In the interests of user-safety (Required by safety regulation in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
IMPORTANT SERVICE NOTES ............ . .........i
[1]
SPECIFICATIONS ................................. . .... 1-1
[1]
PARTS NAMES...................................... . .... 2-1
[1]
REMOVING OF MAJOR PARTS ........... . .... 3-1
[2]
AGRAM.................................................. . .... 3-3
[3]
IMPORTANT SERVICE NOTICE........... . .... 3-3
[4]
UPGRADING ......................................... . .... 3-4
[1]
TROUBLESHOOTING TABLE............... . .... 4-1
[1]
MAIN BLOCK DIAGRAM ....................... . .... 5-1
[2]
BLOCK DIAGRAM ................................. . .... 5-2
BLIES
[1]
MAIN PWB............................................. . .... 6-1
[2]
ANALOG PWB....................................... . .... 6-5
[3]
POWER PWB ........................................ . .... 6-7
[4]
OPERATION-L PWB.............................. . .... 6-9
[5]
LCD PWB............................................... . .. 6-10
[1]
GRAM .................................................... . .... 7-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
SERVICE MANUAL
BLU-RAY DISC PLAYER
MODEL
CONTENTS
[2]
GRAM......................................................... 7-2
[3]
GRAM......................................................... 7-3
[4]
GRAM......................................................... 7-4
[5]
GRAM......................................................... 7-5
[6]
GRAM......................................................... 7-6
[7]
GRAM......................................................... 7-7
[8]
GRAM......................................................... 7-8
[9]
GRAM......................................................... 7-9
GRAM....................................................... 7-10
GRAM....................................................... 7-11
GRAM....................................................... 7-12
GRAM....................................................... 7-13
GRAM....................................................... 7-14
DIAGRAM................................................. 7-16
No. S29W8BDHP16U/
BD-HP16U
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
BD-HP16U

Advertisement

Table of Contents
loading

Summary of Contents for Sharp BD-HP16U

  • Page 1: Table Of Contents

    TopPage BD-HP16U SERVICE MANUAL No. S29W8BDHP16U/ BLU-RAY DISC PLAYER BD-HP16U MODEL In the interests of user-safety (Required by safety regulation in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
  • Page 2: Safety Precaution

    BD-HP16U BDHP16U Service Manual   SAFETY PRECAUTION IMPORTANT SERVICE NOTES IMPORTANT SERVICE NOTES This Player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the rear cover. This product contains a low power laser device. To ensure continued safety do not remove any cover or attempt to gain access to the inside of the product.
  • Page 3 BD-HP16U IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.
  • Page 4: Precautions For Using Lead-Free Solder

    BD-HP16U Precautions for using lead-free solder Employing lead-free solder • “All PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
  • Page 5: Chapter 1. Specifications Specifications

    BD-HP16U BDHP16U Service Manual   CHAPTER 1. SPECIFICATIONS [1] SPECIFICATIONS General Power supply AC 120V, 60Hz Power consumption (Normal) 19 W Power consumption (Standby) 0.5 W (When "Quick Start" is set to "No") Dimensions Approx. 17 x 10 inch (Wx H x D) Approx.
  • Page 6: Chapter 2. Operation Manual Parts Names

    BD-HP16U BDHP16U Service Manual   CHAPTER 2. OPERATION MANUAL [1] PARTS NAMES Major Components Main Unit (Front) AQUOS PURE MODE indicator OPEN/CLOSE POWER Flap door PLAY Remote control sensor Disc tray STOP Front panel display ON/STANDBY indicator PAUSE BD/DVD/CD mode indicator...
  • Page 7 BD-HP16U Remote Control Unit POWER OPEN/CLOSE AUDIO, SUBTITLE Number buttons REPEAT SKIP/ SKIP/ PAUSE PLAY TOP MENU/TITLE LIST Cursor buttons ( / ), ENTER EXIT A (Red), B (Green), C (Blue), D (Yellow) (Lock) (See below.) COMPONENT RESET DISPLAY TV CONTROL buttons...
  • Page 8: Chapter 3. Removing Of Major Parts

    BD-HP16U BDHP16U Service Manual   CHAPTER 3. REMOVING OF MAJOR PARTS [1] REMOVING OF MAJOR PARTS 3. Removing the BD drive 1. Disconnect the BD FFC between the BD drive and Main PWB . 1. Removing the tray cover 2. Remove three screws...
  • Page 9 BD-HP16U 5. Removing the fan and the rear terminal board 6. Removing each PWB 1. Disconnect the board to board connector from the Main PWB and 1. Remove two screws Analog PWB, then remove two screws 2. Remove six screws Disconnect the board to board connector between the Main PWB 3.
  • Page 10: Extension Cable Connection Diagram

    BD-HP16U [2] EXTENSION CABLE CONNECTION DIAGRAM Parts Code Price Code Name/Description QCNW-E227WJPZ CN901 <=> SC9001, SC5601 <=> CN2301 [3] IMPORTANT SERVICE NOTICE 1. To replace the Main CBA, perform the items 9 - 12 of [4] Upgrading and confirm the version: it is necessary to upgrade with a disc to the latest ver- sion if the CBA version is old.
  • Page 11: Upgrading

    BD-HP16U [4] UPGRADING Consult with your Services Company as we cannot provide the upgrading software. 1. Press [Power] button to turn the switch on, then wait till the BD_LED changes from blinking to lit. 2. Press [Tray Open/Close] button to open the Tray, put the upgrade disc on the tray and close the tray.
  • Page 12: Chapter 4. Troubleshooting Table

    BD-HP16U BDHP16U Service Manual   CHAPTER 4. TROUBLESHOOTING TABLE [1] TROUBLESHOOTING TABLE 1. MAIN UNIT FLOW CHART No.1 The main PWB circuit doesn't function when the power is turned ON. The power does not become ON. Is the level of pin (6) of SC9001 at Low? The power becomes OFF.
  • Page 13 BD-HP16U FLOW CHART No.3 No video signal output from the main PWB. Check SC5601. Is video signal input into each terminal of SC5601? 1) S-VIDEO and COMPOSIT OUTPUT TERMINALS 2 pins (SUB_YOUT), 4 pins (SUB_COUT) 2) CONPONENT-VIDEO TERMINAL 6 pins (MAIN_YOUT), 8 pins (MAIN_PBOUT),...
  • Page 14 BD-HP16U FLOW CHART No.5 No video and audio signal output from HDMI terminal. Defective TV set or cable. Or, check the contact of soldered Replace the TV set (cable) and reconfirm. connector of SC4201. Still no video and audio output? Are output voltages of IC4204 as 5V, IC4202 as 3.3V OK?
  • Page 15 BD-HP16U 2. ANALOG UNIT FLOW CHART No.1 No picture appears with the component or composite signal. Check the connected cable and its connection tightness. Is the video signal outputted from the component or Check also the input of connected TV set.
  • Page 16 BD-HP16U FLOW CHART No.2 The reproduced audio signal does not come from each audio output terminal. Check the connected cable and its connection tightness. Is the audio signal outputted from J2401? Check also the input of connected TV set or amplifier.
  • Page 17 BD-HP16U FLOW CHART No.2 The LCD display fails to light up. Replace LCD1101. Is the LCD unit cracked or otherwise damaged? Replace LCD1101. Is the display-designated SEG or COM signal inputted to LCD1101? Are the signals outputted from pins (1 thru 17, 33, 34 and 35) Check the pattern between IC1101 and LCD1101.
  • Page 18 BD-HP16U FLOW CHART No.4 The LED power indicator fails to light up. Is the power as specified? POWER FLOW CHART No.1 or POWER FLOW CHART No.3 Check each transistor, LED and the current-limiting resistor. Is the "H" potential applied at the base of Q1202 or Q1203? Is there the "H"...
  • Page 19 BD-HP16U FLOW CHART No.6 A button fails to work. Check the relevant switch. Replace it as required. Is the button switch contact and tightness as specified? Check the line between each button and IC2503. Or check the Is the control voltage properly applied at pin (72) (KEY_EJCT) pull-up resistor at pin (72) of IC2503.
  • Page 20 BD-HP16U FLOW CHART No.3 The power does not come ON from power OFF status. Is AT_5V line working normally? Check the circuit of AT_5V. When the Power key (S1201) is pressed, is pin (73) of IC2503 Check the line between S1201 and IC2503.
  • Page 21: Chapter 5. Block Diagram

    BD-HP16U Service Manual BDHP16U   CHAPTER 5. BLOCK DIAGRAM [1] MAIN BLOCK DIAGRAM 5 – 1...
  • Page 22: Analog/Power/Lcd/Operation Block Diagram

    BD-HP16U [2] ANALOG/POWER/LCD/OPERATION BLOCK DIAGRAM 5 – 2...
  • Page 23: Chapter 6. Printed Wiring Board Assem

    BD-HP16U Service Manual BDHP16U   CHAPTER 6. PRINTED WIRING BOARD ASSEMBLIES [1] MAIN PWB MAIN UNIT Side-A 6 – 1...
  • Page 24 BD-HP16U MAIN UNIT Chip Parts Side-A 6 – 2...
  • Page 25 BD-HP16U MAIN UNIT Side-B 6 – 3...
  • Page 26 BD-HP16U MAIN UNIT Chip Parts Side-B 6 – 4...
  • Page 27: Analog Pwb

    BD-HP16U [2] ANALOG PWB ANALOG UNIT Side-A RADIAL AXIAL CHECKER AUTO RJ2302 CN2401 J2402 KF054TE RJ2306 R2372 R2371 J2401 FF054WJ C2322 L2301 LUG2301 RJ2304 UL ID*** 6 – 5...
  • Page 28 BD-HP16U ANALOG UNIT Side-B CN2401 J2401 RJ2302 FDC6 J2402 RJ2306 R2372 R2371 C2322 IC2301 LUG2301 L2301 RJ2304 Sn-Ag-Cu 6 – 6...
  • Page 29: Power Pwb

    BD-HP16U [3] POWER PWB POWER UNIT Side-A T3.15A L250V For other Country 3.15A 250V For US and Canada (CRI.PART) 3.15A 250V K901 IC903 D921 LUG921 LUG922 F901 (CRI.PART) FH901 D929 D925 FH902 D952 IC904 (CRI.PART) D922 RDA921 VA902 D924 (CRI.PART) (CRI.PART)
  • Page 30 BD-HP16U POWER UNIT Side-B CN902 CN901 R904 R963 D957 D956 Q953 FB901 C964 D955 R912 FB921 RJ903 R921 R902 C961 D923 C905 C923 C955 C904 IC902 RDA952 C930 Q921 IC904 C902 D924 VA902 D922 C912 D929 D925 D952 FH902 FH901...
  • Page 31: Operation-L Pwb

    BD-HP16U [4] OPERATION-L PWB OPERATION-L UNIT Side-A KF056TE FF056WJ P-ON D1205 C1201 P-ON D1202 LUG1201 D1204 POWER STBY PLAY PAUSE STOP S1208 S1206 S1205 S1207 STBY D1201 POWER PLAY S1201 STOP S1203 PAUSE S1202 D1203 UL ID*** HDMI S1204 OPERATION-L UNIT Side-B...
  • Page 32: Lcd Pwb

    BD-HP16U [5] LCD PWB LCD UNIT Side-A LCD1101 R1116 R1117 R1118 SC1101 Q1104 D1105 Sn-Ag-Cu EJECT C1101 RMC1101 D1110 D1112 D1113 D1114 R1150 D1111 D1109 S1101 FF055WJ KF055TE LCD UNIT Side-B SC1101 R1147 R1146 Sn-Ag-Cu LCD1101 IC1101 R1136 R1132 R1135...
  • Page 33: Chapter 7. Schematic Diagrams Main (1) Circuit Schematic Dia- Gram

    BD-HP16U Service Manual BDHP16U   CHAPTER 7. SCHEMATIC DIAGRAMS [1] MAIN (1) CIRCUIT SCHEMATIC DIAGRAM 7 – 1...
  • Page 34: Main (2) Circuit Schematic Diagram

    BD-HP16U [2] MAIN (2) CIRCUIT SCHEMATIC DIAGRAM 7 – 2...
  • Page 35: Main (3) Circuit Schematic Diagram

    BD-HP16U [3] MAIN (3) CIRCUIT SCHEMATIC DIAGRAM 7 – 3...
  • Page 36: Main (4) Circuit Schematic Diagram

    BD-HP16U [4] MAIN (4) CIRCUIT SCHEMATIC DIAGRAM 7 – 4...
  • Page 37: Main (5) Circuit Schematic Diagram

    BD-HP16U [5] MAIN (5) CIRCUIT SCHEMATIC DIAGRAM U N M O U N T I N G U N M O U N T I N G 7 – 5...
  • Page 38: Main (6) Circuit Schematic Diagram

    BD-HP16U [6] MAIN (6) CIRCUIT SCHEMATIC DIAGRAM 7 – 6...
  • Page 39: Main (7) Circuit Schematic Diagram

    BD-HP16U [7] MAIN (7) CIRCUIT SCHEMATIC DIAGRAM 7 – 7...
  • Page 40: Main (8) Circuit Schematic Diagram

    BD-HP16U [8] MAIN (8) CIRCUIT SCHEMATIC DIAGRAM 7 – 8...
  • Page 41: Main (9) Circuit Schematic Diagram

    BD-HP16U [9] MAIN (9) CIRCUIT SCHEMATIC DIAGRAM 7 – 9...
  • Page 42: Main (10) Circuit Schematic Diagram

    BD-HP16U [10] MAIN (10) CIRCUIT SCHEMATIC DIAGRAM 7 – 10...
  • Page 43: Main (11) Circuit Schematic Diagram

    BD-HP16U [11] MAIN (11) CIRCUIT SCHEMATIC DIAGRAM 7 – 11...
  • Page 44: Main (12) Circuit Schematic Diagram

    BD-HP16U [12] MAIN (12) CIRCUIT SCHEMATIC DIAGRAM 7 – 12...
  • Page 45: Power Circuit Schematic Diagram

    BD-HP16U [13] POWER CIRCUIT SCHEMATIC DIAGRAM AND SHADED COMPONENTS=SAFETY RELATED PARTS 7 – 13...
  • Page 46: Analog Circuit Schematic Diagram

    BD-HP16U [14] ANALOG CIRCUIT SCHEMATIC DIAGRAM C O A X I A L C O N N E C T O R O P T I C A L C O N N E C T O R 7 – 14...
  • Page 47: Lcd Circuit Schematic Diagram

    BD-HP16U [15] LCD CIRCUIT SCHEMATIC DIAGRAM 7 – 15...
  • Page 48: Operation-L Circuit Schematic Diagram

    BD-HP16U [16] OPERATION-L CIRCUIT SCHEMATIC DIAGRAM 7 – 16...
  • Page 49: Parts Guide

    BD-HP16U PartsGuide PARTS GUIDE No. S29W8BDHP16U/ BLU-RAY DISC PLAYER BD-HP16U MODEL CONTENTS PRINTED WIRING BOARD CABINET PARTS ASSEMBLIES FRONT PANEL PARTS (Main Unit) SUPPLIED ACCESSORIES DUNTKF053TEV1 (POWER UNIT) [10] PACKING PARTS (NOT DUNTKF054TEV1 (ANALOG UNIT) REPLACEMENT ITEM) DUNTKF055TE6A (LCD UNIT)
  • Page 50 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES DUNTKF053TEV1 POWER Unit DUNTKF054TEV1 ANALOG Unit DUNTKF056TEV1 OPE-L Unit DUNTKF055TE6A LCD Unit DMECDA013TEV6 BD-RH3 Drive+Main PWB Unit The BD drive unit and the main PWB unit are configured in pairs. Replace them at once as required.
  • Page 51 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) C4210 VCKYCY1CB104KY 0.1 16V Ceramic C4801 RC-KZA195WJZZY CAPACITOR C4802 VCKYCY1CB104KY 0.1 16V Ceramic C4803 VCKYCY1HB103KY 0.01 50V Ceramic C4811 VCKYCY1AB105KY 1 10V Ceramic C4812 VCKYCY1HB104KY 0.1 50V Ceramic...
  • Page 52 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) C7254 VCKYCZ1AB104KY 0.1 10V Ceramic C7255 VCKYCY1EF104ZY 0.1 25V Ceramic C7256 VCKYCY1EB103KY 0.01 25V Ceramic C7257 VCKYCY1HB392KY 3900p 50V Ceramic C7258 RC-KZA195WJZZY CAPACITOR C7261 VCKYCZ1AB104KY 0.1 10V Ceramic...
  • Page 53 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) C7343 VCKYCZ1EB103KY 0.01 25V Ceramic C7344 VCCCCY1HH4R0CY 40p 50V Ceramic C7345 VCCCCY1HH4R0CY 40p 50V Ceramic C7819 VCKYCY1CB104KY 0.1 16V Ceramic C7820 VCKYCY1CB104KY 0.1 16V Ceramic C7821 VCKYCY1CB104KY 0.1 16V Ceramic...
  • Page 54 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) C9001 RC-KZA510WJPZY CAPACITOR C9003 VCKYCY1HB102KY 1000p 50V Ceramic C9004 RC-KZA214WJZZY CAPACITOR C9005 RC-KZA214WJZZY CAPACITOR C9007 VCKYCY1HB222KY 2200p 50V Ceramic C9008 VCKYCY1HB561KY 560p 50V Ceramic C9009 RC-KZA510WJPZY CAPACITOR C9011...
  • Page 55 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) FB7001 RBLN-0252TAZZY BALUN FB7201 RBLN-A021WJZZY BALUN FB7202 RBLN-A018WJZZY BALUN FB7203 RBLN-A021WJZZY BALUN FB7204 RBLN-A018WJZZY BALUN FB7205 RBLN-A021WJZZY BALUN FB7206 RBLN-A018WJZZY BALUN FB7207 RBLN-A021WJZZY BALUN FB7208 RBLN-A021WJZZY BALUN FB7209...
  • Page 56 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) L9002 RCILCA029WJZZY COIL L9003 RCILPA787WJQZY COIL L9004 RCILPA886WJZZY COIL L9006 RCILPA886WJZZY COIL LUG9001 QLUGHA006WJZZY LUG9002 QLUGHA006WJZZY Q2501 VSRT1N241C/-1Y RT1N241C-T112-1 Q2502 VS2SC3928AR-1Y 2SC3928A-T112-1R Q2503 VSRT1N241C/-1Y RT1N241C-T112-1 Q2504 VSRT1N241C/-1Y RT1N241C-T112-1...
  • Page 57 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R2588 VRS-CY1JF104JY 100k 1/16W Metal Oxide R2590 VRS-CY1JF104JY 100k 1/16W Metal Oxide R2591 VRS-CY1JF103JY 10k 1/16W Metal Oxide R2592 VRS-CY1JF103JY 10k 1/16W Metal Oxide R2593 VRS-CY1JF103JY 10k 1/16W Metal Oxide...
  • Page 58 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R3046 VRS-CY1JF152FY 1.5k 1/16W Metal Oxide R3047 VRS-CY1JF681FY 680 1/16W Metal Oxide R3048 VRS-CY1JF103JY 10k 1/16W Metal Oxide R3067 VRS-CY1JF103JY 10k 1/16W Metal Oxide R4002 VRS-CY1JF103JY 10k 1/16W Metal Oxide...
  • Page 59 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R5723 VRS-CY1JF473JY 47k 1/16W Metal Oxide R5724 VRS-CY1JF473JY 47k 1/16W Metal Oxide R5725 VRS-CY1JF473JY 47k 1/16W Metal Oxide R7001 VRS-CY1JF103JY 10k 1/16W Metal Oxide R7003 VRS-CY1JF000JY 0 1/16W Metal Oxide...
  • Page 60 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R7285 VRK-SC1FF270JY 27 1/32W Metal Composition R7287 VRS-CY1JF102FY 1k 1/16W Metal Oxide R7288 VRS-CY1JF000JY 0 1/16W Metal Oxide R7290 VRS-CY1JF622JY 6.2k 1/16W Metal Oxide R7291 VRS-CY1JF102FY 1k 1/16W Metal Oxide...
  • Page 61 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R7809 VRS-CH1JF220JY 22 1/16W Metal Oxide R7810 VRS-CH1JF220JY 22 1/16W Metal Oxide R7811 VRS-CH1JF220JY 22 1/16W Metal Oxide R7812 VRS-CY1JF220JY 22 1/16W Metal Oxide R7813 VRS-CY1JF220JY 22 1/16W Metal Oxide...
  • Page 62 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] (Main Unit) R9022 VRS-CY1JF123FY 12k 1/16W Metal Oxide R9023 VRS-CY1JF103FY 10k 1/16W Metal Oxide R9024 VRS-CY1JF332JY 3.3k 1/16W Metal Oxide R9025 VRS-CY1JF101JY 100 1/16W Metal Oxide R9026 VRS-CY1JF103FY 10k 1/16W Metal Oxide...
  • Page 63 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [3] DUNTKF053TEV1 (POWER UNIT) D903 RH-EX0649GEZZY MTZJT-7216B D904 RH-EX0627GEZZY MTZJT-728.2B D921 RH-EX0633GEZZY MTZJT-7210B D922 VHDHSS4148+-1Y HSS4148TA-E D923 RH-DX0321CEZZY EG01CV1 D924 VHDHSS4148+-1Y HSS4148TA-E D925 VHDHSS4148+-1Y HSS4148TA-E D928 VHD10ERB40+-1Y 10ERB40-TA2B5 D929 RH-EX0630GEZZY MTZJT-729.1B...
  • Page 64 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [4] DUNTKF054TEV1 (ANALOG UNIT) C2159 RC-EZB596WJZZ CAPACITOR C2170 RC-EZB596WJZZ CAPACITOR C2177 RC-QZA222TAYJ+ CAPACITOR C2178 RC-QZA222TAYJ+ CAPACITOR C2201 VCEA9M0JW107M+ 100 6.3V Electrolytic C2202 VCKYCY1CB104KY 0.1 16V Ceramic C2301 VCKYCY1HB103KY 0.01 50V Ceramic...
  • Page 65 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [5] DUNTKF055TE6A (LCD UNIT) RMC1101 RRMCUA069WJQZ REMOTE RECEIVER S1101 QSW-K0003AJZZ+ SWITCH SC1101 QSOCN0611FJQ1 SOCKET LHLDZB326WJZZ HOLDER LHLDZB392WJZZ HOLDER PSHEPA468WJZZ SHEET [6] DUNTKF056TEV1 (OPE-L UNIT) C1201 VCEA9M0JW476M+ 47 6.3V Electrolytic D1201 RH-PXA046WJZZ+...
  • Page 66 BD-HP16U [7] CABINET PARTS POWER PWB MAIN PWB ANALOG PWB OPERATION-L PWB LCD PWB FRONT PANEL...
  • Page 67 BD-HP16U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [7] CABINET PARTS CCABAC236TEV1 TOP CABINET TLABMD299WJZZ MODEL LABEL DMECDA013TEV6 BD-RH3 GBDYUA365WJFW CHASSIS GCOVAD292WJZZ REAR PANEL LANGFA610WJFW DRIVE ANG L LHLDWA236WJKZ HDMI HOLDER LHLDZB327WJKZ INSULATION HOLDER LX-JZA010WJF7 M3X10, x23 NFANRA093WJQZ FAN MOTOR...
  • Page 68 BD-HP16U [9] SUPPLIED ACCESSORIES Remote control unit AC cord "AA" size battery (x 2) AV cable PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [9] SUPPLIED ACCESSORIES RRMCGA717WJPA QACCDA058WJPZ AC CORD QCNW-E699WJPZ A.V CABLE TGANEA016WJQZ REGIST. CARD TINS-E030WJQZ Operation Manual(E/SP)
  • Page 69 BD-HP16U [10] PACKING PARTS (NOT REPLACEMENT ITEM) PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [10] PACKING PARTS (NOT REPLACEMENT ITEM) SPAKCE745WJZZ PACKING CASE SPAKPB335WJZZ MIRROR MAT SPAKXC350WJZZ SIDE AD-R SPAKXC351WJZZ SIDE AD-L SSAKA0005PEZZ POLY BAG TLABV0182AJZZ NO LABEL [11] SERVICE JIG...
  • Page 70 BD-HP16U © COPYRIGHT 2009 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
