Dyon SMART 42 XT V2 Instructions Manual

Hide thumbs Also See for SMART 42 XT V2:

Quick start manual (2 pages)

Quick start manual (2 pages)

User manual (56 pages)

Table of Contents

Quick Links

Content

Important Safety Instructions ................................................................ 3

Support Information .............................................................................. 8

Appropriate use .................................................................................... 8

Notes on energy efficiency .................................................................... 9

Conformity .......................................................................................... 11

Montage ............................................................................................. 12

6.1

Stand mounting ......................................................................................... 12

6.2

Wall mounting ........................................................................................... 13

Controls and connections ................................................................... 14

7.1

The buttons on the device ........................................................................ 14

7.2

Connections .............................................................................................. 15

7.3

CI/CI+ Slot ................................................................................................ 16

7.4

Remote Key Function ............................................................................... 18

7.5

Antenna connection .................................................................................. 21

Initial setup ......................................................................................... 22

8.1

Language .................................................................................................. 22

8.2

Country ..................................................................................................... 22

8.3

Information on data collection and firmware updates .............................. 23

8.4

Network ..................................................................................................... 23

8.4.1

WiFi .................................................................................................... 24

8.4.2

Wired .................................................................................................. 24

8.5

Set up Netflix ............................................................................................ 24

8.6

Select TV Mode ........................................................................................ 25

8.7

Tuner Mode .............................................................................................. 25

Input source selection ......................................................................... 26

10 TV Features ....................................................................................... 26

10.1 EPG (Electronic Program Guide) ............................................................. 26

10.2 Channel List .............................................................................................. 27

10.3 HbbTV ....................................................................................................... 28

10.4 Teletext ..................................................................................................... 29

10.5 Hotel Mode................................................................................................ 30

11 Menu Settings .................................................................................... 31

11.1 Video Menu ............................................................................................... 31

11.2 Audio Menu ............................................................................................... 32

11.3 TV Menu ................................................................................................... 33

11.3.1

Edit channel ....................................................................................... 34

11.4 Menu System ............................................................................................ 34

11.5 Parental Menu .......................................................................................... 35

11.6 About Menu .............................................................................................. 36

12 Smart Functions ................................................................................. 37

13 CI+ Information ................................................................................... 38

14 USB Devices ...................................................................................... 40

14.1 Connecting USB devices .......................................................................... 40

DYON SMART 42 XT V2

V1.0.0

Table of Contents

Need help?

Do you have a question about the SMART 42 XT V2 and is the answer not in the manual?

Questions and answers

Jenei János

February 1, 2025

Hello, This model has bluetooth connection possibility?

Summary of Contents for Dyon SMART 42 XT V2

Page 1: Table Of Contents
DYON SMART 42 XT V2 V1.0.0 Content Important Safety Instructions ..............3 Support Information ................8 Appropriate use ..................8 Notes on energy efficiency ..............9 Conformity ..................11 Montage ..................... 12 Stand mounting ..................12 Wall mounting ................... 13 Controls and connections ..............
Page 2 DYON SMART 42 XT V2 14.2 Video Playback ..................41 14.3 Picture Playback ..................41 14.4 Music Playback ..................41 15 Troubleshoouting ................42 15.1 Error Notes....................42 15.2 No sound / no picture ................44 16 Specifications ..................45 17 Glossar ....................
Page 3: Important Safety Instructions
DYON SMART 42 XT V2 Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions.
Page 4 DYON SMART 42 XT V2 13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Page 5 DYON SMART 42 XT V2 The symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. The symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. Warning High voltages are used in the operation of this television receiver.
Page 6 DYON SMART 42 XT V2 Caution Do not trap the power supply cord under the television. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall.
Page 7 DYON SMART 42 XT V2 Tips regarding environmental protection At the end of its operating life, this product may not be disposed of by way of your normal household waste. Instead it must be delivered to a collection point for recycling electrical and electronic equipment.
Page 8: Support Information
DYON SMART 42 XT V2 Support Information See our website for the latest information on this device, on other products by our company and on our company itself. If you have questions or problems, please read the FAQs on our website or contact our customer support service.
Page 9: Notes On Energy Efficiency
DYON SMART 42 XT V2 Notes on energy efficiency The device has facilities for reducing the energy requirement. Make the appropriate settings as required. TV Mode During initial installation and via the menu: MENU button – Setup – TV Mode Adapted illuminance for home use.
Page 10 DYON SMART 42 XT V2 Important! The device switches to standby mode independently after 4 hours without operations. Please note, this is NOT a defect. It is a legal requirement. A note occurs shortly before the device turn in the off- mode.
Page 11: Conformity
DYON SMART 42 XT V2 Conformity We, Axdia International GmbH, hereby declare that this device corresponds to the basic requirements and relevant regulations outlined in guidelines 2014/53/EU, 2014/30/EU, 2014/35/EU and 2009/125/EC. The CE declaration of conformity for this product may be found on the following link: www.axdiaservice.de/konform...
Page 12: Montage
DYON SMART 42 XT V2 Montage Stand mounting Fix the feet in the device as described in the picture and fix them with the enclosed mounting screws.
Page 13: Wall Mounting
DYON SMART 42 XT V2 Wall mounting Fasten your wall bracket to the threads on the back and observe the hole spacing. For the wall mounting two persons are required. Please follow the mounting instructions of the wall mount used and the length of the screws used.
Page 14: Controls And Connections
DYON SMART 42 XT V2 Controls and connections The buttons on the device Power Button Note The illustrations in this manual serve to describe the device functions and may vary depending on the model.
Page 15: Connections
DYON SMART 42 XT V2 Connections 1. Digital Audio Output 6. HDMI 1 (ARC) (optical) 7. HDMI 2 2. CI+ Slot 8. USB 2.0 2x 3. Mini AV-IN 9. LAN (RJ45) 4. DVB-S (LNB IN) 5. Antenna connection (C/T2) (RF) Please use only connection cables that are not longer than 1,5m.
Page 16: Ci/Ci+ Slot
DYON SMART 42 XT V2 CI/CI+ Slot Note according the CI Slot Please take care to insert the CI-Module (CAM) in the correct way. The Top side of the module must face against the wall behind. This device is equipped with a CI+ slot for use with CAM modules and Smart cards which allow for the viewing of encrypted Pay-TV channels.
Page 17 DYON SMART 42 XT V2   Please note Module and smart card are not including. Install the CI+ module after the channel scan has been accomplished and all other settings have been set. The activation of the card may take several minutes for the first time it is used.
Page 18: Remote Key Function
DYON SMART 42 XT V2 Remote Key Function POWER: to switch the device to on or standby MUTE: To disable or enable the sound output NUMBER KEYS: used to select channel numbers or input numbers in menus RECALL: Display the previous channel...
Page 19 DYON SMART 42 XT V2 26. TEXT: In TV Mode: Open Teletext 27. |: Fast rewind 28. |: Fast forward 29. SLEEP: Setting for Sleep Timer 30. : Fast rewind 31. : Fast forward 32. ASPECT: Change the aspect ratio 33.
Page 20 DYON SMART 42 XT V2 Inserting the battery into the remote control Remove the battery cover. Insert two AAA 1.5V batteries. Make sure that the polarity (+ or -) is correct. The polarity is indicated. Reinsert the battery cover. Note on batteries Alkaline Batteries are recommended.
Page 21: Antenna Connection
DYON SMART 42 XT V2 Antenna connection Connection for DVB-T2 reception or cable TV Connect the signal cable (e.g. the antenna cable) to the antenna input (RF) on the back of the device. After connection, turn on the device. Press the MENU button, select TV menu, select Tuner mode and now select DVB-T/C and perform channel search.
Page 22: Initial Setup
DYON SMART 42 XT V2 Connection to the satellite receiver Connect the signal cable to the LNB IN input on the back of the device. After connection, turn on the device. Press the MENU button, select the TV menu, select Tuner mode and now select "Satellite"...
Page 23: Information On Data Collection And Firmware Updates
DYON SMART 42 XT V2 Information on data collection and firmware updates Use the /buttons to select "Accept" or "View additional details" to obtain additional information about the data acquisition. Confirm your selection with the OK button. Press the BACK button to return to the previous menu.
Page 24: Wifi
DYON SMART 42 XT V2 8.4.1 WiFi Select the desired network access, the network name of your network (SSID) from the list on the right with the / buttons, confirm your selection with the OK button. Select Connecting and press the OK button to confirm your selection.
Page 25: Select Tv Mode
DYON SMART 42 XT V2 Use the / buttons to select the desired option and confirm your selection with the OK button. If you want to start and set up Netflix, select "Start Netflix". If you skip this step, you can easily start the application even...
Page 26: Input Source Selection
DYON SMART 42 XT V2 Note For private satellite reception, DVB-T or cable TV, please use DVB-T, DVB-S or DVB-C accordingly for the channel search. Analog channels (ATV) are no longer available here. Input source selection This device includes various input sources that can be accessed and selected with the SOURCE button on the remote control.
Page 27: Channel List
DYON SMART 42 XT V2 Channel view Press the / buttons to switch between channel list and program list. Press the / buttons to select the desired channel or program. Press the INFO button to get detailed information about the current program (not supported by all stations).
Page 28: Hbbtv
DYON SMART 42 XT V2 Advanced functions  Press the red button to mark the channel as favorite.  Press the green button to enter the channel list menu.  Press the blue button to open the favorite list. ...
Page 29: Teletext
DYON SMART 42 XT V2 10.4 Teletext Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.)
Page 30: Hotel Mode
DYON SMART 42 XT V2 10.5 Hotel Mode To enter the hotel mode, press the MENU button and enter the password 4588 immediately afterwards. The Hotel Mode settings will be displayed directly. Press the / buttons to open the setting (On/Off) and then select "On".
Page 31: Menu Settings
DYON SMART 42 XT V2 11 Menu Settings Press the MENU button and the /buttons to select a function. Press the /buttons to open a setting. 11.1 Video Menu You can adjust picture settings such as contrast, brightness, etc. here.
Page 32: Audio Menu
DYON SMART 42 XT V2 11.2 Audio Menu Here you can adjust the sound. Press the / buttons to select a setting, press the / buttons to change the setting and press the OK button to confirm. Press the BACK button to return to the previous menu.
Page 33: Tv Menu
DYON SMART 42 XT V2 Dialogue Enhacement Off, Low, Medium, High 11.3 TV Menu Here you can make setting of the channel search. Press the /buttons to select a setting, press the /buttons to change the setting and press the OK button to confirm. Press the BACK button, to return to the previous menu.
Page 34: Edit Channel
DYON SMART 42 XT V2 Note All saved channels are deleted and overwritten during the automatic channel scan. After the automatic channel search, the first DTV station is displayed. If no signal is received for 5 minutes, the TV will automatically activate sleep mode.
Page 35: Parental Menu
DYON SMART 42 XT V2 Description of the individual menu items OSD Language Select the OSD Language Audio Languages Subtitle Teletext Language HbbTV Support On / Off Network DTV Time Setup Here you can set time settings such as Time Zone,...
Page 36: About Menu
DYON SMART 42 XT V2 Description of the individual menu items Lock broadcasting Off / On system Lock the System (Password 0000) Channel Block Certain content can be blocked according to availability Age Rating None / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 11 / 12...
Page 37: Smart Functions
DYON SMART 42 XT V2 12 Smart Functions Press the HOME button to open the Smart Functions. Netflix, Prime Video and YouTube can be opened directly via the respective buttons. Navigation is possible via the arrow buttons and the OK button to confirm.
Page 38: Ci+ Information
DYON SMART 42 XT V2 13 CI+ Information The TV set contains a Common Interface CI+ Slot. Different CAM cards with Smart card reader can be found at local dealers for different Pay-TV provider. • Set in: Turn off the TV. Now insert the module.
Page 39 DYON SMART 42 XT V2 Important Menu options and existing setting points depend on the CI+ module you are using. The CI+ module (not included in the scope of delivery) is necessary to be able to receive encrypted stations using a smart card (not supplied).
Page 40: Usb Devices
DYON SMART 42 XT V2 14 USB Devices 14.1 Connecting USB devices This device is provided two USB ports for updating the software and playing media files. Please connect USB media directly to the USB interface of the device. If this is not possible, please use only connection cables that are not longer than 25cm.
Page 41: Video Playback
DYON SMART 42 XT V2 14.2 Video Playback buttons or / buttons. A Select a media file with the / preview image is displayed. Press the ► button (at the bottom of the remote control) to play the media file in full screen mode.
Page 42: Troubleshoouting
DYON SMART 42 XT V2 15 Troubleshoouting If you have any problems with this device or installation, please refer again carefully to the relevant section in this manual and read details in the table below. 15.1 Error Notes Display Possible cause...
Page 43 DYON SMART 42 XT V2 Check the input The reception is source using the disturbed, the antenna SOURCE button. cable is not Check the antenna connected, an unused cable. No Signal reception path has In TV mode, press been selected, or the...
Page 44: No Sound / No Picture
DYON SMART 42 XT V2 15.2 No sound / no picture Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction or connection Ghost Normal audio electronic equipment, car/motorcycle, fluorescent light Interfere Noise...
Page 45: Specifications
DYON SMART 42 XT V2 16 Specifications Frequency Range 46.25MHz ~ 863.25MHz 75Ω Input impedance Video System PAL, SECAM Sound System BG, DK, I, NICAM/A2 (PAL, SECAM) Teletext 1000Pages Max. Number of 99CH channels Frequency Range VHF (174MHz ~ 230 MHz) UHF (474MHz ~ 862 MHz) 75Ω...
Page 46 DYON SMART 42 XT V2 Product information about the energy efficiency of this device according to EU regulation (EU) 2019/2013 can be found on the following website of the European Union from 1 of March 2021. To open, please scan the following QR code with your...
Page 47 DYON SMART 42 XT V2 Maximum transmission power Function Frequency (MHz) Output power (dBm) 2412-2472 (802.11b/g) Wi-Fi 18.6 2412-2472 (802.11n(HT20)) 2412-2472 (802.11n(HT40)) Disposal This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of life separately from your household waste.
Page 48: Glossar
DYON SMART 42 XT V2 17 Glossar DiSEqC Digital Satellite Equipment Control Digital system, with which the receiver can control different components of the external unit. It is especially used for selecting from multiple satellite positions (for example Astra and Eutelsat).
Page 49: Warranty Condition
Axdia International GmbH, Hanns-Martin-Schleyer-Straße 36-38, 47877 Willich, hereinafter referred to as AXDIA, grants to consumers for products of the brands ODYS and DYON hereinafter referred to as product a limited warranty represented by the following warranty conditions. By this warranty, AXDIA...
Page 50 DYON SMART 42 XT V2 5. The warranty claim does not apply if repairs or other work is carried out by unauthorized persons or if our products are equipped with additional parts or accessories that are not approved for our products.
Page 51 DYON SMART 42 XT V2 Please observe the following when sending the product: 1. The shipment should be sent in with sufficient postage and insurance, and suitable for transport. The original accessories, such as USB cable and mains adaptor for example, must be enclosed with the product unless otherwise specified by the AXDIA Service Centre.
