„ RJ45-Ethernetkabel
①
„ Erdungsleitung
Website für technische
Informationen
"Countermeasure for
Lightning Surge"
<Kontroll-Nr.: C0121>
M3 × 6 mm
Empfohlenes Anzugsmoment:
0,69 N·m
②
65
RJ45 Ethernet
Kategorie 5e oder besser,
geradlinig, 4 Leiterpaare
(8 Pins)
<100 m
Innen
Außen
Erdungsleitung
(vor Ort zu beschaffen)
