English – 2
Privacy notice
When you connect the eBike to the Bosch DiagnosticTool 3
or replace eBike components, technical information about
your eBike (e.g. manufacturer, model, bike ID, configuration
data) and the eBike usage (e.g. total riding time, energy con-
sumption, temperature) is transferred to Bosch eBike Sys-
tems (Robert Bosch GmbH) for the purposes of processing
your inquiry, servicing and product improvement. You can
find further information about data processing at
www.bosch-ebike.com/privacy-full.
Product Description and
Specifications
Intended Use
The System Controller and Mini Remote/Mini Remote
Dropbar operating units are designed for controlling an
eBike/on-board computer from the system generation the
smart system. You can also use them to change the assist-
ance level in the eBike Flow app.
So as to be able to use the operating unit fully, a compatible
smartphone with the eBike Flow app is required.
Using the eBike Flow app, a Bluetooth® connection can be
established between the smartphone and the eBike,
between the smartphone and System Controller, and
between System Controller and Mini Remote/Mini Re-
mote Dropbar.
Depending on the smartphone's operating sys-
tem, the eBike Flow app can be downloaded
free of charge from the Apple App Store and
the Google Play store.
Technical Data
Operating unit
Product code
Operating temperature
Storage temperature
Protection rating
Dimensions
Weight
Bluetooth® Low Energy 5.0
– Frequency
– Transmission power
Operating unit
Product code
Operating temperature
Storage temperature
Battery
Protection rating
Dimensions
0 275 007 3RC | (01.06.2023)
Use your smartphone to scan the code in order to download
the eBike Flow app.
Product Features
All illustrations of bike parts except for the drive unit, on-
board computer (including operating unit), speed sensor
and the corresponding holders are a schematic representa-
tion and may differ on your eBike.
The numbering of the components shown refers to the illus-
trations on the graphics pages at the beginning of the
manual.
(1) Operating unit Mini Remote/Mini Remote Dropbar
(2) Operating unit System Controller
(3) LED indicator light
(4) Button for increasing assistance level +/
bicycle lights
(5) Select button
(6) Button for decreasing assistance level –/
walk assistance
(7) Fastening screw for holder
(8) Holder
(9) Rubber insert/battery holder
(10) Assistance level LED
(11) ABS LED (optional)/ambient light sensor
(12) On/off button
(13) Charge indicator of the eBike battery
(14) Mode button
°C
°C
mm
g
MHz
mW
Mini Remote
BRC3300
°C –5 to +40
°C +10 to +40
1× CR1620
mm 40 × 39 × 22
System Controller
BRC3100
−5 to +40
+10 to +40
88 × 28 × 27
2400–2480
Mini Remote Dropbar
BRC3310
–5 to +40
+10 to +40
1× CR1620
IP55
50 × 46 × 22
Bosch eBike Systems
IP55
35
≤ 1
IP55
