Summary of Contents for Beko COOL74FDS
- Page 1 Frost Free Combi Fridge Freezer COOL74FDS...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in a 1st-class manufacturing facility and checked under the most meticulous quality control procedures, will provide you with years of good service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future reference.
-
Page 3: Table Of Contents
1 Your refrigerator 4 Preparation Final Check ........15 2 Warnings 5 Using your refrigerator 16 Electrical Requirements .....5 Warning! This Appliance Must Be Icematic and ice storage container ..20 Earthed ..........5 Water Dispenser ......21 Energy Saving Tips ......6 *optional ..........21 3 Installation 6 Maintenance and cleaning... -
Page 4: Your Refrigerator
Your refrigerator Congratulations on your choice of a BEKO quality Appliance which has been designed to give you service for many years. Door Shelves (Small bottles,cans, Crisper bins (for fresh fruit and tubes) vegetables) Egg Tray 10. Lower storage shelf (Store meat,... -
Page 5: Warnings
• Do not dispose of the appliance on structure, clear of obstruction. a fire. At BEKO, the care and protection • Do not use mechanical devices of our environment is an ongoing or other means to accelerate the commitment. -
Page 6: Electrical Requirements
3. Connect the brown (Live) wire to mains lead which can only be obtained the terminal in the plug marked ‘L’ or from a BEKO Authorised Service coloured red. Agent. With alternative plugs a 13 A fuse must... -
Page 7: Energy Saving Tips
Energy Saving Tips 1- Ensure your appliance is installed in a well ventilated area. 2- Ensure the time between buying chilled/frozen food and placing them in your appliance is kept at minimum, particularly in summer. We recommend you use a cool bag or a special carrier bag to carry perishable food. -
Page 8: Installation
Installation Please remember that the 4.You will hear a noise as the compressor manufacturer shall not be held liable if starts up. The liquid and gases sealed the information given in the instruction within the refrigeration system may manual is not observed. also give rise to noise, even if the compressor is not running and this is Points to be considered... -
Page 9: Disposing Of Your Old Refrigerator
Disposing of your old 4. Place your refrigerator on an even floor refrigerator surface to prevent jolts. Dispose of your old refrigerator without giving any harm to the environment. •You may consult your authorised dealer or waste collection center of your municipality about the disposal of your refrigerator. -
Page 10: Transportation Instructions
Do not move the appliance by your flooring, pipes,wall coverings etc. pulling by the door or handle. BEKO plc declines to accept any 6. Empty any water in the drain tray liability should the instructions not be and Water Dispenser tank before followed. -
Page 11: Installation Instructions
Installation Instructions case of transportation, ensure you locate the plug in the receptacle 1. Fit the two plastic wall spacers provided to avoid transit damage. supplied onto the condenser at the back of the appliance by rotating 1/4 turn. 5. The space in the room where the appliance is installed must 2. - Page 12 This appliance is designed to operate at temperatures specified in the table below is equipped with ‘Freezer Guard’ which ensures that at the advised setting [4 - four on the control] the frozen food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C.
-
Page 13: Replacing The Interior Light Bulb
Replacing the interior light bulb Should the light fail to work, proceed as follows. 1. Switch off at the socket outlet and pull out the mains plug. • You may find it useful to remove shelves for easy access. 2. Use a flat tipped screwdriver to remove the light diffuser cover by inserting the blade in each of the two recesses to prise off each side. -
Page 14: Repositioning The Doors
Repositioning the doors 17-Unscrew and reposition the bottom hinge bushing. (15) (see diagram on the opposite 18-Unscrew bolt of the pin on the bottom page) hinge. Fit the pin to the other hole on 1- Switch off the appliance at the socket the hinge and tighten the bolt on the outlet and pull out the mains plug. - Page 15 45 ¡ 180°...
-
Page 16: Preparation
Preparation Your refrigerator should be installed at • When the door is open the fridge least 30 cm away from heat sources interior light will come on. such as hobs, ovens, central heater 5. You will hear a noise as the compressor and stoves and at least 5 cm away starts up. -
Page 17: Using Your Refrigerator
Using your refrigerator TEMPERATURE CONTROL AND Remember you must take your reading ADJUSTMENT very quickly since the thermometer temperature will rise very rapidly after you remove it from the freezer. Please remember each time the door is opened cold air escapes and the internal temperature rises. - Page 18 7. Keep the food packed wrapped or SUGGESTED ARRANGEMENT OF covered. Allow hot food and beverages FOOD IN THE FRIDGE/FREEZER to cool before placing them in the fridge. Arrangement Examples (See diagram) Do not store explosive substances. 1. Baked, chilled cooked food, dairy High proof alcohol must be stored products, cans.
- Page 19 STORING FROZEN FOOD When freezing fresh food turn the setting towards Max. Small quantities Prepacked commercially frozen food of food up to 1/2 kg. (1 lb) can be should be stored in accordance with the frozen without having to rotate the frozen food manufacturer’s instructions temperature control .
- Page 20 DEFROSTING B) FREEZER COMPARTMENT A) FRIDGE COMPARTMENT The fridge compartment defrosts The freezer compartment operation is automatically. The defrosting water frost free and does not need defrosting. runs to the drain tube via a collection container at the back of the appliance Warnings! (1).
-
Page 21: Icematic And Ice Storage Container
Icematic and ice storage container Using the Icematic Fill the Icematic with water and place it into its seat. Your ice will be ready approximately in two hours. Do not remove the Icematic from its seating to take ice. Turn the knobs on it clockwise by 90 degrees. -
Page 22: Water Dispenser
Water Dispenser *optional Water dispenser is a very useful feature based on reaching cold water without opening the door of your refrigerator. As you will not have to open your refrigerator door frequently, you will have saved energy. As the level of the water in your glass/ container rises, slightly lessen the pressure on the arm to prevent the overspill. - Page 23 used. Warranty does not cover such usages. Some chemical substances and additives contained in these kinds of drinks/liquids may damage the water tank. • Use clean and pure drinking water only. • Capacity of the water tank is 2.2 liters (3.8 pints);...
- Page 24 Make sure that the parts removed (if any) during cleaning are properly attached to their original places. Otherwise, water leakage may occur. Important: Components of the water tank and water dispenser should not be washed in dishwasher. Water tray Water that dripped while using the water dispenser accumulates in the spillage tray.
-
Page 25: Maintenance And Cleaning
Maintenance and cleaning ** Removal of door tray • To remove door racks, remove ** We recommend that you switch off all the contents and then simply push the appliance at the socket outlet and the door rack upwards from the base. pull out the mains plug before cleaning. -
Page 26: Do's And Don'ts
Do's and Don'ts Do- Clean your appliance regularly Do- Wrap all food in aluminium foil or (See “Cleaning and Care”) freezer quality polythene bags and Do- Keep raw meat and poultry below make sure any air is excluded. cooked food and dairy products. Do- Wrap frozen food when you buy it Do- Take off any unusable leaves on and put it in to the freezer as soon... - Page 27 into the freezer as they may burst. Don’t- Exceed the maximum freezing PROBLEM SOLVING loads (6 kg in any 24 hours) when If the appliance does not operate freezing fresh food. when switched on, check whether: Don’t- Give children ice-cream and •...
- Page 28 • The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse.
- Page 29 Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 6004911 e-mail: service@beko.co.uk...
- Page 30 BEKO plc Beko House Caxton Way Watford Hertfordshire WD18 8UF Tel: 0845 6004911 Fax: 0845 6004922 Printed in Turkey e-mail: service@beko.co.uk 57 2024 0000 Part no: website: www.beko.co.uk Revision no:...
