Whirlpool ADP 2756 Quick Reference Manual

GB
ADP 2756
Programme selector
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
Option
Delayed start button
The wash cycle can be programmed to start after
3-6-9 hours. Then press the Start button.
The wash programme will start at the set time.
Programme Symbol
and Temperature
Pre-wash
Rapid 30'
Delicate 40° C
2)
Eco 50° C
Daily 65° C
3)
Daily plus 65° C
Intensive 70° C
1) Values may vary in relation to usage, e.g.: different loads, water temperatures - above or below
15° C - as well as water hardness and power supply voltage.
2) Programme recommended when using detergents of type B (enzyme-based detergents).
Reference programme for energy label.
3) Programme recommended when using detergents of type A (non enzyme-based detergents).
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme selection and
recommended load type
Crockery to be washed later.
Lightly soiled crockery with no dried-on food.
Light soiling, especially glasses and cups.
Normally or heavily soiled crockery with dried-on food.
Normally soiled crockery.
Normally or heavily soiled crockery.
Heavily soiled pans and saucepans.
Salt level indicator
Add regeneration salt; only add regeneration salt
immediately before starting a wash programme.
Half Load / Multizone button
Load the upper or lower rack only.
This function can be used with any
programme.
press once = upper rack (the indicator lamp comes on)
press twice = lower rack (the indicator lamp comes on)
press 3 times = Off (half load function deactivated).
Place the detergent in the:
small compartment large compartment
-
-
-
X
-
X
X
Programme progress indicator
Pre-rinse / Pre-wash
Washing
Drying
Programme end
Consumption
Normal Load /
(Half load / Multizone)
Water Energy
(Litres) (kWh)
- 5.0 (4.2) 0.02 (0.02)
X 13.0 (13.0) 0.85 (0.75)
X 12.5 (10.5) 0.82 (0.78)
X 16.0 (14.5) 1.26 (1.05)
X 13.0 (11.0) 1.45 (1.38)
X 16.0 (14.0) 1.60 (1.40)
X 21.5 (18.2) 1.70 (1.60)
5019 100 91329
(We reserve the right to make technical modifications)
1)
Time
(Min.)
9 (9)
30 (30)
60 (59)
133 (125)
73 (71)
86 (83)
93 (90)
