- Page 1 Reyee RG-E6 Home Wi-Fi Router Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023-09-26...
-
Page 2: Table Of Contents
Contents 1 Product Introduction ........................... 1 1.1 Overview ............................ 1 1.2 Package Contents........................1 1.3 Appearance ..........................2 1.3.1 Top View ......................... 2 1.3.2 Back View ........................3 1.4 Technical Specifications ......................4 1.5 Power Supply Technical Specifications ..................5 1.6 Cooling ............................ - Page 3 3.3.2 Connecting Cables ....................... 11 3.4 Bundling Cables ........................12 3.5 Verifying the Installation ......................12 4 Debugging ............................13 4.1 Setting Up the Configuration Environment ................13 4.2 Powering On ..........................13 4.2.1 Checking Before Power-on ..................13 4.2.2 Checking After Power-on ..................... 13 4.3 Troubleshooting Power Failures ....................
-
Page 4: Product Introduction
Product Introduction Overview The RG-E6 router is a dual-band Gigabit Wi-Fi 6 wireless router designed especially for gamers seeking a top- notch Wi-Fi experience. Designed with the next-generation Wi-Fi 6 technology, it delivers mind-blowing speeds of up to 6000 Mbps across both bands. Featuring a 2.5 Gbps WAN/LAN port and a flagship-grade 2.0 GHz quad-core processor, this router comes packed with power and delivers an incredibly strong signal thanks to the eight independent power amplifiers. -
Page 5: Appearance
Fast blinking: The router is starting up. Press the button for less than 2 seconds: This device Reyee Mesh/Game turbo serves as the primary router, and starts mesh networking. button... -
Page 6: Back View
Hardware Installation and Reference Guide Product Introduction 1.3.2 Back View Figure 1-2 Back View Table 1-3 Ports and Buttons Mark Item Description Press and hold for less than 1 second: No action is triggered. Reset button Press and hold for more than 10 seconds: The router is restored to factory defaults. -
Page 7: Technical Specifications
Hardware Installation and Reference Guide Product Introduction Technical Specifications Table 1-4 Specifications Radio Design 2.4 GHz and 5 GHz dual-radio four-stream Protocol and Standard Supports 802.11ax, 802.11ac wave2/wave1 and 802.11a/b/g/n standards for simultaneous operation Operating Frequency 802.11b/g/n/ac/ax: 2.4 GHz to 2.4835 GHz Bands 802.11a/n/ac/ax: 5.1 GHz: 5.150 to 5.350 GHz;... -
Page 8: Power Supply Technical Specifications
Hardware Installation and Reference Guide Product Introduction Power Step Dimensions (W x D x 242 mm × 242 mm × 64 mm (9.53 in. × 9.53 in. × 2.52 in.) (excluding antenna) 293 mm × 293 mm × 64 mm (11.54 in. ×11.54 in. × 2.52 in.) (including antenna) Net Weight 1.3 kg (2.87 lbs.) Service Ports... -
Page 9: Cooling
Hardware Installation and Reference Guide Product Introduction Cooling This router adopts a fanless design. Therefore, a sufficient clearance needs to be maintained around the router for cooling. techsupport@ireyee.com... -
Page 10: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions This router plays a vital role in connecting networks, and its proper functioning is crucial for ensuring the normal operation of all interconnected subnetworks. The following safety precautions must be followed during installation and use: ... -
Page 11: Esd Protection Requirements
Hardware Installation and Reference Guide Preparing for Installation but also increases the likelihood of communication failures. The risk of electrostatic adsorption increases when the indoor relative humidity is low. The following table describes the requirements for the dust content and granularity. Max. -
Page 12: Checking The Mounting Workbench
Wire stripper, crimping plier, RJ45 crimping plier, and wire cutter Tools Meters Multimeter and bit error rate tester (BERT) Note The RG-E6 router is not shipped with a tool kit. You need to prepare a tool kit by yourself. techsupport@ireyee.com... -
Page 13: Installation
Hardware Installation and Reference Guide Installation Installation Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2. Before You Begin Carefully plan and arrange the installation location, networking mode, power supply, and cabling of the device before installation. -
Page 14: Connecting Cables
Hardware Installation and Reference Guide Installation Do not place the router in a place where it will be exposed to moisture or excessive heat. Keep the router away from devices with strong electromagnetic interference, such as Bluetooth devices, microwave ovens, or cordless phones. Generally, the router is placed on a horizontal surface, such as on a shelf or desktop. -
Page 15: Bundling Cables
Hardware Installation and Reference Guide Installation Bundling Cables Note Bundle the cables in a visually pleasing way. Make sure that the twisted pair cables at the connectors have natural bends or bends of large radius. Do not bind twisted pair cables too tightly, as this may press the twisted pair cables and affect their service life and transmission performance. -
Page 16: Debugging
Hardware Installation and Reference Guide Debugging Debugging Setting Up the Configuration Environment Verify that the power cables are in good condition and meet safety requirements. Powering On 4.2.1 Checking Before Power-on Verify that the DC power cord connector of the device is in good condition, and that the device does not shake when the DC power adapter is connected to the DC power cord connector. -
Page 17: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring You can observe the LED status to monitor the device in operation. Hardware Maintenance If the hardware is faulty, please email us at techsupport@ireyee.com. techsupport@ireyee.com... -
Page 18: Common Troubleshooting
Hardware Installation and Reference Guide Common Troubleshooting Common Troubleshooting Troubleshooting Flowchart Common Faults 6.2.1 The LED Is Off After the Device Is Powered On Verify that the supplied power adapter is connected properly, and that the Ethernet cable is connected properly. 6.2.2 The Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In Verify that the device at the other end of the Ethernet cable is working properly. -
Page 19: A Client Cannot Discover The 5 Ghz Ssid Of The Router
Hardware Installation and Reference Guide Common Troubleshooting 6.2.4 A Client Cannot Discover the 5 GHz SSID of the Router Verify that a 5 GHz SSID is configured on the router. Verify that the router is compliant with the IEEE 802.3at standard. techsupport@ireyee.com... -
Page 20: Appendixes
Hardware Installation and Reference Guide Appendixes Appendixes Appendix A Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port The 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, the 1000BASE-T port requires Category 5e 100-ohm UTP or STP (recommended) with a maximum distance of 100 meters (328 feet). -
Page 21: Appendix C Compliance Statements
Hardware Installation and Reference Guide Appendixes The following figure shows feasible connections of the straight-through and crossover twisted pair cables for a 100BASE-TX/10BASE-T port. Figure 7-2 100BASE-TX/10BASE-T Twisted Pair Connections Straight-Through Crossover Switch Adapter Switch Switch Appendix C Compliance Statements The router complies with the European Commission (EC) Regulation No.
