Motorola VM44-2 CONNECT Quick Start Manual

QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User
Guide.
1. Setting up your Digital Video Baby Monitor
A. Connecting the Power Supply of the Parent Unit
A rechargeable battery (Lithiumion battery 2000mAh) inside the Parent Unit allows
you to move it without losing the link and picture from the Baby Unit. We recommend
charging the for at least 16 hours before first use, and when the Parent Unit indicates
the battery is low.
MODELS:
VM44 CONNECT,
VM44-2 CONNECT,
VM44-3 CONNECT,
VM44-4 CONNECT
STRANGULATION HAZARD. Children have STRANGLED in
cords. Keep this cord out of the reach of children (more than 1
Frequency band:
2400MHz to
metre away). Never use extension cords with AC Adapters. Only
2483.5MHz
Max. transmitted
use the AC Adapters provided.
power: < 20dBm
B. Desktop Stand of the Parent Unit
C. Connecting the Power Supply for the Baby Unit
NOTE:
When the Baby and Parent Units are both turned on and within range, the Parent
Unit should show a color image from the Baby Unit camera, but if the room is dark,
the image will be in black and white, with an
illumination by the Baby Unit.
2. Basic operation of the keys
Parent unit
Baby Unit
3. Setting up the Baby Unit for Wi-Fi® internet viewing
A. Install Motorola Nursery App
B. View on Compatible Smartphones and Tablets
1. Open the Motorola Nursery App on your compatible smartphone or tablet.
2. Follow the in-app instructions to create your account and connect to your device.
Please take note of the following minimum system requirements:
Smartphones/Tablets: iOS 11, Android™ 7.0
Wi-Fi ® requirements:
At least 0.6 Mbps upload bandwidth per Smart Montitoring Companion, test your Internet
speed at: http://www.speedtest.net/
(available for download from motorolanursery.com).
WARNING:
ON/OFF button
0
UP/DOWN buttons
+-
LEFT/RIGHT
<>
buttons
MENU button
M
OK button
O
VIDEO button
V
T
TALK button
RESET button
PAIR button
Camera Wi-Fi®
• Connect the small plug of the power
adapter to the parent unit and the
other end to the power socket.
Only use the enclosed adapter
(5VDC/1000mA).
• Press and hold the 0 button to turn
the Parent unit on, the Parent unit and
Baby unit are automatically linked and
ready to use.
• The parent unit comes with a desktop
stand attached to the back of the parent
unit.
• To place the parent unit on a desk, simply
pull out the stand, as shown.
NOTE
Place the parent unit on a flat, even surface.
• Insert th e DC plug of the power adapter
into the DC socket on the back of the Baby
Unit.
• Connect the other end of the power adapter
to a suitable power socket.
• The baby unit turns on and the power
indicator lights in Blue colour.
NOTE
Only use the supplied power adapter
(DC5V/1000mA).
Press and hold to switch the Parent Unit ON/OFF.
Press to select brightness level of Parent Unit.
Press to adjust menu setting when menu is active.
Press to adjust volume level.
Press to access menu options when menu is active.
Press to open menu options or exit the menu.
Press to confirm a selection.
Press to turn the LCD screen ON/OFF.
Press and hold to talk to your baby.
Press and hold with a small pin to reset the unit.
Press and hold to pair with the parent unit or Motorola
Nursery Setup.
• Scan the QR code with your smart device and download
Motorola Nursery App from the App Store for iOS
devices or from the Google Play™ Store for Android™
devices.
• Install Motorola Nursery App on your device.
Connect to Internet
via Wi-Fi ®
icon showing, due to the infra-red
Compatible
Viewing Devices
EN
