- Page 1 SDM-S74/S74E/S94 US Model SERVICE MANUAL Canadian Model AEP Model Chinese Model TFT LCD COLOR COMPUTER DISPLAY...
- Page 2 There are some different LCD panels are used in the model SDM-S74/S94. Therefore the repair parts are also different . Please confirm the serial number before repairing. Model name Colour Main destination CMO:L05 FUJITSU SDM-S74(TCO'99) GRAY 1,720,001 -1,730,000 1,730,001 -1,740,000...
-
Page 3: Table Of Contents
: 1280 x 1024 / 60Hz 19 inch (SDM-S94) 5. POWER SUPPLY Pixel Pitch : 0.264 (H) x 0.264 (V) (SDM-S74/E) 5-1. Power : AC 100~240V, 50/60Hz , 1.0A 0.294 (H) x 0.294 (V) (SDM-S94) 5-2. Power Consumption Color Depth : 16.2M colors (SDM-S74/E) - Page 4 T. M. D. S. Data1/3 Shield T. M. D. S. Data3- T. M. D. S. Data3+ +5V Power Ground (return for +5V, H. Sync. and V. Sync.) T. M. D. S. (Transition Minimized Differential Signaling) – 4 – SDM-S74/S74E/S94 (E)
-
Page 5: Precaution
• Avoid contact with water as it may a short circuit within the module. • If the surface of panel become dirty, please wipe it off with a softmaterial. (Cleaning with a dirty or rough cloth may damage the panel.) TIMING CHART VIDEO SYNC – 5 – SDM-S74/S74E/S94 (E) - Page 6 – 76.068Hz 31.216 1480 1170 1170x584 46.200 50Hz 50.026Hz 60.000 1800 1280 1280x960 108.000 60Hz 60.000Hz 1000 63.981 1688 1280 1280x1024 108.000 60Hz 60.020Hz 1066 1024 79.976 1688 1280 1280x1024 135.000 75Hz 75.025Hz 1066 1024 – 6 – SDM-S74/S74E/S94 (E)
-
Page 7: Operating Instructions
4. OK Button This button actives tge selected menu item and adjustments made using the buttons( 5. ECO Button This button is used to reduce the power consumption. REAR VIEW(SDM-S74) REAR VIEW(SDM-S94) HD15(RGB) input AC IN HD15(RGB) input connector connector... -
Page 8: Disassembly
4) Please pull upper side edge of Rear cabinet outside by same method. with fingertip. 5) Please pull right side edge of Rear cabinet outside with 6) Please pull left side edge of Rear cabinet outside with fingertip. fingertip. – 8 – SDM-S74/S74E/S94 (E) - Page 9 5) Please pull the Rear cabinet both edge outside with 6) If Rear cabinet be departed easily, please pull upside fingertips like picture, then Rear cabinet will be edge of Rear cabinet outside. departed. – 9 – SDM-S74/S74E/S94 (E)
-
Page 10: Adjustment
2. Setup primary mode. 1) Prepare timing and pattern data for a signal c. Adjust “SUB CONTRAST “ to secure the color generator according to the Sony timing temperature. specifications. d. Press “MENU” key to exit adjust mode. 2) Connect a monitor video cable to the signal generator. - Page 12 SDM-S74 EXPLODED VIEW PARTS LIST Ref. No. Part No. Description X-2021-045-1 BEZEL ASSY (Gray) X-2021-054-1 BEZEL ASSY (Black ) X-2022-009-1 BEZEL ASSY (Silver ) Panel: M170EN05-V1 (AU) 1-805-277-11 Panel: M170EN05-V4 1-805-277-31 Panel: M170EN05-V5 (AU) 1-805-600-21 Panel: M170E05-L05 (CMO) 4-097-375-21 BACK CABINET (Gray)
- Page 13 SDM-S74/S74E EXPLODED VIEW PARTS LIST Ref. No. Part No. Description X-2022-784-1 BEZEL ASSY (Silver) X-2022-787-1 BEZEL ASSY (Black) X-2022-790-1 BEZEL ASSY (Gray) 1-805-730-11 LCD PANEL (AU) X-2022-785-1 CABINET ASSY (S74, Silver) X-2022-788-1 CABINET ASSY (S74, Black) X-2022-791-1 CABINET ASSY (S74, Gray)
- Page 14 4-097-462-01 CUSHION 4-103-574-01 INDIVIDUAL CARTON (Gray) 4-103-576-01 INDIVIDUAL CARTON (Gray),TCO'03 4-103-575-01 INDIVIDUAL CARTON (Black) 2-059-677-01 INDIVIDUAL CARTON (Silver) 2-067-032-01 INDIVIDUAL CARTON (Silver),TCO'03 English Sony EMCS Corporation 2005DR02-1 Made in Japan Ichinomiya Tec 9-878-243-03 © 2005.4 – 14 – SDM-S74/S74E/S94 (E)
