Thank you for purchasing this product.
- Read these instructions carefully for optimum
performance and safety before use.
- Keep this manual for future reference.
Operating & Installation Instructions
Fully Automatic Washing Machine
NA-FD135X3
Model No.
NA-FD125X3
No. Reg. : IMKG.1011.06.2023
Contents
￿￿￶￷  ￶￳￶ ￶
AWW9901CCRC0-0C0
(Household Use)
A0823-0(I)
Printed in Vietnam
08-2023
2
6
7
8
9
10
12
14
18
19
20
24
28
30
32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NA-FD135X3 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic NA-FD135X3

Summary of Contents for Panasonic NA-FD135X3

  • Page 1: Table Of Contents

    Operating & Installation Instructions Fully Automatic Washing Machine (Household Use) NA-FD135X3 Model No. NA-FD125X3 No. Reg. : IMKG.1011.06.2023 Contents Safety Precautions Part Names / Accessories Before Washing Operation Panel Washing Variety of Programs Detergent / Softener / Bleach Washing Options •...

  • Page 2: Safety Precautions

    Safety Precautions WARNING May cause serious injury or death. Children must not use it alone. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 3 In case of failure or damaged power cord, Accumulated dust stop use and ask the electrical technician. may cause fire. Securely insert the ground prong. Wipe the power plug periodically. Call your local dealer for a new socket. Use a socket appropriate for this Keep away from appliance.
  • Page 4 Safety Precautions (continued) CAUTION May cause injury. Be careful not to get your fingers caught. Do not climb or put objects on the appliance. If the lid is broken, immediately stop using. Be careful of your hands and feet. May cause water leakage. Turn off the water faucet.
  • Page 5 May cause failure. Keep away from heat and direct Do not wash waterproof sunlight. items. Raincoats, wet suits, etc. Do not obstruct. Do not use hot water. Do not obstruct the openings of Over 50 ºC the bottom face with carpet, etc. For machine-washable items only.

  • Page 6: Part Names / Accessories

    Part Names / Accessories Part names Operation panel Water supply valve (P. 8) (P. 26) Detergent and softener drawer (P. 12) Lint filter (P. 20) Power cord and plug* (P. 3) * The plug shape varies with the region. Pulsator External drain water hose Adjustable leg...

  • Page 7: Before Washing

    Before Washing Laundry preparation and check Pre-laundry check Use laundry nets for delicates Overpack For “Stain Master” (P. 16) Pretreatments for heavily stains Reverse Observe the clothes' care labels Clothes likely to pill Paper diapers To prevent colour staining...

  • Page 8: Operation Panel

    (P. 14) Water level (L) Detergent * 79 * Flashing (in progress) Approx. 5 sec Remaining time *1 NA-FD135X3: 79 L NA-FD125X3: 77 L : 1 scoop of detergent Child Lock lamp Refill (P. 18) (P. 19) Tangle Preset...

  • Page 9: Washing

    Washing „ Preset timer (P. 14) (P. 10) Measures the amount of laundry. 10 sec 5 sec 20 sec (P. 8) (P. 12) „After pressing “Start” To change each operation (while washing). Pause Start To check or change the water level (while washing). You cannot change the program.

  • Page 10: Variety Of Programs

    Variety of Programs Max. Program Purpose capacity * (kg) Everyday clothes Normal (P. 9) 13.5 12.5 Anti-tangling Tangle • Washing more gently than “Normal” to Care (P. 9) reduce tangle. • Disentangling clothes after spin: 6 kg or less. For light soil 13.5 Speedy (P.
  • Page 11 * Top: NA-FD135X3 / Bottom: NA-FD125X3 Max. Program Purpose capacity * (kg) 13.5 For heavy soil Soak (P. 9) 12.5 Presoaking to wash For the following stains (P. 16) Light Use more softener to keep the Odour/ scent longer Aroma+...

  • Page 12: Detergent / Softener / Bleach

    Detergent / Softener / Bleach Follow the instructions on each package. For cleaning (P. 21) Close auto dosing drawer completely before use. Detergent Do not pour detergent directly into the tub. The level of foaming depends on the load size, soil, detergent, and water hardness.
  • Page 13 Liquid Powder Softener detergent detergent Max level Softener To put softener while the machine is Water operating: Pause Concentrated softener Softener cannot be used with the Do not use separated “Water Save” program. or solidified softeners...

  • Page 14: Washing Options

    Washing Options Preset Wash / Rinse / Spin Set how many hours later to finish operation. 2 min All other indications turn off. 2 - 24 1 - 24 2 - 24 NOTE Not available for “Tangle Care”. 2 - 24 3 - 24 2 - 24 „...

  • Page 15: Delicates

    4.2 kg Max. 55 L 3.0 kg • 100 % synthetic fibre water amount * • 100 % cotton NOTE * NA-FD135X3: 79 L / NA-FD125X3: 77 L Liquid delicate Bleach detergent „ After operation ends Take out immediately. NOTE...

  • Page 16: Stain Master

    Washing Options (continued) Stain Master Preparation: (P. 7) NOTE Max. capacity (P. 11) „ Timer preset (hours) (P. 14) Max. water amount: 65 L You cannot change the wash process setting of this program.

  • Page 17: Air Dry (90 Min)

    Air Dry (90 min) The air blown from the tub rotation removes water from clothes. Dryable clothes: Synthetic fibre (Max. 2.0 kg) NOTE Clothes may not be sufficiently dried (depends on amount and type of clothes, and the temperature). This function does not use a heater. Clothes may be cold and half dry.

  • Page 18: Convenient Functions

    Convenient Functions Setting Auto Tub Clean Setting Child Lock Preventing black mould, available with all programs except “Water Save” and “Air Dry (90 min)”. „ Lamp indications Operating Function enabled Forcible 10 sec drainage (P. 29) Function disabled * This function does not lock the lid and button operations.

  • Page 19: Contents Of Programs

    Contents of Programs Total time Wash Rinse Spin Program (min) (min) (times) (min) Normal Tangle Care Speedy Delicates Baby Care Water Save Blanket Soak (Soak 59) Odour/Aroma+ Soya/Sauce (Soak 29) Tub Hygiene (Soak 62) *1 Total time is approximate (When the standard water supply rate is 15 L / min and the water temperature is 28 ºC).

  • Page 20: Maintenance

    Maintenance Lint filter After each operation Water Click NOTE If it is difficult to remove If the filter is broken Without the filter the filter Local dealer...
  • Page 21 Detergent and softener drawer If stained with detergent or softener Remove Thin Thick Click Attach Main unit, lid For heavy soil Neutral kitchen detergent...
  • Page 22 Maintenance (continued) Water supply filter If water does not flow smoothly Water supply filter Start Approx. 40 sec Loosen Tighten...
  • Page 23 Once a week <Air Dry> (P. 17) Empty Once a month <Tub Hygiene> Whiten bleach (chlorine bleach) 200 ml Start Empty Approx. 2.5 hours Start Pause Full...

  • Page 24: Installation

    Make sure to ask a service person for installation. Check the location. „ Do not install by yourself. „ Follow this installation method. If you do not, Panasonic will not be liable for any accident or damage. Bottom cover External drain water hose...
  • Page 25 Attach the bottom cover Attach the external drain water hose NOTE Over 10 cm Over 3 m...
  • Page 26 Installation (continued) Connect the water supply hose Thread: Approx. 4 mm Check that the Loosen elbow is not loose. Tighten CAUTION Tighten the nut firmly. Tighten securely Do not twist, squash, modify or cut (To prevent water the hose. leakage).
  • Page 27 Connect the power plug and grounding Check that the washing machine is level „ If the washing machine wobbles Loosen Adjust Tighten Trial operation Abnormal sounds (P. 28)

  • Page 28: Error Display

    Error Display „ Preparation Cancel Child Lock (P. 18) if it is set. Error Display Points to be checked Check Lint Water cannot drain. Over 10 cm Over 3 m The lid is open. Even Uneven Spin or “Air Unstable or incline Stable Dry”...
  • Page 29 Error Display Points to be checked Water outage Turned off Water cannot be supplied. Water supply filter (P. 22) With Child Lock set Forcible drainage 10 sec Water has been forcibly drained. 5 sec Inspection is required.

  • Page 30: Troubleshooting

    Troubleshooting Symptoms Points to be checked Time indication is approximate. Indication increases or Remaining time is corrected during operation. does not decrease. Longer than the indication. When clothes When the water When the water are uneven. drainage is not good. supply is not good.
  • Page 31 Symptoms Points to be checked Water is supplied while When amount of When water washing. level drops. laundry is large. Water is added automatically. The water level When there is water When laundry is wet. in the tub before operation. too high The water level may be higher When clothes are light...

  • Page 32: Specifications

    Pressure of tap water 0.01 - 1 MPa Diimpor oleh: Pusat Pelayanan Pelanggan: PT Panasonic Gobel Indonesia Contact Center JI.Dewi Sartika No.14 (Cawang II), Telp. 0804-1-111-111 Jakarta, 13630, Indonesia E-mail: ccc@id.panasonic.com Website: www.panasonic.com/id https://www.panasonic.com © Panasonic Appliances (Vietnam) Co., Ltd. 2023...
