Summary of Contents for Husqvarna FC 250 Heritage 2023
- Page 1 OWNER'S MANUAL 2023 FC 250 FC 250 Heritage Art. no. 3402631en...
- Page 3 DEAR HUSQVARNA MOTORCYCLES CUSTOMER Congratulations on your decision to purchase a Husqvarna motorcycle. You are now the owner of a state-of- DEAR HUSQVARNA MOTORCYCLES CUSTOMER the-art, sporty motorcycle that you will continue to enjoy for a long time if you maintain it properly.
-
Page 4: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 6.15 Plug-in stand........20 MEANS OF REPRESENTATION......5 PREPARING FOR USE........21 Symbols used ........5 Formats used ........5 Advice on preparing for first use..21 Running in the engine ......22 SAFETY ADVICE ..........6 Starting power of lithium-ion Use definition –... - Page 5 TABLE OF CONTENTS 10.8 Checking the static sag of the 11.30 Removing the main silencer....68 shock absorber ........40 11.31 Installing the main silencer....69 10.9 Checking the riding sag of the 11.32 Changing the glass fiber yarn filling shock absorber ........
- Page 6 TABLE OF CONTENTS 13.7 Checking the spoke tension ..... 101 TECHNICAL SPECIFICATIONS..... 131 ELECTRICAL SYSTEM........102 22.1 Engine ..........131 22.2 Engine tightening torques....132 14.1 Removing the 12-V battery ... 102 22.3 Capacities ......... 134 14.2 Installing the 12-V battery .....
-
Page 7: Means Of Representation 1
Indicates work that requires expert knowledge and technical understanding. In the interests of your own safety, have these jobs performed by an authorized Husqvarna Motorcycles workshop. Your motorcycle will be cared for there to the highest degree by specially trained experts using the special tools required. -
Page 8: Safety Advice
2 SAFETY ADVICE Use definition – intended use This vehicle has been designed and built to withstand the normal stresses and strains of racing. This vehicle complies with the currently valid regulations and categories of the top international motorsports organizations. Info Only operate this vehicle in closed-off areas remote from public road traffic. -
Page 9: Tampering Warning
Only operate the vehicle when it is in perfect technical condition, in accordance with its intended use, and in a safe and environmentally compatible manner. The vehicle should only be used by trained persons. Have malfunctions that impair safety immediately eliminated by an authorized Husqvarna Motorcycles work- shop. Adhere to the information and warning labels on the vehicle. -
Page 10: Protective Clothing
– Always wear protective clothing that is in good condition and meets the legal regulations. In the interest of your own safety, Husqvarna Motorcycles recommends that you only operate the vehicle while wearing protective clothing. Work rules Unless specified otherwise, the ignition must be turned off during all work (models with ignition lock, models with transponder key) or the motor must be at a standstill (models without ignition lock or transponder key). - Page 11 The Owner's Manual can be downloaded several times using the QR code or the link on the delivery certificate. The Owner's Manual is also available for download from your authorized Husqvarna Motorcycles dealer and on the Husqvarna Motorcycles website. A printed copy can also be ordered from your authorized Husqvarna Motorcycles dealer.
-
Page 12: Important Notes
3 IMPORTANT NOTES Manufacturer warranty, implied warranty The work prescribed in the service schedule must only be carried out in an authorized Husqvarna Motorcy- cles workshop and confirmed in the Husqvarna Motorcycles Dealer.net, as otherwise all warranty claims will be void. Damage or secondary damage caused by tampering with and/or conversions on the vehicle are not covered by the manufacturer warranty. -
Page 13: View Of Vehicle 4
VIEW OF VEHICLE 4 View of vehicle, front left (example) A01202-10 Hand brake lever ( p. 15) Clutch lever ( p. 15) Fuel tank filler cap Air filter box cover Cold start button ( p. 18) Engine number ( p. 13) Shift lever ( p. -
Page 14: View Of Vehicle, Rear Right (Example)
4 VIEW OF VEHICLE View of vehicle, rear right (example) A01203-10 Shock absorber compression adjuster Combination switch ( p. 16) Stop button ( p. 15) Start button ( p. 16) Throttle grip ( p. 15) Vehicle identification number ( p. 13) Steering head label ( p. -
Page 15: Serial Numbers
SERIAL NUMBERS 5 Vehicle identification number The vehicle identification number is stamped on the right side of the steering head. 401945-10 Steering head label The steering head label is attached to the front of the steering head. 401946-10 Engine number Engine number is embossed on the left side of the engine above the engine sprocket. -
Page 16: Shock Absorber Article Number
5 SERIAL NUMBERS Shock absorber article number The shock absorber article number is stamped on the top of the shock absorber. F03756-10... -
Page 17: Controls 6
CONTROLS 6 Clutch lever The clutch lever is fitted on the left side of the handlebar. The clutch is hydraulically operated and self-adjusting. F03647-10 Hand brake lever The hand brake lever is located on the right side of the han- dlebar. -
Page 18: Start Button
6 CONTROLS Start button Start button is fitted on the right side of the handlebar. Possible states • The start button is in the basic position is pressed – In this position, the starter • The start button motor is actuated. F03650-10 Combination switch The combination switch is fitted on the left side of the handlebar. -
Page 19: Combination Instrument
CONTROLS 6 Combination instrument The combination instrument is attached in front of the han- dlebar. The combination instrument shows the total number of operating hours of the engine. The operating hour counter begins counting when the engine is started and stops when the engine is switched off. Info Nothing can be cleared or adjusted on the combination instrument. -
Page 20: Closing The Fuel Tank Filler Cap
6 CONTROLS 6.10 Closing the fuel tank filler cap – Mount fuel tank filler cap and turn it clockwise until the fuel tank is tightly closed. Info Route fuel tank breather hose without kinks. A01173-10 6.11 Cold start button The cold start button is fitted to the bottom of the throttle valve body. -
Page 21: Idle Speed Adjusting Screw
CONTROLS 6 6.12 Idle speed adjusting screw The idle setting of the throttle valve body substantially influences the vehicle’s starting behavior, a stable idle speed, and the vehi- cle’s response when the throttle is opened. An engine with a correctly set idle speed is easier to start than an engine with the idle speed set incorrectly. -
Page 22: Foot Brake Lever
6 CONTROLS 6.14 Foot brake lever Foot brake lever is located in front of the right footrest. The foot brake lever is used to activate the rear brake. 401956-10 6.15 Plug-in stand The holder for the plug-in stand is the left side of the wheel spindle. -
Page 23: Preparing For Use 7
When using the motorcycle, remember that others may be disturbed by excessive noise. – Ensure that the pre-sale inspection work has been carried out by an authorized Husqvarna Motorcycles workshop. You will receive a delivery certificate when the vehicle is handed over. -
Page 24: Running In The Engine
7 PREPARING FOR USE – Adjust basic position of the hand brake lever. ( p. 83) – Adjust the basic position of the foot brake lever. p. 90) – Adjust the basic position of the shift lever. p. 117) – Get used to the handling characteristic of the motorcycle on suitable terrain before undertaking a more challenging ride. -
Page 25: Preparing The Vehicle For Difficult Operating Conditions
Preparing the vehicle for rides on dry sand – Mount the air filter dust cover. Air filter dust cover (A46009620000) Info Observe the fitting instructions for Husqvarna Motor- cycles technical accessories. F03669-01 – Mount the air filter sand cover. Air filter sand cover (A46006922000) -
Page 26: Preparing The Vehicle For Rides On Wet Sand
600868-01 Preparing the vehicle for rides on wet sand – Mount the air filter rain cover. Air filter rain cover (A46006921000) Info Observe the fitting instructions for Husqvarna Motor- cycles technical accessories. F03669-01 – Clean the chain. Chain cleaner ( p. -
Page 27: Preparing Vehicle For High Temperatures Or Slow Riding
– Check the coolant level. ( p. 109) Preparing the vehicle for low temperatures or snow – Mount the air filter rain cover. Air filter rain cover (A46006921000) Info Observe the fitting instructions for Husqvarna Motor- cycles technical accessories. F03669-01... -
Page 28: Riding Instructions
8 RIDING INSTRUCTIONS Checks and maintenance measures when preparing for use Info Before every trip, check the condition of the vehicle and ensure that it is safe to operate. The vehicle must be in perfect technical condition when it is being operated. –... -
Page 29: Activating Launch Control
RIDING INSTRUCTIONS 8 – Remove plug-in stand – Shift the transmission to the neutral position. H02629-10 Condition Ambient temperature: < 20 °C (< 68 °F) – Push the cold start button in all the way. – Press start button Info Press the start button for a maximum of 5 sec- onds. -
Page 30: Activating Traction Control
8 RIDING INSTRUCTIONS Info The launch control is deactivated automatically for a few seconds after the vehicle has started. Launch control is also deactivated in the following cases: if the throttle valve is closed more than 1/3 of the way after full throttle, and/or if there is no start within 3 minutes. -
Page 31: Quickshifter
Do not change into a low gear at high engine speed. Info If unusual noises occur while riding, stop immediately, switch off the engine, and contact an authorized Husqvarna Motorcycles workshop. First-gear is used for starting off and for steep inclines. –... -
Page 32: Applying The Brakes
Danger of accidents A spongy pressure point on the front or rear brake reduces braking efficiency. – Check the brake system and do not continue riding until the problem is eliminated. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) -
Page 33: Stopping, Parking
RIDING INSTRUCTIONS 8 Warning Danger of accidents Moisture and dirt impair the brake system. – Brake carefully several times to dry out and remove dirt from the brake linings and the brake discs. – On sandy, wet, or slippery surfaces, use mostly the rear brake. –... -
Page 34: Transporting
8 RIDING INSTRUCTIONS 8.11 Transporting Note Danger of damage The parked vehicle can roll away or fall over. – Park the vehicle on a firm and level surface. Note Fire hazard Hot vehicle components pose a fire hazard and explosion risk. – Do not park the vehicle near to materials which are highly flammable or explosive. - Page 35 In some countries and regions, the available fuel quality and cleanliness may not be sufficient. This will result in problems with the fuel system. – Refuel only with clean fuel that meets the specified standards. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) Note Environmental hazard Improper handling of fuel is a danger to the environment.
-
Page 36: Service Schedule
Individual service intervals and scopes may change in the course of technical developments. The most up- to-date service schedule can always be found on Husqvarna Motorcycles Dealer.net. Your authorized Husq- varna Motorcycles dealer will be glad to advise you. - Page 37 ● ● Take a test ride. ○ ● ● ● ● Read out the fault memory after the test ride using the Husqvarna Motorcycles diag- nostics tool. ○ ● ● ● ● Make a service entry in Husqvarna Motorcycles Dealer.net.
-
Page 38: 10 Tuning The Chassis
– In the delivered condition, Husqvarna motorcycles are adjusted for an average rider's weight (with full protective clothing). Guideline Standard rider weight 75 …... -
Page 39: Compression Damping Of The Shock Absorber
The shock absorber is filled with highly compressed nitrogen. – Please follow the description provided. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) Info The effect of the low-speed compression adjuster can be seen in slow to normal compression of the shock absorber. -
Page 40: Adjusting The High-Speed Compression Damping Of The Shock Absorber
The shock absorber is filled with highly compressed nitrogen. – Please follow the description provided. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) Info The effect of the high speed compression adjuster can be seen in the fast compression of the shock absorber. -
Page 41: Measuring The Dimension Of The Rear Wheel Unloaded
TUNING THE CHASSIS 10 – Turn adjuster clockwise up to the last perceptible click. – Turn counterclockwise by the number of clicks correspond- ing to the shock absorber type. Guideline Rebound damping (All EU models) Comfort 17 clicks Standard 15 clicks Sport 13 clicks F03640-10... -
Page 42: Checking The Static Sag Of The Shock Absorber
10 TUNING THE CHASSIS 10.8 Checking the static sag of the shock absorber – Measure dimension of rear wheel unloaded. ( p. 39) – Hold the motorcycle upright with aid of an assistant. – Measure the distance again between the rear axle and mark- ing SAG on the rear fender using the sag gage. -
Page 43: Adjusting The Spring Preload Of The Shock Absorber
The shock absorber is filled with highly compressed nitrogen. – Please follow the description provided. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) Info Note the current adjustment before changing the spring preload - e.g. measure the spring length. -
Page 44: Adjusting The Riding Sag
10 TUNING THE CHASSIS – Install the right side panel. ( p. 68) – Check the free travel of the foot brake lever. ( p. 89) – Remove the motorcycle from the lift stand. ( p. 49) 10.11 Adjusting the riding sag Preparatory work –... -
Page 45: Checking The Basic Setting Of The Fork
TUNING THE CHASSIS 10 10.12 Checking the basic setting of the fork Info For various reasons, no exact riding sag can be determined for the fork. – Smaller differences in the rider's weight can be compensated for by the fork air pressure. –... -
Page 46: Adjusting The Compression Damping Of The Fork
10 TUNING THE CHASSIS Info This is due to the volume of the hose and not due to a defect in the fork airpump or the fork. Observe the accompanying instructions for Husq- varna Motorcycles technical accessories. – Adjust the air pressure as specified. Guideline Air pressure (All EU models) 10.3 bar (149 psi) -
Page 47: Adjusting The Rebound Damping Of The Fork
TUNING THE CHASSIS 10 Guideline Compression damping (All EU models) Comfort 17 clicks Standard 12 clicks Sport 7 clicks Compression damping (All US models) Comfort 17 clicks Standard 12 clicks Sport 7 clicks Info Turn clockwise to increase damping; turn counter- clockwise to reduce damping during compression. -
Page 48: Handlebar Position
10 TUNING THE CHASSIS 10.16 Handlebar position The holes on the handlebar support are placed at a distance from the center. Hole distance A 3.5 mm (0.138 in) The handlebar can be mounted in 2 different positions. This allows the handlebar to be mounted in the most comfortable position for the rider. - Page 49 TUNING THE CHASSIS 10 Main work – Remove screws . Take off handlebar clamp . Take off the handlebar and lay it to one side. Info Cover the components to protect them against dam- age. Do not kink the cables or lines. –...
- Page 50 10 TUNING THE CHASSIS Adjusting the handlebar position with the handlebar clamp – Place the handlebar support in the required position. Info The handlebar support is longer and higher on one side. – Mount and tighten the screws with the bushings Guideline Screw, handle- 40 Nm (29.5 lbf ft)
-
Page 51: Service Work On The Chassis 11
SERVICE WORK ON THE CHASSIS 11 11.1 Raising the motorcycle with a lift stand Note Material damage The vehicle may be damaged by incorrect procedure when parking. Significant damage may be caused if the vehicle rolls away or falls over. The components for parking the vehicle are designed only for the weight of the vehicle. –... -
Page 52: Bleeding The Fork Legs
11 SERVICE WORK ON THE CHASSIS 11.3 Bleeding the fork legs Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) Main work – Release bleeder screws Any excess pressure escapes from the interior of the fork. –... -
Page 53: Removing The Fork Protector
SERVICE WORK ON THE CHASSIS 11 11.5 Removing the fork protector – Remove screws and take off the clamp. – Remove screws and take off the left fork protector. – Remove screws and take off the right fork protector. A01213-10 11.6 Installing the fork protector –... -
Page 54: Installing The Fork Legs
11 SERVICE WORK ON THE CHASSIS – Loosen screws . Remove the left fork leg. – Loosen screws . Remove the right fork leg. A01189-10 11.8 Installing the fork legs Main work – Position the fork legs. Air bleeder screw of the right fork leg is positioned to the front. -
Page 55: Removing The Lower Triple Clamp
SERVICE WORK ON THE CHASSIS 11 11.9 Removing the lower triple clamp Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) – Remove the front wheel. p. 96) – Remove the fork legs. p. 51) – Remove the start number plate. -
Page 56: Installing The Lower Triple Clamp
11 SERVICE WORK ON THE CHASSIS 11.10 Installing the lower triple clamp Main work – Clean the bearing and sealing elements, check for damage, and grease. High viscosity grease ( p. 143) – Insert the lower triple clamp with the steering stem. Mount upper steering head bearing. - Page 57 SERVICE WORK ON THE CHASSIS 11 – Tighten screws Guideline Screw, bottom triple 12 Nm (8.9 lbf ft) clamp A01198-10 – Tighten screw Guideline Screw, top steering M20x1.5 12 Nm (8.9 lbf ft) head A01191-11 – Mount and tighten screw Guideline Screw, top 20 Nm (14.8 lbf ft)
-
Page 58: Checking The Steering Head Bearing Play
Danger of accidents Incorrect steering head bearing play impairs the handling characteristic and damages components. – Correct incorrect steering head bearing play immediately. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) Info If the vehicle is operated for a lengthy period with play in the steering head bearing, the bearings and the bearing seats in the frame can become damaged over time. -
Page 59: Adjusting Steering Head Bearing Play
SERVICE WORK ON THE CHASSIS 11 11.12 Adjusting steering head bearing play Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) – Remove the handlebar cushion. Main work – Loosen screws – Remove screw – Loosen and retighten screw Guideline Screw, top steering M20x1.5... -
Page 60: Removing The Start Number Plate
11 SERVICE WORK ON THE CHASSIS 11.14 Removing the start number plate – Remove screw – Unhook the start number plate from the brake line and remove it. A01216-10 11.15 Installing the start number plate – Position the brake line in holders on the start number plate. -
Page 61: Installing The Front Fender
SERVICE WORK ON THE CHASSIS 11 11.17 Installing the front fender Main work – Position the front fender. Mount and tighten screws Guideline Screw, fender 12 Nm (8.9 lbf ft) A01174-10 Finishing work – Install the start number plate. ( p. -
Page 62: Installing The Shock Absorber
11 SERVICE WORK ON THE CHASSIS – Remove screws – Pull off foot brake cylinder from the push rod. F03701-10 – Remove the connecting link of the chain. – Take off the chain. Info Cover the components to protect them against dam- age. - Page 63 SERVICE WORK ON THE CHASSIS 11 – Position the link fork and mount the swingarm pivot. Info Pay attention to flat area – Mount and tighten nut Guideline Nut, fork pivot M16x1.5 100 Nm (73.8 lbf ft) F03705-10 – Mount the chain. –...
-
Page 64: Removing The Seat
11 SERVICE WORK ON THE CHASSIS – Position the left frame protector. – Insert the right frame protector from below and push it to the rear. – Mount and tighten screws with washers. Guideline Screw, frame pro- 3 Nm (2.2 lbf ft) tector –... -
Page 65: Mounting The Seat
SERVICE WORK ON THE CHASSIS 11 11.21 Mounting the seat – Attach the seat to the collar bushings at the front and simul- taneously push it back. The holding lugs engage in the recesses at the back. – Make sure the seat is latched in place correctly. A01197-10 –... -
Page 66: Installing The Air Filter Box Cover
11 SERVICE WORK ON THE CHASSIS Condition The air filter box cover is not secured. – Pull off the air filter box cover in area and push it side- ways and forward. Take off the air filter box cover. A01177-11 11.23 Installing the air filter box cover Condition... -
Page 67: Removing The Air Filter
SERVICE WORK ON THE CHASSIS 11 Condition The air filter box cover is not secured. – Insert the air filter box cover in area and clip it into area Info An air filter box cover with openings for greater airflow and a more direct response is included. A01178-10 11.24 Removing the air filter... -
Page 68: Cleaning The Air Filter And Air Filter Box
11 SERVICE WORK ON THE CHASSIS 11.25 Cleaning the air filter and air filter box Note Environmental hazard Hazardous substances cause environmental damage. – Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable regulations. Info Do not clean the air filter with fuel or petroleum since these substances attack the foam. -
Page 69: Installing The Air Filter
SERVICE WORK ON THE CHASSIS 11 11.26 Installing the air filter Main work – Mount the clean air filter on the air filter support. Info The marking on the air filter support must face upwards. – Grease the air filter in area Long-life grease ( p. -
Page 70: Removing The Right Side Panel
11 SERVICE WORK ON THE CHASSIS Finishing work – Install the air filter box cover. ( p. 64) 11.28 Removing the right side panel – Unhook right side panel in area , slide forward in area and unhook and detach in area Info If the side panel does not have to be completely removed, the side panel can remain hooked into... -
Page 71: Installing The Main Silencer
SERVICE WORK ON THE CHASSIS 11 – Detach spring Spring hook (50305017000C1) – Remove screws with the washers and take off the main silencer. A01181-10 11.31 Installing the main silencer – Position the main silencer. – Mount screws with washers, but do not tighten yet. –... -
Page 72: Removing The Fuel Tank
11 SERVICE WORK ON THE CHASSIS Main work – Remove the screws on the main silencer. – Take off silencer cap and O-ring – Pull glass fiber yarn filling out of the silencer cap. – Pull glass fiber yarn filling from the inner tube. - Page 73 SERVICE WORK ON THE CHASSIS 11 Main work – Unplug fuel pump connector – Clean quick release coupling thoroughly with compressed air. Info Under no circumstances should dirt enter into the fuel line. Dirt in the fuel line clogs the injection valve! H04981-10 –...
-
Page 74: Installing The Fuel Tank
11 SERVICE WORK ON THE CHASSIS 11.34 Installing the fuel tank Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –... -
Page 75: Checking For Chain Dirt Accumulation
SERVICE WORK ON THE CHASSIS 11 – Plug in fuel pump connector – Remove the wash cap set and thoroughly clean the quick release coupling using compressed air. Info Under no circumstances should dirt enter into the fuel line. Dirt in the fuel line clogs the injection valve! –... -
Page 76: Checking The Chain Tension
11 SERVICE WORK ON THE CHASSIS Info The service life of the chain depends largely on its maintenance. Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) Main work – Rinse off loose dirt with a soft jet of water. –... -
Page 77: Adjusting The Chain Tension
SERVICE WORK ON THE CHASSIS 11 11.38 Adjusting the chain tension Warning Danger of accidents Incorrect chain tension damages components and results in accidents. If the chain is tensioned too much, the chain, engine sprocket, rear sprocket, transmission and rear wheel bearings wear more quickly. Some components may break if overloaded. If the chain is too loose, the chain may fall off the engine sprocket or the rear sprocket. -
Page 78: Checking The Chain, Rear Sprocket, Engine Sprocket, And Chain Guide
11 SERVICE WORK ON THE CHASSIS 11.39 Checking the chain, rear sprocket, engine sprocket, and chain guide Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) Main work – Shift the transmission into neutral. – Check the chain, rear sprocket and engine sprocket for wear. »... - Page 79 SERVICE WORK ON THE CHASSIS 11 – Check the chain sliding guard for wear. » If the lower edge of the chain pins is in line with, or below, the chain sliding guard: – Change the chain sliding guard. – Check that the chain sliding guard is firmly seated.
-
Page 80: Checking The Frame
If the link fork exhibits damage, cracking, or deformation: – Change the link fork. Info Always replace a damaged link fork. Repair of the link fork is not authorized by Husqvarna Motorcycles. F03646-01 11.42 Checking the throttle cable routing Warning Danger of accidents The throttle cable can become kinked, trapped or blocked if it is not routed cor-... -
Page 81: Checking The Rubber Grips
SERVICE WORK ON THE CHASSIS 11 – Remove the right side panel. ( p. 68) – Remove the fuel tank. p. 70) Main work – Check the throttle cable routing. Both throttle cables must be routed to the throttle valve body side by side on the back of the handlebars and above the fuel tank roller. -
Page 82: Programming The Quickshifter
11 SERVICE WORK ON THE CHASSIS 11.44 Programming the quickshifter Info If the shifting performance of the quickshifter starts to decrease, it must be reprogrammed. – Carry out start procedure. ( p. 26) – Press and hold the QS button for at least 10 seconds. -
Page 83: Changing The Hydraulic Clutch Fluid
SERVICE WORK ON THE CHASSIS 11 Info The fluid level rises with increasing wear of the clutch facing discs. Avoid contact between brake fluid and painted parts. Brake fluid corrodes paint. – Move the hydraulic clutch fluid reservoir mounted on the han- dlebar into a horizontal position. - Page 84 11 SERVICE WORK ON THE CHASSIS – Move the hydraulic clutch fluid reservoir mounted on the han- dlebar into a horizontal position. – Remove screws – Take off cover with membrane H04933-10 – Fill bleeding syringe with the appropriate hydraulic fluid. Syringe (50329050000) Brake fluid DOT 4 / DOT 5.1 ( p.
-
Page 85: Brake System 12
Do not make any adjustments while riding. 12.3 Checking the brake discs Warning Danger of accidents Worn-out brake discs reduce the braking effect. – Make sure that worn-out brake discs are replaced immediately. (Your authorized Husqvarna Motor- cycles workshop will be glad to help.) -
Page 86: Checking The Front Brake Fluid Level
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized Husqvarna Motorcycles workshop will be glad to help.) -
Page 87: Adding Front Brake Fluid
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized Husqvarna Motorcycles workshop will be glad to help.) -
Page 88: Checking That The Brake Linings Of The Front Brake Are Secured
Checking that the brake linings of the front brake are secured Warning Danger of accidents Worn-out brake linings reduce the braking effect. – Ensure that worn-out brake linings are replaced immediately. (Your authorized Husqvarna Motorcy- cles workshop will be glad to help.) – Check the brake linings for minimum thickness ≥... -
Page 89: Changing The Brake Linings Of The Front Brake
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized Husqvarna Motorcycles workshop will be glad to help.) - Page 90 12 BRAKE SYSTEM – Remove screws – Press back the brake linings by slightly tilting the brake caliper laterally on the brake disc. Carefully pull the brake caliper up and off the brake disc. – Press the brake piston back into the basic position and ensure that brake fluid does not flow out of the brake fluid reservoir;...
-
Page 91: Checking The Free Travel Of Foot Brake Lever
If there is no free travel on the foot brake lever, pressure builds up in the brake system on the rear brake. – Set the free travel on the foot brake lever in accordance with the specification. – Ensure that the adjustment steps are performed properly. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Disconnect spring –... -
Page 92: Adjusting The Basic Position Of The Foot Brake Lever
If there is no free travel on the foot brake lever, pressure builds up in the brake system on the rear brake. – Set the free travel on the foot brake lever in accordance with the specification. – Ensure that the adjustment steps are performed properly. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Detach spring –... -
Page 93: Adding Rear Brake Fluid
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized Husqvarna Motorcycles workshop will be glad to help.) - Page 94 12 BRAKE SYSTEM Note Environmental hazard Hazardous substances cause environmental damage. – Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable regulations. Info Avoid contact between brake fluid and painted parts. Brake fluid corrodes paint. Preparatory work –...
-
Page 95: Checking That The Brake Linings Of The Rear Brake Are Secured
Checking that the brake linings of the rear brake are secured Warning Danger of accidents Worn-out brake linings reduce the braking effect. – Ensure that worn-out brake linings are replaced immediately. (Your authorized Husqvarna Motorcy- cles workshop will be glad to help.) – Check the brake linings for minimum thickness ≥... - Page 96 12 BRAKE SYSTEM Warning Danger of accidents Oil or grease on the brake discs reduces the braking effect. – Always keep the brake discs free of oil and grease. – Clean the brake discs with brake cleaner when necessary. Note Environmental hazard Hazardous substances cause environmental damage. –...
- Page 97 BRAKE SYSTEM 12 – Check that spring plate in the brake caliper and brake pad sliding plate in the brake caliper bracket are seated correctly. Info The arrow on the spring plate points in the direction of rotation of the brake disc. F03722-10 –...
-
Page 98: 13 Wheels, Tires
13 WHEELS, TIRES 13.1 Removing the front wheel Preparatory work – Raise the motorcycle with a lift stand. ( p. 49) Main work – Manually press the brake caliper toward the brake disc to push back the brake pistons. Info Make sure that you do not press the brake caliper against the spokes when pushing back the brake pis- tons. -
Page 99: Installing The Front Wheel
WHEELS, TIRES 13 13.2 Installing the front wheel Warning Danger of accidents Oil or grease on the brake discs reduces the braking effect. – Always keep the brake discs free of oil and grease. – Clean the brake discs with brake cleaner when necessary. –... -
Page 100: Installing The Rear Wheel
13 WHEELS, TIRES Main work – Manually press the brake caliper toward the brake disc to push back the brake piston. Info Make sure that you do not press the brake caliper against the spokes when pushing back the brake pis- ton. - Page 101 WHEELS, TIRES 13 Main work – Check the wheel bearing for damage and wear. » If the wheel bearing is damaged or worn: – Change the rear wheel bearing. – Clean and grease shaft seal rings and contact surfaces of the spacers. Long-life grease ( p.
-
Page 102: Checking The Tire Condition
Checking the tire condition Info Only mount tires approved and/or recommended by Husqvarna Motorcycles. Other tires could have a negative effect on handling characteristics. The type, condition, and pressure of the tires all have a major impact on the handling characteristic of the motorcycle. -
Page 103: Checking The Spoke Tension
Other spokes will become looser as a result. – Check spoke tension regularly, and in particular on a new vehicle. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) – Strike each spoke briefly using a screwdriver blade. Info The frequency of the sound depends on the spoke length and spoke diameter. -
Page 104: 14 Electrical System
14 ELECTRICAL SYSTEM 14.1 Removing the 12-V battery Caution Danger of burns The voltage regulator gets very hot when the vehicle is operated. – Allow the voltage regulator to cool down before performing any work. Note Environmental hazard 12 V batteries contain environmentally hazardous materials. –... -
Page 105: Installing The 12-V Battery
ELECTRICAL SYSTEM 14 14.2 Installing the 12-V battery Main work – Pull up the battery holding bracket , put the 12-V bat- tery into the battery compartment with the terminals facing upwards and secure with the battery holding bracket Info Ensure that the cable is routed correctly. -
Page 106: Charging The 12-V Battery
14 ELECTRICAL SYSTEM 14.3 Charging the 12-V battery Warning Risk of injury 12 V batteries contain harmful substances. – Keep 12 V batteries out of the reach of children. – Keep sparks and open flames away from 12 V batteries. – Only charge 12 V batteries in well-ventilated rooms. -
Page 107: Changing The Main Fuse
12-V battery with these battery chargers. The charging time may be longer at low temperatures. These battery chargers are only suitable for lithium iron phosphate batteries. Read the accompanying instructions for Husqvarna Motorcycles accessories. Info Never remove cover –... -
Page 108: Changing The Fuse Of The Fuel Pump
14 ELECTRICAL SYSTEM – Remove the fuel tank. p. 70) Main work – Pull starter relay from the holder. F03751-10 – Take off protection caps – Remove faulty main fuse Info A faulty fuse has a burned-out fuse wire A spare fuse is located in the starter relay. -
Page 109: Diagnostics Connector
ELECTRICAL SYSTEM 14 Preparatory work – Remove the seat. ( p. 62) Main work – Take off protection cap – Remove the faulty fuse Info A faulty fuse has a burned-out fuse wire – Insert the new fuse for the fuel pump. Fuse (58011109105) ( p. -
Page 110: 15 Cooling System
15 COOLING SYSTEM 15.1 Cooling system Water pump in the engine circulates the coolant. The pressure resulting from the warming of the cooling system is regulated by a valve in radiator cap . This ensures that operat- ing the vehicle at the specified coolant temperature will not result in a risk of malfunctions. -
Page 111: Checking The Coolant Level
COOLING SYSTEM 15 15.3 Checking the coolant level Warning Danger of scalding During motorcycle operation, the coolant gets hot and is under pressure. – Do not open the radiator, the radiator hoses or other cooling system components if the engine or the cooling system are at operating temperature. -
Page 112: Refilling With Coolant
15 COOLING SYSTEM Warning Danger of poisoning Coolant is harmful to health. – Keep coolant out of the reach of children. – Do not allow coolant to come into contact with the skin, the eyes and clothing. – Consult a doctor immediately if coolant is swallowed. –... -
Page 113: Changing The Coolant
COOLING SYSTEM 15 15.6 Changing the coolant Warning Danger of scalding During motorcycle operation, the coolant gets hot and is under pressure. – Do not open the radiator, the radiator hoses or other cooling system components if the engine or the cooling system are at operating temperature. –... -
Page 114: 16 Tuning The Engine
16 TUNING THE ENGINE 16.1 Checking the play in the throttle cable – Check the throttle grip for smooth operation. – Move the handlebar to the straight-ahead position. Turn the throttle grip back and forth slightly and determine the play in throttle cable Play in throttle cable 3 …... -
Page 115: Adjusting The Characteristic Map Of The Throttle Response
TUNING THE ENGINE 16 Main work – Move the handlebar to the straight-ahead position. – Push back sleeve – Loosen nut – Turn adjusting screw in as far as possible. – Loosen nut – Push cold start button all the way to the stop. –... - Page 116 16 TUNING THE ENGINE – Remove guide plate from handle tube – Position the required guide plate on the grip tube. Guideline The label OUTSIDE must be visible. Marking must be positioned at marking Black guide plate (A46002014000) Alternative 1 Grey guide plate (A48002014000) Info The gray guide plate opens the throttle valve more...
-
Page 117: Changing The Mapping
Use effective exhaust extraction when starting or running the engine in an enclosed space. Warning Danger of accidents The engine may go out spontaneously if the idle speed is set too low. – Set the idle speed to the specified value. (Your authorized Husqvarna Motorcycles workshop will be glad to help.) -
Page 118: Programming The Throttle Valve Position
16 TUNING THE ENGINE – Run the engine until warm. The cold start button is deactivated – The cold start but- ton is in its basic position. ( p. 18) – Adjust the idle speed by turning idle speed adjusting screw using a suitable tachometer. -
Page 119: Checking The Basic Position Of The Shift Lever
TUNING THE ENGINE 16 16.7 Checking the basic position of the shift lever Info When driving, the shift lever must not touch the rider's boot when in the basic position. If the shift lever is permanently touching the boot, the transmission will be subject to excessive load; this can cause a malfunction of the quickshifter. -
Page 120: 17 Service Work On The Engine
17 SERVICE WORK ON THE ENGINE 17.1 Changing the fuel screen Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –... -
Page 121: Checking The Engine Oil Level
SERVICE WORK ON THE ENGINE 17 Danger Danger of poisoning Exhaust gases are toxic and inhaling them may result in unconsciousness and death. – Always make sure there is sufficient ventilation when running the engine. – Use effective exhaust extraction when starting or running the engine in an enclosed space. -
Page 122: Changing The Engine Oil And Oil Filter, Cleaning The Oil Screen
17 SERVICE WORK ON THE ENGINE 17.3 Changing the engine oil and oil filter, cleaning the oil screen Warning Danger of scalding Engine and gear oil get hot when the motorcycle is operated. – Wear suitable protective clothing and safety gloves. –... - Page 123 SERVICE WORK ON THE ENGINE 17 – Mount and tighten screw plug with the O-ring. Guideline Screw plug, oil M20x1.5 15 Nm (11.1 lbf ft) screen – Mount and tighten oil drain plug with the magnet and a new seal ring. Guideline Oil drain plug with M12x1.5...
-
Page 124: Adding Engine Oil
141) Info For optimal performance of the engine oil, do not mix different types of engine oil. 401955-10 Husqvarna Motorcycles recommends changing the engine oil. – Mount and tighten the filler plug together with the O-ring. Danger Danger of poisoning Exhaust gases are toxic and inhaling them may result in unconsciousness and death. -
Page 125: Cleaning, Care 18
CLEANING, CARE 18 18.1 Cleaning the motorcycle Note Material damage Components become damaged or destroyed if a pressure cleaner is used incorrectly. The high pressure forces water into the electrical components, connectors, throttle cables, and bearings, etc. Pressure which is too high causes malfunctions and destroys components. –... - Page 126 18 CLEANING, CARE – After the motorcycle has cooled down, lubricate all moving parts and pivot points. – Clean the chain. ( p. 73) – Treat bare metal (except for brake discs and the exhaust sys- tem) with a corrosion inhibitor. Preserving materials for paints, metal and rubber p.
-
Page 127: Storage 19
– Store the vehicle in a dry location that is not subject to large fluctuations in temperature. Info Husqvarna Motorcycles recommends jacking up the motorcycle. – Raise the motorcycle with a lift stand. ( p. 49) –... -
Page 128: Putting Into Operation After Storage
19 STORAGE Info Do not use non-porous materials since they prevent humidity from escaping, thus causing corrosion. Avoid running the engine for a short time only. Since the engine cannot warm up properly, the water vapor produced during combustion condenses and causes valves and the exhaust system to rust. -
Page 129: Troubleshooting 20
– Check the electrical system. – Malfunction in the electronic Read out the fault memory using the fuel injection Husqvarna Motorcycles diagnostics tool. – Engine does not speed up Malfunction in the electronic Read out the fault memory using the... - Page 130 – Read out the fault memory using the Husqvarna Motorcycles diagnostics tool. – High oil consumption Engine vent hose bent Route the vent hose without bends or change it if necessary.
-
Page 131: Blink Code 21
BLINK CODE 21 Combination switch, left side – buttons pressed longer than 20 seconds Error level condition Blink code for malfunc- tion indicator lamp Malfunction indicator lamp flashes continuously THREF – internal malfunction of the engine control unit Error level condition Blink code for malfunc- tion indicator lamp 02 Malfunction indicator lamp flashes 2x short... - Page 132 21 BLINK CODE Blink code for malfunc- tion indicator lamp 33 Malfunction indicator lamp flashes 3x long, 3x short Injection valve cylinder 1 – circuit fault Error level condition Blink code for malfunc- tion indicator lamp 37 Malfunction indicator lamp flashes 3x long, 7x short Ignition coil –...
-
Page 133: Technical Specifications 22
TECHNICAL SPECIFICATIONS 22 22.1 Engine Design 1-cylinder 4-stroke engine, water-cooled Displacement 249.91 cm³ (15.2505 cu in) Stroke 48.5 mm (1.909 in) Bore 81 mm (3.19 in) Compression ratio 14.5:1 Idle speed 2,250 … 2,350 rpm Control DOHC, four valves controlled via cam lever, drive via timing chain Valve diameter, intake 32.5 mm (1.28 in) -
Page 134: Engine Tightening Torques
22 TECHNICAL SPECIFICATIONS 22.2 Engine tightening torques Hose clip, intake flange 3 Nm (2.2 lbf ft) Nozzle, crank chamber ventilation 2 Nm (1.5 lbf ft) ® Loctite 243™ Oil nozzle for clutch lubrication 2 Nm (1.5 lbf ft) ® Loctite 243™... - Page 135 TECHNICAL SPECIFICATIONS 22 Screw, outer clutch cover M6x25 10 Nm (7.4 lbf ft) Screw, outer clutch cover M6x45 10 Nm (7.4 lbf ft) Screw, shift drum locating 10 Nm (7.4 lbf ft) ® Loctite 243™ Screw, shift lever 14 Nm (10.3 lbf ft) Loctite ®...
-
Page 136: Capacities
22 TECHNICAL SPECIFICATIONS Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) Screw plug, oil pressure control M12x1.5 20 Nm (14.8 lbf ft) valve Oil drain plug M14x1.5 15 Nm (11.1 lbf ft) Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft) Nut, primary gear wheel M18LHx1.5... -
Page 137: Electrical System
The tires specified represent one of the possible series production tires. For alternative manufacturers, if any, contact an authorized dealer or qualified tire dealership. If local road approval regulations apply, these and the respective technical specifications must be observed. Additional information is available in the Service section under: www.husqvarna‑motorcycles.com 22.7 Fork 22.7.1... -
Page 138: All Us Models
22 TECHNICAL SPECIFICATIONS + 10 + 0.34 Oil capacity external mechanism ml (7.78 fl. oz.) Fork oil (SAE 4) (48601166S1) − 50 − 1.69 right p. 142) + 10 + 0.34 Oil capacity external mechanism ml (7.78 fl. oz.) Fork oil (SAE 4) (48601166S1) −... -
Page 139: All Us Models
TECHNICAL SPECIFICATIONS 22 Sport 13 clicks Spring preload 8 mm (0.31 in) Spring rate Weight of rider: 65 … 75 kg (143 … 165 lb.) 39 N/mm (223 lb/in) Weight of rider: 75 … 85 kg (165 … 187 lb.) 42 N/mm (240 lb/in) Weight of rider: 85 …... -
Page 140: Chassis Tightening Torques
22 TECHNICAL SPECIFICATIONS 22.9 Chassis tightening torques ® Fitting, start button EJOT PT K50x18 2 Nm (1.5 lbf ft) ® Fitting, stop button EJOT PT K50x18 2 Nm (1.5 lbf ft) ® Screw, air filter box cover EJOT PT K60x20-Z 5 Nm (3.7 lbf ft) ®... - Page 141 TECHNICAL SPECIFICATIONS 22 Screw, ground wire on frame 10 Nm (7.4 lbf ft) Screw, hand lever 5 Nm (3.7 lbf ft) Screw, push rod ball joint on the 10 Nm (7.4 lbf ft) rear brake cylinder ® Loctite 243™ Screw, rear brake disc 14 Nm (10.3 lbf ft) Loctite ®...
- Page 142 22 TECHNICAL SPECIFICATIONS Nut, frame on linkage lever M16x1.5 80 Nm (59 lbf ft) Nut, linkage lever on angle lever M16x1.5 80 Nm (59 lbf ft) Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) Nut, wheel spindle, rear...
-
Page 143: Substances 23
SUBSTANCES 23 Brake fluid DOT 4 / DOT 5.1 Standard/classification – Guideline – Use only brake fluid that complies with the specified standard (see specifications on the container) and that exhibits the corresponding properties. Recommended supplier Castrol – REACT PERFORMANCE DOT 4 ®... - Page 144 23 SUBSTANCES Fork oil (SAE 4) (48601166S1) Standard/classification – SAE ( p. 145) (SAE 4) Guideline – Use only oils that comply with the specified standards (see specifications on the container) and that exhibit the corresponding properties. Shock absorber fluid (SAE 2.5) (50180751S1) Standard/classification –...
-
Page 145: Auxiliary Substances 24
AUXILIARY SUBSTANCES 24 Air filter cleaner Recommended supplier ® MOTOREX – Racing Bio Dirt Remover Chain cleaner Recommended supplier ® MOTOREX – Chain Clean Fuel additive Recommended supplier ® MOTOREX – Fuel Stabilizer High viscosity grease Recommended supplier ® – LGHB 2 Long-life grease Recommended supplier... - Page 146 24 AUXILIARY SUBSTANCES Silicone spray Recommended supplier ® MOTOREX – Silicone Spray Special cleaner for glossy and matte paint finishes, metal and plastic surfaces Recommended supplier ® MOTOREX – Quick Cleaner Special grease (00062010053) Recommended supplier ® Klüber Lubrication – Klüberfood NH1 34‑401 Universal oil spray Recommended supplier...
-
Page 147: Standards 25
STANDARDS 25 JASO T903 MA2 Different technical development directions required a separate specification for motorcycles – the JASO T903 MA2 standard. Earlier, engine oils from the automobile industry were used for motorcycles because there was no separate motorcycle specification. Whereas long service intervals are demanded for automobile engines, the focus for motorcycle engines is on high performance at high engine speeds. -
Page 148: 26 Index Of Special Terms
26 INDEX OF SPECIAL TERMS Launch control Vehicles electronics functions for achieving the best possible acceleration from a standing position On-board diagnosis Vehicle system, which monitors the specified param- eters of the vehicle electronics Quickshifter Function of the engine electronics for shifting up without clutch actuation Traction Control Auxiliary function of the motor control that reduces... -
Page 149: List Of Abbreviations 27
LIST OF ABBREVIATIONS 27 Art. no. Article number circa compare e.g. for example etc. et cetera i.a. inter alia number poss. possibly... -
Page 150: 28 List Of Symbols
28 LIST OF SYMBOLS 28.1 Yellow and orange symbols Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are also represented by yellow or orange symbols. Malfunction indicator lamp lights up/flashes orange – The OBD has detected a malfunction in the vehicle electronics. -
Page 151: Index
INDEX INDEX engine oil ..... 121, 134 Chain 12-V battery checking ......76 installing . - Page 152 INDEX Engine sprocket High-speed compression damping checking ......76 shock absorber, adjusting ....38 Environment .
- Page 153 INDEX Preparing for use spring preload, adjusting ....41 advice on preparing for first use ..21 static sag, checking ....40 checks and maintenance measures when Shock absorber article number .
- Page 154 INDEX Vehicle identification number ... . . 13 View of vehicle front left ......11 rear right .
- Page 155 *3402631en* 3402631en 27.09.2023 Husqvarna Motorcycles GmbH Stallhofnerstraße 3 5230 Mattighofen Austria Photo: Mitterbauer/KISKA, www.husqvarna‑motorcycles.com Husqvarna Motorcycles GmbH...
