- Page 1 PN-HW501T Dismantle Instruction LCD MONITOR PN-HW501T MODEL Dismantle Instruction...
-
Page 2: Table Of Contents
PN-HW501T Dismantle Instruction Table of contents 1. Scope........................3 2. Tools for dismantling ....................3 3. Dismantle Procedure ....................3 4. Back covers ......................4 5. Printed circuit boards ..................... 5 6. Battery ........................ 5 7. LCD Module ......................6 8. -
Page 3: Scope
PN-HW501T Dismantle Instruction 1. Scope This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU. 2. Tools for dismantling Below tools are required to dismantle this product. Screw Driver Nipper 3. Dismantle Procedure This product can be dismantled by below steps. -
Page 4: Back Covers
PN-HW501T Dismantle Instruction 4. Back covers Back cover can be removed by screw driver. -
Page 5: Printed Circuit Boards
PN-HW501T Dismantle Instruction 5. Printed circuit boards All PWBs can be removed by screw driver. Main I/F PWB (1pcs) Power PWB (1pcs) LED driver PWB (1pcs) T-CON PWB (1pcs) 6. Battery This model uses only AAA battery for remote control. -
Page 6: Lcd Module
PN-HW501T Dismantle Instruction 7. LCD Module LCD Dismantle procedure Remove the Brackets for touch panel mounting Remove the Touch panel Remove the Rear cover Remove the PWBs Remove the Cables... -
Page 7: Capacitors
PN-HW501T Dismantle Instruction 8. Capacitors Electrolyte Capacitors which diameter/height is larger than 25mm is installed on Power PWB. These capacitors can be removed by using nipper to cut the leads. On Power PWB 9. Parts List Parts described in Annex VII of directive 2012/19/EU are as below.
