button for several seconds, then release. Repeat until food has desired consistency. Releasing the PULSE button automatically turns the blender off (C).

7. Open the lid cap to add ingredients while the blender is running and drop ingredients through the opening (D).

   Do not remove the lid while the blender is running.

8. When finished, press the PULSE/OFF button. Make sure blades have completely stopped before attempting to remove the blending jar from the base.
9. To remove the jar, grasp the handle and lift up.
10. Remove lid to pour.
11. Always unplug the appliance when not in use.

BLENDING TIPS AND TECHNIQUES

• Cut food into pieces no larger than ¾" for use in the blender.
• When preparing foods that have several different kinds of ingredients, always add liquid ingredients first.
• When ingredients splatter onto the sides of the jar or the mixture is very thick, press the PULSE/OFF button to turn appliance off. Remove the lid and use a rubber spatula to scrape down the sides of the jar and to redistribute the food, pushing food toward the blades. Replace the lid and continue blending.
• The lid cap holds up to 2 oz. of liquid and can be used as a measure when adding ingredients such as juices, milk, cream or liquor.
• When making bread crumbs make sure blender jar is completely dry.
• When using PULSE function, use short bursts. Allow the blades to stop rotating between pulses. Do not use PULSE for more than 2 minutes.
• Use the ICE CRUSH button when preparing beverages that include ice cubes or anything frozen; this helps to produce a smoother texture.
• The PULSE function is helpful when short bursts of power are needed, such as when preparing thick smoothies or milkshakes.
• It is helpful to begin the blending process on the lowest speed and then increase to a higher speed, if necessary.
• To stop blending at any time, press the PULSE/OFF button.
• When blending hot ingredients, remove the lid cap and then put it back partly open, with the opened side tilted away from you. Cover lid with a cloth to avoid splattering and only use the lowest speed. Do not blend more than 2½ to 3 cups at a time.

DO NOT PLACE ANY OF THE FOLLOWING IN THE BLENDER:

• Large pieces of frozen foods
• Tough foods such as raw turnips, sweet potatoes and potatoes
• Bones
• Hard salami, pepperoni
• Boiling liquids (cool for 5 minutes before placing in blending jar)

OTHER DONT'S:

• Do not operate blender without the lid on the blending jar.
• Do not store foods in the blending jar.
• Do not overfill the blender (the blender is more efficient with less rather than more).
• Do not put boiling liquids into blender.
• Do not use PULSE for more than 10 seconds at a time; release the PULSE/OFF button regularly, allow the blender to rest briefly, then continue.
• Do not run blender for longer than 1½ minutes at a time. Scrape down sides of blending jar, if necessary, and continue blending.
• Do not use if blending jar is chipped or cracked.

TASKS NOT RECOMMENDED FOR THE BLENDER:

• Beating egg whites
• Mixing dough
• Mashing potatoes
• Grinding meats

SPEED CHART

RECIPES

BLUE CHEESE SALAD DRESSING
This creamy, fresh dressing is great with any salad greens. Try it as a dip with chicken wings or as a dip for your favorite veggies.

• ½ cup sour cream
• ¼ cup mayonnaise

• 1 Tbsp. fresh chopped parsley
• 1 garlic clove, peeled and chopped
• 2 tsp. lemon juice
• 1/8 tsp. each, salt and pepper

Place all ingredients in blender jar. Cover; press Blend/Stir and run 30 seconds or until blended.
Store covered in refrigerator up to 2 days. Stir before using. For a larger batch, double the recipe and prepare using the full size blender jar.
Makes about 1 cup.

QUICK AND EASY SALSA
This fast and easy restaurant-style salsa is a great substitution for fresh Pico de Gallo when tomatoes are no longer in season. Serve it with your favorite chips or as a topping for tacos.

• 2 cans (10 oz.) diced tomatoes with green chilies
• ½ small onion, quartered
• 1 small jalapeno pepper, seeded, deveined
• 1 clove garlic, peeled and smashed
• 1/2 cup loosely packed cilantro leaves
• 1 Tbsp. lime juice
• 1 tsp. sugar
• 1/2 tsp. cumin
• ½ tsp. salt

Place all ingredients in blender jar. Cover and pulse 30 seconds or to desired consistency. For a small batch, cut recipe in half and blend in your personal size blender jar.

CARE AND CLEANING

This product contains no user serviceable parts. Refer service to qualified service personnel.

CLEANING

1. Before cleaning, turn off and unplug the appliance.
2. Lift the blending jar by the handle off the base turning slightly counterclockwise.
3. Remove jar base by turning it counterclockwise until loose.
4. Remove the blade assembly.

   Blades are sharp, handle carefully.
5. Remove lid and lid cap.
6. Wash removable parts by hand or in the dishwasher. Place the jar on the bottom rack and the rest of the parts on the top rack only.

Helpful Tips:

• For quick cleanup, combine 1 cup hot water and a drop of liquid dish soap in the blending jar.
• Cover and blend on CLEAN for about 30 seconds.
• Discard liquid and rinse thoroughly.

• Do not place the jar parts in boiling liquids.
• Do not immerse the base in liquid. Wipe the base with a damp cloth and dry thoroughly.
• Remove stubborn spots by rubbing with a damp cloth and nonabrasive cleaner.
  Note: If liquids spill onto the base, wipe with a damp cloth and dry thoroughly. Do not use rough scouring pads or cleansers on parts or finish.

Model: BL1120
Customer Care Line: 1-800-231-9786
For online customer service: www.prodprotect.com/applica
