DCP-330C
DCP-540CN
Before you can use the machine, you must set up the hardware and install the software.
Please read this Quick Setup Guide for the correct setup procedure and installation instructions.
Installing the Driver & Software
Keep this Quick Setup Guide, the User's Guide and the supplied CD-ROM in a convenient place for
quick and easy reference at all times.
STEP 1
Setting Up the Machine
STEP 2
Setup is Complete!
Advertisement
Table of Contents
Related Manuals for Brother DCP-540CN
Summary of Contents for Brother DCP-540CN
- Page 1 DCP-330C DCP-540CN Before you can use the machine, you must set up the hardware and install the software. Please read this Quick Setup Guide for the correct setup procedure and installation instructions. STEP 1 Setting Up the Machine STEP 2 Installing the Driver &...
-
Page 2: Setting Up The Machine
STEP1 Setting Up the Machine Removing the protective Loading paper parts Pull the paper tray completely out of the machine and lift the output paper tray cover (1). Remove the protective tape and film covering the scanner glass. Remove the foam bag containing the ink cartridges from on top of the paper tray. - Page 3 STEP1 Setting Up the Machine Check that the paper is flat in the tray. Slowly push the paper tray completely into the machine. Gently adjust the paper side guides with both hands and the paper length guide to fit the paper.
-
Page 4: Connecting The Power Cord
Setting Up the Machine Connecting the power cord Installing the ink cartridges Connect the power cord. Warning If ink gets in your eyes, wash them out with water Improper Setup at once, and if irritation occurs consult a doctor. DO NOT connect the interface cable. The LCD shows: Connecting the interface cable is done during the software installation process. - Page 5 STEP1 Setting Up the Machine Note Do not throw away the yellow protective part. You will need it if you transport the machine. brother XXXX Cleaning i i i i i Preparing System Approx 4 Minutes...
-
Page 6: Print Quality Check
Setting Up the Machine The LCD asks you if the print quality is OK for Print quality check black and colour. Press (Yes) or (No). Black OK? Yes iPress Set Paper and Press iPress Color OK? Make sure paper is loaded in the paper tray. Yes iPress Press Colour Start. -
Page 7: Setting The Lcd Contrast
STEP1 Setting Up the Machine Press a repeatedly to enter the two digits for Setting the LCD contrast the day, and then press OK. Date/Time Press Menu. Day: Press a or b to choose General Setup. Press OK. Press a or b to choose LCD Settings. Press OK. -
Page 8: Installing The Driver & Software
Follow the instructions on this page for your operating system and interface. For the latest drivers and documentations and to find the best solution for your problem or question, access the Brother Solutions Center directly from the driver or visit http://solutions.brother.com. -
Page 9: For Usb Interface Users
The installation of PaperPort SE will automatically start and is followed by the installation of MFL-Pro Suite. When the Brother MFL-Pro Suite Software License Agreement window appears, click Yes if you agree to the Software License Agreement. Choose Standard (DCP-330C) or Local Connection (DCP-540CN), and then click Next. - Page 10 ® Windows Turn on the machine by connecting the power cord. The installation of the Brother drivers will automatically start. The installation screens appear one after another. Please wait, it will take a few seconds for all screens to appear.
- Page 11 STEP2 Installing the Driver & Software ® Windows For Network Interface Users (DCP-540CN only) ® (For Windows 98/98SE/Me/2000 Professional/XP/XP Professional x64 Edition) Disconnect the machine from the power socket. Turn on the machine by connecting the power cord. Turn on your computer.
- Page 12 Software License Agreement. Choose Network Connection, and then click Next. The installation of the Brother drivers will automatically start. The installation screens appear one after another. Please wait, it will take a few seconds for all the screens to appear.
-
Page 13: For Usb Interface Users (For Mac Os ® X 10.2.4 Or Greater)
Note Please wait, it will take a few seconds for the software to install. After the installation, click Restart to finish installing the software. The Brother software will search for the Brother device. When this screen appears, click OK. ®... - Page 14 Choose USB. Choose DCP-XXXX (where XXXX is your model name), and then click Add. Click Print Center, then Quit Print Center. The MFL-Pro Suite, Brother printer driver, scanner driver and Brother ControlCenter2 have been installed and the installation is now complete.
- Page 15 Please wait, it will take a few seconds for the software to install. After the installation, click Restart to finish installing the software. The Brother software will search for the Brother device. Note • If the machine is configured for your network, choose the machine from the list, and then click OK.
- Page 16 ® For Mac OS X 10.2.x users, click Print Center, then Quit Print Center. The MFL-Pro Suite, Brother printer driver, scanner driver and Brother ControlCenter2 have been installed and the installation is now complete. • If you want to use the machine’s Scan key to scan over the network you must check the Register your computer with the “Scan To”...
- Page 17 The contents of this manual and the specifications of this product are subject to change without notice. Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.
- Page 18 EEU-ENG...
