Operating Instructions
LED TV
GX880H series
For more detailed instructions, please refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0419-0
(image: TH-75GX880H)
(p. 18)
English
TQB4GD0190
English
Advertisement
Table of Contents
Related Manuals for Panasonic GX880H Series
Summary of Contents for Panasonic GX880H Series
- Page 1 ● How to use [eHELP] (p. 18) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ··············································· 5 Accessories ························································ 7 Installing the TV ··················································· 8 Installing the wall-hanging bracket ··························· 9 Connections ·······················································10 Identifying Controls ··············································15 First time Auto Tuning···········································17 Watching TV·······················································18 How to Use eHELP ··············································18 FAQs ································································20 Maintenance ······················································21 Specifications ·····················································21... -
Page 3: Important Notice
(excerpted from our privacy policy). We do this to protect our customers and the integrity of our Service as well as to protect the rights or property of Panasonic. If you wish to know more about the processing of your information in this context, please refer to the full text of our privacy ●... - Page 4 Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf.
-
Page 5: Safety Precautions
Do not use an unapproved pedestal / mounting ● Insert the mains plug fully into the mains socket. equipment. Be sure to ask your local Panasonic ● To turn Off the apparatus completely, you must pull dealer to perform the setup or installation of approved the mains plug out of the mains socket. - Page 6 Do not use the pedestal if it becomes warped or Caution physically damaged. If this occurs, contact your ● nearest Panasonic dealer immediately. The TV uses the 2.4 GHz radio frequency ISM band (Bluetooth ). To avoid malfunctions or slow response ®...
-
Page 7: Accessories
■ Accessories Moving the TV Caution Before moving the TV, disconnect all cables. ● At least two people are required to move the TV to Standard accessories prevent injury that may be caused by the tipping or falling of TV. Remote Control (p. -
Page 8: Installing The Tv
Installing the TV Assembling the pedestal ● Insert the pedestal firmly, otherwise it may come off when setting up the TV. ● Do not assemble the pedestal by any method other Assembling / Removing the pedestal than those specified below. Pedestal Assembly screw (4) M4 ×... -
Page 9: Installing The Wall-Hanging Bracket
Installing the wall- hanging bracket Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ● Holes for wall-hanging bracket installation Rear of the TV 600 mm 300 mm (View from the side) Depth of screw minimum: 11 mm... -
Page 10: Connections
Connections Terminals ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ● Check the terminal type and cable plugs are correct for connection. - Page 11 ■ ■ Aerial Set top box RF cable HDMI cable Aerial Set top box ● For Digital TV, Analogue TV Satellite dish ● Keep RF (aerial) cable away from the mains lead to avoid and minimise mains interference pickup. Network ●...
- Page 12 ■ Camcorder / Game equipment ● Supporting HDR does not increase the peak brightness capabilities of the TV panel. (VIDEO equipment) ■ [HDMI Auto Setting] (Setup Menu) Reproduces the image more precisely with the expanded colour gamut when connecting the 4K compatible equipment.
- Page 13 ● Use HDMI2 to connect the TV to an amplifier which Cable arrangement has ARC (Audio Return Channel) function. Fix the cables using the cable clamp, cable tie, etc. and If connecting to an amplifier without ARC function, then attach the cable cover / terminal cover to the TV. use DIGITAL AUDIO OUT.
- Page 14 ■ ■ Fixing the cables using the cable tie Attaching the cable cover / terminal cover ● Be careful not to nip the cables between the TV and the cable cover / terminal cover. ● When using USB 2 port, USB 3 port, HDMI3 terminal or HDMI4 terminal, you cannot attach the cable cover.
-
Page 15: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays channel list. Remote Control 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ●... - Page 16 27 Aspect 4 Input mode selection ● ● Changes aspect ratio. Press repeatedly until you reach the desired mode. ■ [Main Menu] Installing / Removing batteries ● Press and hold for about 3 seconds to display main menu. OK (when in the menu system) Pull open 5 Channel Up / Down ●...
-
Page 17: First Time Auto Tuning
First time Auto Tick the TV signal mode to tune, and then select [Start Auto Tuning] ■ Tuning When you select the analogue TV signal, select your area. ● When selecting [CATV/Other], press the OK button, and then select the Channel Plan from Indian CATV, When the TV is turned on for the first time, it will South Africa, American System, American CATV or automatically search for available TV channels and give... -
Page 18: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... - Page 19 ● To scroll the description (if more than 1 page) While the description is highlighted ● To open the reference screen ( ● To display the menu related to the description (only for some descriptions) (red) ● To check the features of this TV Search by Purpose >...
-
Page 20: Faqs
● Check the mains lead is plugged into the TV and the mains socket. About the inquiry ● Please contact your local Panasonic dealer for The TV goes into Standby mode assistance. ● Auto power standby function is activated. If you make an inquiry from a place where this TV... -
Page 21: Maintenance
Maintenance Specifications ■ First, remove the mains plug from the mains socket. Model No. TH-75GX880H Display panel, Cabinet, Pedestal Dimensions (W × H × D) Regular care: Gently wipe the surface of the display panel, cabinet, 1 680 mm × 1 046 mm × 413 mm (With Pedestal) or pedestal by using a soft cloth to remove dirt or 1 680 mm ×... - Page 22 HDMI1 / 2 / 3 / 4 input UHF BAND TYPE A Connectors 21-69 (PAL G, H, I/SECAM G, K, K1) HDMI1 / 3 / 4: 4K, Content Type, Deep Colour, 28-69 (PAL B AUST.) x.v.Colour™ 13-57 (PAL D, K) HDMI2: 4K, Content Type, Audio Return Channel, 13-62 (NTSC M Japan) Deep Colour, x.v.Colour™...
- Page 23 Note ● Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate. ● For information about the open source software, refer to [eHELP] (Search by Purpose > Read first > Before use > Licence). ● TH-75GX880H complies with China Terrestrial Television National Standard (GB20600-2006) Mode-C=3780.
- Page 24 Warranty Service purposes. Model Number Serial Number English Web Site: http://www.panasonic.com Printed in Malaysia © Panasonic Corporation 2019 04-2019...
