VMI Vision System
VVS (OL82)
Technical Manual
Version
Revision no.
Issue date
VVSX 13.0.12.0, VVSU 3.0.6
4
2016-07-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VVS OL82 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VMI VVS OL82

  • Page 1 VMI Vision System VVS (OL82) Technical Manual Version VVSX 13.0.12.0, VVSU 3.0.6 Revision no. Issue date 2016-07-11...
  • Page 2 This page has been left blank intentionally.
  • Page 3 VMI retains the intellectual property rights of the software, as mentioned above. VMI shall not be obliged to provide the source code for the software, as mentioned above. VMI shall not be obliged to provide the buyer with updated versions of software, as mentioned above, or software updates as released by any of the third‑party suppliers of VMI.
  • Page 4 VMI Holland BV will evaluate machine performance and correct information during the contract period, provided that such concerns are reproducible, have been reported to VMI in writing and are acknowledged by VMI. The end user will render all reasonable assistance to correct the concerns.

  • Page 5: Table Of Contents

    Adjust and focus the camera ........5.3.3 Calibrate the camera ..........5-14 5.3.4 Calibrate the actuator ..........5-17 5.3.5 Calibrate the encoder ..........5-23 VVS Tread ................5-25 THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 6 Tread read profile command sequence ..... 6-31 6.8.4.2 Tread centering command sequence ....6-32 6.8.5 EMERGENCY STOP recovery sequence ....6-32 6.8.6 HEARTBEAT sequence .......... 6-33 THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 7 Holes in the body-ply are detected by the camera .. 8-27 8.6.3 Deviation between measured and actual bodyply 8-28 width (only for 24x) ..........THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 8 Upgrade camera firmware ............8-33 8.9.1 Check the current camera firmware version ... 8-33 8.9.2 Upgrade the camera firmware ......... 8-34 Index ..................... THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 9: About This Manual

    Chapter About this manual About this manual Section Page General Audience Abbreviations THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 10 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 11: General

    ABOUT THIS MANUAL General General This is a specialist manual for the VMI Vision System (VVS) and it applies to VVS installed on the standard VMI IPC plaform. VVS is installed on the following VMI machines: MAXX EXXIUM VAST / MILEXX Tread –...

  • Page 12: Audience

    ● Configuration ● Maintenance ● Alignments, adjustments and calibrations Operator information for VVS is described in the technical manual of the installation. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 13: Abbreviations

    VMI All Steel Truck tire building machine Veluwse Machine Industrie VMI Vision System VVSC VMI Vision System Carcass VVSU VVS User interface software VVSX VVS Controller software THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 14 ABOUT THIS MANUAL Abbreviations This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 15: Safety

    Chapter Safety Safety Section Page General THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 16 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 17: General

    SAFETY General General Refer to the machine manual for machine specific safety instructions. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 18 SAFETY General This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 19: Installation And Configuration

    Chapter Installation and configuration Installation and configuration Section Page Installation Configuration THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 20 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 21: Installation

    Insert the installation CD in the laptop. Open the directory <CD-root-dir>\Software\VMI\VVSU\vx.x.x\setup. Run setup.exe. Click OK. Check the destination directory and click the install icon button. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 22 INSTALLATION AND CONFIGURATION Installation Check the program group and click CONTINUE. The VVSU setup starts. Click OK. If necessary, create a desktop shortcut to VVSU. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 23: Configuration

    A dialog box opens. In the dialog box select the configuration file (VMI.OPF). If you do not have a valid VMI.OPF file available; go to the next page to configure this file. In general all settings are ready to use except for the IP address of the PLC that the OPC server will communicate with.

  • Page 24: Configure The Opc Wrapper File

    The VMI_OPCSERVER_WRAPPER.INI consists of a number of sections starting with a title between square brackets ([]). The file always starts with a general section [GENERAL] followed by a number of product sections. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 25 Status information is always send from VVSX to PLC, so this bit is always 0 (false). Check the Active statements of all components. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 26: Opc Wrapper Address Definition

    The measurements can be in random order. It is recommended to keep a logical order and to group the measurements for one component by a comment line. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 27 200 camera samples (every 1 second), the measurement values are sent. This configuration is intended for systems that do not use an encoder. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 28: Carcass Measurement Options

    Check the reuse of encoders Save the VVSConfig.ini file. ‑ 11. For more information, refer to the paragraph VVS Config file definitions on page 3 THINKING FORWARD 3-10 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 29: Vvs Config File Definitions

    INSTALLATION AND CONFIGURATION Configuration 3.2.5 VVS Config file definitions The standard setup of the VVSConfig.ini file looks as follows: THINKING FORWARD 3-11 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 30 ● 0: New breaker will be centered depending on previous measured breaker width. ● 1: New breaker will be centered depending on breaker width parameter. THINKING FORWARD 3-12 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 31 The CAN addresses must correspond with the address settings on the devices (For more information, refer to the paragraph Addresses of all devices in the CAN ‑ 15). network on page 3 THINKING FORWARD 3-13 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 32 BREAKER1 = Stock roll 2 In this example, the name 'Stock roll 2' appears between brackets behind the conveyor name wherever it appears. THINKING FORWARD 3-14 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 33 Actuator Breaker 1 How to set the address of actuator RK4004 Actuator Breaker 2 How to set the address of actuator RK4004 THINKING FORWARD 3-15 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 34: How To Set The Address Of Actuator Rk4004

    How to set the address of actuator RK4004 The address can be set as follows: ● Using Java Canmon ● Directly on the actuator controller THINKING FORWARD 3-16 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 35 The device number is indicated above the Wait approximately 20 seconds. The new device address will be saved and a software reset is triggered. THINKING FORWARD 3-17 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 36: How To Set The Address Of Beckhoff Bk5120

    Select the device for which you want to adjust the CAN address [2]. Go to the SET ADDRESS tab [3]. Enter the new device address [4]. Click the SET ADDRESS button [5]. THINKING FORWARD 3-18 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 37: How To Set The Virtual Address Of The Camera

    Select LOGIN and press ENTER. Change user to ADMIN. Press LOGIN [F4]. Use the BACK button to navigate back to the main menu. THINKING FORWARD 3-19 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 38 ● For VVS Breaker, select both camera check boxes. ● For VVS Tread, select the CAM1 check box and clear the CAM2 check box. THINKING FORWARD 3-20 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 39: Functional Description

    Chapter Functional description Functional description Section Page General System architecture VVS Software Camera types THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 40 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 41: General

    General General The VMI Vision System (VVS) is used to center breaker, carcass, and tread material before application of the material to the Tire Building Machine (TBM) drums. For this function it is connected to the TBM central controller (the PLC). From the PLC, VVS receives commands, and VVS sends feedback on the centering result to the PLC.

  • Page 42: System Architecture

    For special applications, it can be configured so that one camera set monitors two breakers. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 43 System architecture 4.2.3 MAXX / EXXIUM System diagram of VVS breaker and tread centering on a VMI MAXX / EXXIUM passenger tire building machine: THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 44: Vast / Milexx

    2 VVS cameras measure 4 breaker conveyors with 4 actuators. System diagram of VVS breaker centering on a VMI truck tire building machine: THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 45: Vvs Software

    VVS Controller. NOTICE VVSU has no copy protection. Copies of the program may be used without license agreement. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 46: Camera Types

    Applicable to breaker 1 and 2. Applicable to breaker 1, 2, 3, and 4. MAXX tire building machines use a VMI3D application with Matrix Vision BlueLYNX cameras (VVSC). THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 47: Alignments, Adjustments And Calibrations

    Chapter Alignments, adjustments and calibrations Alignments, adjustments and calibrations Section Page Tooling Connect to VVS VVS Breaker 5-25 VVS Tread 5-33 VVS Carcass THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 48 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 49: Tooling

    * For VMI part numbers of the tools, refer to mechanical drawing "Alignment tooling". Tools supplied by the customer Description Illustration Laptop Spirit level Wrenches Allen wrenches THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 50: Connect To Vvs

    VVSU connects to the selected VVSX server and starts the main VVSU screen. Go to the SELECT menu and select the correct camera position. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 51: Vvs Breaker

    Use the camera connector [2] as a reference relative to the material direction [1]. The camera connector must be on the left when you look in the direction of the material. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 52 Use a spirit level. [1] The camera image in the VVSUDISPLAY SENSOR tab should be acceptable, if not, adjust with adjustment screw [C]. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 53: Adjust And Focus The Camera

    When the gray lens filter (B&W type 103) is mounted on the lens cover, you must place or hold the cover on lens to check the camera image. Example - underexposed image: THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 54 If necessary, use the adjustment screws [A], [B, [C] to adjust the camera image. The following illustrations show a simplified display view when the camera is not aligned. Adjustment screw [A]: THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 55 ALIGNMENTS, ADJUSTMENTS AND CALIBRATIONS VVS Breaker Adjustment screw [B]: Adjustment screw [C]: THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 56 Turn the focus ring [3] until the narrow spikes almost have the same intensity as the baseline in the DISPLAY SENSOR screen. THINKING FORWARD 5-10 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 57 Example - bad focus image: Example - good focus image: THINKING FORWARD 5-11 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 58 ● Change the value of Start Service to 10 and pres ENTER. ● Click TRANSMIT to send the values to VVSX. After a few seconds the value returns to 0. THINKING FORWARD 5-12 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 59 Use the mouse pointer in DISPLAY SENSOR to determine the intensity. Example - food focus image (white balance on): 16. Fix the adjustment screws [A], [B, [C] settings with the lock nuts. THINKING FORWARD 5-13 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 60: Calibrate The Camera

    Select SENSOR in the SELECT ITEM TO CALIBRATE drop‑down box. Enter the template width in the TEMPLATE WIDTH (MM) field. Enter thickness 0 in the MATERIAL THICKNESS (MM) field. THINKING FORWARD 5-14 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 61 Actuator calibration on page 5 If the LEFT VALUE and RIGHT VALUE difference is not within the tolerance of 2 mm, proceed with the next step. THINKING FORWARD 5-15 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 62 ● Move the camera in such direction that the LEFT VALUE and RIGHT VALUE is within the tolerance of 2 mm. ● Fasten the screws (4x). 11. Repeat the calibration from step 7. THINKING FORWARD 5-16 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 63: Calibrate The Actuator

    Click FILE > REFRESH PARAMETERS and check the values in the ACTUATOR tab screen. In VVSU, go to tab STATUS. Select Jog right. THINKING FORWARD 5-17 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 64 20. In the SELECT ITEM TO CALIBRATE drop‑down menu, select ACTUATOR. 21. Click START CALIBRATION to start the actuator calibration (determine the motor type). Wait for the Calibration OK message. THINKING FORWARD 5-18 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 65 Select Home Conveyor. 30. Go to the conveyor and measure the deviation of the heart line in respect to1BCV (2BCV) relative to 1BAR (2BAR). THINKING FORWARD 5-19 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 66 34. In VVSU, go to tab ACTUATOR. 35. Change the value of Zero Offset to 10 and press ENTER. THINKING FORWARD 5-20 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 67 If this is not the case, the Motion Range and Pos Range must be adjusted and the calibration must be repeated, starting with adjusting the parameter settings. THINKING FORWARD 5-21 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 68 ● Wait 30 seconds until the actuator is back online. 54. Click FILE > REFRESH PARAMETERS and check the values in the ACTUATOR screen. THINKING FORWARD 5-22 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 69: Calibrate The Encoder

    Move the applicator conveyor belt 1000 mm via the HMI or via motion direct command. In the CALIBRATION LENGTH (MM) field enter 1000. Click TRANSMIT to send the values to VVSX. THINKING FORWARD 5-23 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 70 Enter the value Counts Per Meter as noted in step 10 and press ENTER. 12. Click TRANSMIT to send the values to VVSX. THINKING FORWARD 5-24 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 71: Vvs Tread

    Use a spirit level. [1] The camera image in the VVSUDISPLAY SENSOR tab should be acceptable, if not, adjust with adjustment screw [C]. THINKING FORWARD 5-25 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 72 When the gray lens filter (B&W type 103) is mounted on the lens cover, you must place or hold the cover on lens to check the camera image. Example - simplified image: THINKING FORWARD 5-26 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 73 The following illustrations show a simplified display view when the camera is not aligned. Adjustment screw [A]: Adjustment screw [B]: Adjustment screw [C]: THINKING FORWARD 5-27 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 74 Place the calibration template on the conveyor belt, and make sure the text 'mm' is placed next to the center belt and the text 'mm' is shown as narrow spikes in the camera image (as illustrated). THINKING FORWARD 5-28 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 75 Use the mouse pointer in DISPLAY SENSOR to determine the intensity. 17. Fix the adjustment screws [A], [B, [C] settings with the lock nuts. THINKING FORWARD 5-29 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 76 Enter the template width in the TEMPLATE WIDTH (MM) field. Enter thickness 0 in the MATERIAL THICKNESS (MM) field. Click TRANSMIT to send the values to VVSX. THINKING FORWARD 5-30 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 77 If the LEFT VALUE and RIGHT VALUE difference is not within the tolerance of 2 mm, proceed with the next step. THINKING FORWARD 5-31 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 78 ● Move the camera in such direction that the LEFT VALUE and RIGHT VALUE is within the tolerance of 2 mm. ● Fasten the screws (4x). 11. Repeat the calibration from step 7. THINKING FORWARD 5-32 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 79: Vvs Carcass

    MAXX tire building machines use a VMI3D application with Matrix Vision BlueLYNX cameras (VVSC). For more information, refer to the VMI 3D Vision Backlight Width Monitor (BLWM) technical manual. THINKING FORWARD 5-33 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 80 ALIGNMENTS, ADJUSTMENTS AND CALIBRATIONS VVS Carcass This page has been left blank intentionally. THINKING FORWARD 5-34 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 81 Section Page General Parameter buffer 6-14 Command buffer 6-16 Status buffer 6-22 System parameters 6-26 Actuator parameters 6-27 Sensor parameters 6-29 Communication scenarios THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 82 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 83: General

    This chapter describes the parameters used in communication between the PLC and VVS. NOTICE System parameters of VVS itself are described in Operation. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 84: Parameter Buffer

    Splice correction 4/9 0.1 mm Splice correction 5/9 0.1 mm Splice correction 6/9 0.1 mm Splice correction 7/9 0.1 mm Splice correction 8/9 0.1 mm THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 85 The correction is linear decreasing from tip correction value at the tip to zero at Tip Correction Length distance from the tip. Tip Correction Length is equal for both leading and trailing end. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 86 Detected material smaller than the Obstruction width is ignored, to avoid that breaker centering is started by the support beam instead of the breaker material. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 87 Side guiding (Algorithm selection = 0%) In the Leading End and Trailing End, the centering set point is the straight edge of the breaker material. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 88 ● -1% = guiding is not active, material clamps are functioning. ● -2% = guiding is not active, material clamps are not functioning. 6.2.1.7 Material scan example THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 89 Apply a breaker on the B&T drum. Check the splice. Total splice First correction Measure the opening, at an angle of 90 degrees to the transport direction. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 90 Offset Sidewall 0.1 mm Sidewall width 0.1 mm Sidewall outer tolerance 0.1 mm Sidewall inner tolerance 0.1 mm Sidewall tilt tolerance 0.1 mm THINKING FORWARD 6-10 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 91 The measured material width is the running average over 21 samples. When the measured material width is outside the tolerance, an error message is given. THINKING FORWARD 6-11 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 92 Spare Spare Spare Thickness 0.1 mm Tread width 0.1 mm Spare Tread outer tolerance 0.1 mm Tread inner tolerance 0.1 mm Spare THINKING FORWARD 6-12 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 93 From this the 'counts per meter' is calculated. ‑ 23. For more information, refer to the paragraph Encoder calibration on page 5 THINKING FORWARD 6-13 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 94: Command Buffer

    Switch to trailing end Only Breaker Spare Calibrate encoder Encoder calibration for Breaker and Tread (C) Hold conveyor Clear width compensation Clear width difference compensation THINKING FORWARD 6-14 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 95 Commands from the PLC grafcets lead to a change of state in this register, signaling the VVS system that new command data is available. THINKING FORWARD 6-15 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 96: Status Buffer

    When calibrate command is high, this bit becomes high until calibrate command is withdrawn or the product parameters are send with a Calibration Length parameter > 0. THINKING FORWARD 6-16 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 97 This signal changes state every second. PLC should timeout after 2 2 seconds. seconds. If heartbeat restarts after a timeout, product parameters should be send to the VVS system. THINKING FORWARD 6-17 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 98 This bit is set when the moving average of 20 samples exceeds the tolerance. Sensor 1 overexposed A, B Refer to remarks. Sensor 2 overexposed A, B, C Refer to remarks. THINKING FORWARD 6-18 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 99 VVS is set to 2 seconds and is reset when this status has been received. When the timer times out, this bit is set. THINKING FORWARD 6-19 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 100 The breaker average width is based on the last 150 camera width measurements (in the body). The average length and the average width are valid after a centering ready (when a centering cycle is finished). THINKING FORWARD 6-20 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 101 If split breaker material is handled, the words in the extended status (13, 14 and 15) are used. For 'normal' breaker material, word 7 in the actual position measurements is used. THINKING FORWARD 6-21 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 102: System Parameters

    Body‑D Normal Differential Gain. D Parameters of the same loop controller. THINKING FORWARD 6-22 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 103 Fault Percentage Fault percentage. 100 % THINKING FORWARD 6-23 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 104 How to measure the mechanical gain for a tread server The illustration shows the mechanical gain as the quotient of two measurements (1000 x A/B). THINKING FORWARD 6-24 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 105 System parameters 6.5.3.2 How to measure the camera to end conveyor distance The parameter camera to end conveyor distance is measured as follows. THINKING FORWARD 6-25 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 106: Actuator Parameters

    Position I I component for the internal speed controller. Position D D component for the internal speed controller (not implemented in RK4004). THINKING FORWARD 6-26 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 107: Sensor Parameters

    Third digit indicates lighting errors: ● 0 = optimum lighting ● 1 = soiled ● 2 = under-exposed ● 3 = over-exposed THINKING FORWARD 6-27 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 108 End point of Region Of Interest. xxxx pixels Exposure Sets the height of the illumination curve shown Setpoint with DISPLAY SENSOR tab. THINKING FORWARD 6-28 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 109: Communication Scenarios

    HMI should display error message "VVS did not start conveyor homing" Operator should press the RESTART button Zero command Restart the HOME command sequence END IF THINKING FORWARD 6-29 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 110 HMI should display error message "VVS did not start conveyor centering" Operator should press the RESTART button Zero command Restart the CENTERING command sequence END IF THINKING FORWARD 6-30 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 111 Zero command Zero status ZERO STATUS is the situation where all bits, except the heartbeat bit, are set to zero. THINKING FORWARD 6-31 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 112 E-STOP while material is under the sensor. Instead raise the HOLD bit and continue centering after having cleared the HOLD bit. THINKING FORWARD 6-32 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 113 HMI should display error message "VVS system down" VVSDown = true END IF IF Not Time-out(HeartbeatTimer) AND VVSDown THEN VVSDown = false PLC send parameters END IF THINKING FORWARD 6-33 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 114 PARAMETERS Communication scenarios This page has been left blank intentionally. THINKING FORWARD 6-34 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 115 Chapter VVSU Operation VVSU Operation Section Page General Start VVSU Screen layout (generic) THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 116 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 117 Depending on the configuration and the software version, the actual screens and functions may have a different layout and values than shown in this chapter. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 118: Start Vvsu

    VVSU connects to the selected VVSX server and starts the main VVSU screen. OFFLINE VVS offers the possibility of using VVSU without a connection to a VVSX server. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 119: Screen Layout (Generic)

    Control the program with a touch screen. Entering values is done by a numeric pop-up screen. Demo mode Not applicable. Debug log Not applicable. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 120 For example, Breaker 1 [first breaker] Exit Exit the VVSU program. The VVSX server is not shut down. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 121 The user name on the VVSX Server username with administrator rights. Default user names are: ● vmi (for WES7 VVS IPCs) ● administrator (for WES2009/XPE VVS PCs) THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 122 Select the conveyor of interest. An alias can be added to the name of the conveyor (refer to FILE > OPTIONS). THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 123: Interface Status

    Shows the connection path (for example, \\172.16.1.10\Vvs). Shows the selected material (for example, Breaker 1 [BREAKER 1]). Shows the current time. Shows the current date. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 124: Screen Selection

    Shows the most recent material scan when entered. History Scan data Shows the contents of the selected conveyor data folder. Screens for specialists only. THINKING FORWARD 7-10 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 125 Click the check box to toggle a bit. Shows the bit history. With every change of a status bit (except for the heartbeat) these columns move right. THINKING FORWARD 7-11 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 126 Click YES to switch the log option on. To remove the messages from the errors field: Right-click in the SENSOR / ACTUATOR ERRORS field [3]. Select REMOVE ALL. THINKING FORWARD 7-12 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 127: Calibration Screen (For Advanced Users Only)

    A right-click on the calibration data fields opens a shortcut menu with copy/paste options. Actual values Shows the actual values of the item to be calibrated. Start Calibration Click to start the calibration. THINKING FORWARD 7-13 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 128 Select the item to calibrate [1]. Enter the required information in the calibration data fields [2]. Click TRANSMIT [5]. Click START CALIBRATION [4]. THINKING FORWARD 7-14 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 129: System Screen (For Advanced Users Only)

    Select the SYSTEM tab. Enter the required values for the parameters that you want to modify. Click TRANSMIT to transmit the parameters to the PLC. THINKING FORWARD 7-15 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 130: Material Screen (For Advanced Users Only)

    Refer to Parameter buffer on page 6 To modify material parameters: Click SELECT, in the VVSU menu bar. Select the required material conveyor. Select the MATERIAL tab. THINKING FORWARD 7-16 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 131: Actuator Screen (Only For Advanced Users)

    Select the ACTUATOR tab. Enter the required values for the parameters that you want to modify. Click TRANSMIT to transmit the parameters to the PLC. THINKING FORWARD 7-17 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 132: Display Sensor Screen

    Range: 0 ‑ 255 Attributes Right-click for an attribute select shortcut menu. In the shortcut menu the background color and line width can be selected. THINKING FORWARD 7-18 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 133: Material Scan Screen

    Left‑click to get a vertical cursor on the material scan field at the position of the mouse pointer. In the top of the field the positions of the edges, width and error appear. THINKING FORWARD 7-19 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 134 Width set point Angle set point History Press this button to see the data of the last 100 scans in a pop- up window. THINKING FORWARD 7-20 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 135 Click on the column header for alpha-numeric sorting of the selected column. An arrow appears in the column header. Click again to reverse the sorting order. THINKING FORWARD 7-21 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 136: Sensor Screen (For Advanced Users Only)

    Select the SENSOR tab. Enter the required values for the parameters that you want to modify. Click TRANSMIT to transmit the parameters to the PLC. THINKING FORWARD 7-22 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 137: History Scan Data Screen

    VVSU OPERATION Screen layout (generic) 7.3.4.9 History scan data screen Shows the contents of the selected conveyor data folder. THINKING FORWARD 7-23 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 138 VVSU OPERATION Screen layout (generic) This page has been left blank intentionally. THINKING FORWARD 7-24 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 139: Troubleshooting

    8-14 CAN-bus problems 8-16 Breaker centering problems 8-20 Guiding problems 8-26 Calculation problems 8-30 Mechanical problems 8-31 Calibration problems 8-33 Upgrade camera firmware THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 140 This page has been left blank intentionally. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 141: Communication

    If your network includes a router, then the VVSU client broadcast will be stopped by the router. If this is the case you can connect using CONNECTION > CONNECT from the VVSU menu bar. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 142: Setting The Priority Of The Network Card

    VVSU shows an error while attempting to connect to the VVSX server NOTICE This is only applicable for Windows XP Embedded VVS PCs. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 143 The VVSU client makes a network drive mapping to the VVS server. The user name and the corresponding password which are used to make the network drive mapping are shown in the connection settings form (CONNECTION > SETTINGS...). THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 144 Right mouse-click on the VVSX folder and select the function Properties in the drop- down menu. Select the SHARING tab and press the PERMISSIONS button. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 145 TROUBLESHOOTING Communication Make sure FULL CONTROL is checked for the account which is used by the VVSU client. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 146 Go to the computer on which VVSU is installed. Start the WINDOWS EXPLORER. Select the TOOLS tab and the function MAP NETWORK DRIVE. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 147 If the network drive mapping fails, check if the workstation service is running on the VVS server. ● This workstation service provides the ability of the VVS server to share a directory over the network. THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 148 TROUBLESHOOTING Communication THINKING FORWARD 8-10 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 149: Device Detection At Startup

    Check the actuator address (using Java Canmon) and make sure that the actuator address specified in the VVSConfig.ini is the same as the one shown in Java Canmon. THINKING FORWARD 8-11 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 150: Camera Version Retrieval Error

    When this heartbeat is not received for at least 4 seconds, an alarm will be send to the PLC. Cause: No encoder detected due to: ● Configuration error. ● Encoder address error THINKING FORWARD 8-12 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 151 ● Turn the power on again. ● Restart VVS. ● Check if the initialization of the BK5120 module was successful. The run led should be uninterrupted green. THINKING FORWARD 8-13 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 152: Can-Bus Problems

    VVSConfig.ini (Encoder inhibit time = VVSConfig value (HEX) × 0.1 ms). Changes made in the VVSConfig.ini will take effect after restart of VVS. THINKING FORWARD 8-14 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 153 Perform a scan of the Canbus network. Compare the devices found by Java Canmon on the Canbus network with the device specified in the VVSConfig.ini. THINKING FORWARD 8-15 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 154: Breaker Centering Problems

    After which it will automatically switch to TE center mode. Solution: Make sure that the PLC sends the switch to TE command on time. THINKING FORWARD 8-16 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 155: Breaker Centering Switches Too Early To Body Center Mode

    VVS can calculate the start of the body. Using this info it will automatically switch to Body centering (only if TBM has encoder). Solution: Make sure the 'parameter width' reflects the material width. Check the width tolerance. THINKING FORWARD 8-17 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 156: Only Half Of The Breaker Is Seen In The Material

    The camera is not well focused. This results in camera samples indicating 'no material', while there is still breaker materials under the camera. THINKING FORWARD 8-18 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 157: Sometimes Side Guiding Is Applied When Splice Guiding Is Selected

    Refer to Check the current camera firmware version on page 8 firmware version of the camera. Refer to the VVS Upgrade Manual for upgrade instructions. THINKING FORWARD 8-19 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 158: Guiding Problems

    VVS will not guide the material, because it just finished the centering cycle and waits for a new PLC command. THINKING FORWARD 8-20 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 159 ● The VVS system can also be made less sensitive to disturbances by setting the 'No Material counter' to 3 (in VVSConfig.ini). This setting takes effect after restarting VVS. THINKING FORWARD 8-21 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 160: Splice Guiding Is Not Working

    It should be noted that the best splice guiding is obtained by setting the 'Encoder inhibit time' to 0 (maximum encoder messages sent as possible). THINKING FORWARD 8-22 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 161: Homing Problem (Rk4004)

    After camera calibration the error code will indicate normal operation (error code 20) and the actuator guiding is resumed. Details about the error codes used by the camera can be found in the Erhardt+Leimer documentation. THINKING FORWARD 8-23 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 162: Correction Overshoot

    'exposure setpoint', thereby resulting in a delay of the camera samples. Solution: Lower the 'Exposure Setpoint' to 200/180: Start VVSU. Go to the SENSOR tab. Adjust the Exposure Setpoint to 200/180. THINKING FORWARD 8-24 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 163 TROUBLESHOOTING Guiding problems THINKING FORWARD 8-25 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 164: Calculation Problems

    Depending on the tip position of the breaker, the angle should be positive or negative. The illustration shows what the angle sign should be. When material angle is positive, the THINKING FORWARD 8-26 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 165: Holes In The Body-Ply Are Detected By The Camera

    Sometimes the body‑ply contains holes which are seen by the camera. This results in a minor deviation of the calculated move to position. THINKING FORWARD 8-27 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 166: Deviation Between Measured And Actual Bodyply Width (Only For 24X)

    5 Width measurements by the camera in Body-ply position could have a deviation due to the material-to-camera distance. THINKING FORWARD 8-28 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 167 In order to make sure that the calibration is successful, a template of 800 mm is put underneath the two camera system. Using VVSU you can check the width measured by the camera. THINKING FORWARD 8-29 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 168: Mechanical Problems

    Conveyor should stay out of the camera field. Make sure that the camera alignment is done in such a way that the camera does not see the cutter conveyor when the conveyor is in its outer limits. THINKING FORWARD 8-30 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 169: Calibration Problems

    If this error is no longer present, the display will indicate the next error. THINKING FORWARD 8-31 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 170 Several reference switch errors detected. end switch error End position proximity switches incorrectly configured. 24 V ext. fault External supply voltage overloaded. THINKING FORWARD 8-32 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 171: Upgrade Camera Firmware

    If there is a newer firmware version available, upgrade the OL82 camera firmware as ‑ 34. described in Upgrade the camera firmware on page 8 THINKING FORWARD 8-33 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 172: Upgrade The Camera Firmware

    Do not unpack the *.tgz file and make sure that the SD memory card contains only one *.tgz file. Place the SD memory card back in the slot [2]. THINKING FORWARD 8-34 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 173 INFO [1] and ESCAPE [2] buttons simultaneously, until the following screen appears on the display [4] (after approximately 10 seconds). THINKING FORWARD 8-35 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 174 10. Set the cameras to the default settings (refer to Set cameras to default). Applicable when the new firmware contains new default settings. 11. Calibrate the VVS camera system. THINKING FORWARD 8-36 VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

  • Page 175: Index

    Configure the CAN network 3‑15 Configure the Kepware OPC Server 3‑5 Configure the number of cameras on the CAN bus 3‑19 Configure the OPC wrapper file 3‑6 THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 176 Install VVSU on a maintenance PC 3‑3 Installation 3‑3 Installation and configuration 3‑1 Intellectual property ‑ii Interface Status 7‑9 Interfering ambient light 8‑19 THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 177 System architecture 4‑4 System parameters 6‑22 System screen (for advanced users only) 7‑15 The camera does not have the right set of parameters 8‑31 THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...
  • Page 178 VVSU Operation 7‑1 VVSU shows an error while attempting to connect to the VVSX server 8‑4 Width and width tolerances 6‑11, 6‑13 World-wide support ‑i THINKING FORWARD VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592...

Table of Contents
