SIMATIC IPC MD-34A Battery Charger
Product Information
Package Content
Scope of delivery:
•
Dual-bay Battery Charger × 1
•
19V AC Adapter × 1
•
Power Cord × 1
Design of product
Device in desk docking
Interfaces
① Dual-bay Battery docking connector
② 19V DC IN
③ LED Indicator
© Siemens AG 2023. All rights reserved
A5E52426055-AA, 05/2023
Front view of battery charger
④ Dual-bay Battery Docking connector
⑤ Buzzer
⑥ Battery Cradle
