3.1

Product structure

You can find information on possible device configurations and device options in the data sheet for
Type 5110 at
10
9
8
7
Fig. 1: MSU air/water
1 Water pressure controller
3 Controlled compressed air outlet
5 Pilot valve
7 Compressed air inlet
9 Compressed air filter
The water shut-off valve and the outlets for water (controlled and uncontrolled) are hidden in the diagram.
10
country.burkert.com
Type 5110
Product description
2 Compressed air pressure controller
4 Uncontrolled compressed air outlet (op-
tional)
6 Compressed air shut-off valve
8 Water inlet
10 Water filter
1
2
3
4
5
6
