About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) IdeaPad Pro 5 14IRH8 83AL IdeaPad Pro 5 14ARP8 83AN...
Base Figure 2. Base view-IdeaPad Pro 5 14IRH8, IdeaPad Pro 5 14ARP8 and IdeaPad Pro 5 14APH8 Figure 3. Base view-IdeaPad Pro 5 16IRH8, IdeaPad Pro 5 16ARP8 and IdeaPad Pro 5 16APH8 User Guide...
Page 9
Description Item Controls & Connectors Wireless antennas Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Notes: • The antennas are not visible from the outside of the computer. • If the location of the antennas is close to the user’s body (<...
Left Figure 4. Left view-IdeaPad Pro 5 14IRH8, IdeaPad Pro 5 14ARP8 and IdeaPad Pro 5 14APH8 Figure 5. Left view-IdeaPad Pro 5 16ARP8 and IdeaPad Pro 5 16APH8 User Guide...
Page 11
Figure 6. Left view-IdeaPad Pro 5 16IRH8 and IdeaPad Pro 5 16APH8 Description Item Controls & Connectors Power connector Connect to power with the included power cord and ac power adapter. Charging light Indicate whether the computer is connected to ac power. •...
Right Figure 7. Right view-IdeaPad Pro 5 14IRH8, IdeaPad Pro 5 14ARP8 and IdeaPad Pro 5 14APH8 Figure 8. Right view-IdeaPad Pro 5 16IRH8, IdeaPad Pro 5 16ARP8 and IdeaPad Pro 5 16APH8 User Guide...
Page 13
The always-on function can be turned on or off in the UEFI/BIOS setup utility. Note: If Lenovo Vantage is pre-installed on your computer, you can also set always-on function within that software.
Bottom Figure 9. Bottom view-IdeaPad Pro 5 14IRH8, IdeaPad Pro 5 14ARP8 and IdeaPad Pro 5 14APH8 Figure 10. Bottom view-IdeaPad Pro 5 16IRH8, IdeaPad Pro 5 16ARP8 and IdeaPad Pro 5 16APH8 Description Item Controls & Connectors Ventilation slots (inlet) Maintain the incoming airflow to dissipate internal heat.
– Maximum output: 20 V dc, 5 A/20 V dc, 7 A – Maximum power: 100 W/140 W – IdeaPad Pro 5 14ARP8, IdeaPad Pro 5 14APH8, IdeaPad Pro 5 16ARP8 and IdeaPad Pro 5 16APH8 – Input: 100 V ac–240 V ac, 50 Hz–60 Hz –...
Page 16
• Form factor: M.2 (2242/2280) • Bus: PCI Express Screen • IdeaPad Pro 5 14IRH8, IdeaPad Pro 5 14ARP8 and IdeaPad Pro 5 14APH8 – Size: 355.6 mm (14 inches) – Display resolution: – 2240 × 1400 pixels – 2880 × 1800 pixels •...
Specifications Descriptions Security • UEFI/BIOS passwords – Administrator password – User password – Master hard disk password – User hard disk password Network Bluetooth and Wi-Fi combo adapter * for selected models Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device.
bottom surface will remain within an acceptable range as defined in IEC 62368-1, but such temperatures can still be high enough to cause discomfort or harm to the user if directly touched for over 10 seconds at a time. As such, it is recommended that users avoid prolonged direct contact with the bottom of the computer.
Night light temperature screen. Note: Selected Lenovo computers are low blue light certified using night light mode and color temperature settings available in the pre-installed operating system. These computers are tested with night light turned on and color temperature set to 48 or greater.
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store.
Interact with your computer Hotkeys Look at the top row of the keyboard of your Lenovo computer and you’ll find keys with printed icons. These keys are called hotkeys and they provide shortcuts to functions that you’ll use frequently. The function that each hotkey provides is denoted by the icon printed on the key.
A Lenovo keyboard usually contains hotkeys in the top row. These hotkeys share keys with the function keys (F1–F12) and other keys. For these dual-function keys, the icons or characters denoting the primary functions are printed on top of the icons and characters denoting the secondary functions.
You can charge the battery any time you want. The battery packs of Lenovo computers support multiple charging modes that are suitable for different power usage habits. You can switch the battery’s active charging mode in Lenovo Vantage, Lenovo PC Manager, or Lenovo Smart Engine.
If the battery pack of your computer supports nighttime charge optimization, it can be enabled in Lenovo Vantage, Lenovo PC Manager, or Lenovo Smart Engine.
You can switch the operation mode in the pre-installed app Lenovo Vantage, Lenovo Smart Engine, or Lenovo PC Manager. As a shortcut, you can also use the key combination Fn + Q. Three modes are usually available for most Lenovo computers. The following table lists the operation modes and the recommended conditions for each mode.
The displays of some Lenovo computers support dual refresh rates. For such a computer, you can manually switch its display to work at either the higher or lower refresh rate. For Windows operation systems, the manual settings are usually found in Settings ➙...
Change the setting to Disabled or Enabled. Select Exit ➙ Exit Saving Changes. Step 4. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility.
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service.
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service.
Why does my computer start automatically when I open the lid Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically.
3. Click Diagnostics ➙ Operating System Diagnostics and then follow the on-screen instructions. Use Lenovo Vantage or Lenovo PC Manager to: • Download and install the latest drivers and firmware. • Configure hardware settings Use Windows Search. • Diagnose computer hardware problems.
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;...
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service.
Appendix A. Function descriptions for Lenovo hotkeys Hotkey functions are denoted by the icons printed on the keys. The following table describes the functions for all Lenovo hotkeys. The keyboard of your Lenovo computer should only support a subset of the listed hotkeys.
Page 36
Table 6. Hotkey icons and denoted functions (continued) Hotkey icon Function description Switches the computer’s active operation mode. Blurs the background for videoconferencing. Switches the computer’s active audio mode. Turns on/off night light mode. (Windows operating systems) Note: Hotkey functions may change if the associated app or the Windows operating system is updated. User Guide...
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 38
Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
