Quick Start

Thank you for purchasing the MSI®
GAMING PLUS
motherboard. This Quick Start section provides demonstration
diagrams about how to install your computer. Some of the installations also provide
video demonstrations. Please link to the URL to watch it with the web browser on your
phone or tablet. You may have even link to the URL by scanning the QR code.

Preparing Tools and Components

Intel® LGA 1200 CPU
DDR4 Memory
Thermal Paste
Phillips Screwdriver
o cerca il tuo prodotto tra le
MPG Z590 GAMING EDGE WIFI/ MPG Z590
CPU Fan
Power Supply Unit
SATA Hard Disk Drive
A Package of Screws
migliori offerte di Schede Madri
Chassis
Graphics Card
SATA DVD Drive
MSI MPG Z590
1
Quick Start

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPG Z590 GAMING PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for MSI MPG Z590 GAMING PLUS

Summary of Contents for MSI MPG Z590 GAMING PLUS

  • Page 1: Quick Start

    Gaming Edge WIFI o cerca il tuo prodotto tra le migliori offerte di Schede Madri Quick Start Thank you for purchasing the MSI® MPG Z590 GAMING EDGE WIFI/ MPG Z590 GAMING PLUS motherboard. This Quick Start section provides demonstration diagrams about how to install your computer. Some of the installations also provide video demonstrations.

  • Page 2: Safety Information

    Safety Information ∙ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ∙ Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start.

  • Page 3: Case Stand-Off Notification

    Case stand-off notification Before installing the motherboard into the case, install first the necessary mounting stand-off required for a motherboard on the mounting plate in the case. To prevent damage to the motherboard, any unnecessary mounting stand-off between the motherboard circuits and the computer case is prohibited. The Case standoff keep out zone signs will be marked on the backside of motherboard (as shown below) to serve as a warning to user.

  • Page 4: Installing A Processor

    Installing a Processor ⚽ https://youtu.be/4ce91YC3Oww Quick Start...

  • Page 5: Installing Ddr4 Memory

    Installing DDR4 memory ⚽ http://youtu.be/T03aDrJPyQs DIMMA1 DIMMA2 DIMMA2 DIMMA2 DIMMB1 DIMMB2 DIMMB2 Quick Start...

  • Page 6: Connecting The Front Panel Header

    Connecting the Front Panel Header ⚽ http://youtu.be/DPELIdVNZUI Power LED Power Switch JFP1 Reserved HDD LED Reset Switch HDD LED + Power LED + HDD LED - Power LED - Reset Switch Power Switch JFP1 Reset Switch Power Switch Reserved No Pin HDD LED - HDD LED HDD LED +...

  • Page 7: Installing The Motherboard

    Installing the Motherboard ⚽ https://youtu.be/wWI6Qt51Wnc Torque: 3 kgf·cm* *3 kgf·cm = 0.3 N·m = 2.6 lbf·in Quick Start...

  • Page 8: Connecting The Power Connectors

    Connecting the Power Connectors ⚽ http://youtu.be/gkDYyR_83I4 ATX_PWR1 CPU_PWR1 CPU_PWR2 PCIE_PWR1 Quick Start...

  • Page 9: Installing Sata Drives

    Installing SATA Drives ⚽ http://youtu.be/RZsMpqxythc Quick Start...

  • Page 10: Installing A Graphics Card

    Installing a Graphics Card ⚽ http://youtu.be/mG0GZpr9w_A Quick Start...

  • Page 11: Connecting Peripheral Devices

    Connecting Peripheral Devices (MPG Z590 GAMING EDGE WIFI) Quick Start...

  • Page 12: Power On

    Power On Quick Start...

  • Page 13: Table Of Contents

    Contents Quick Start ......................1 Preparing Tools and Components................1 Safety Information ....................2 Case stand-off notification ..................3 Installing a Processor .................... 4 Installing DDR4 memory ..................5 Connecting the Front Panel Header ..............6 Installing the Motherboard ..................7 Connecting the Power Connectors ................
  • Page 14 Onboard LEDs ...................... 45 EZ Debug LED ....................... 45 LED_SW1: EZ LED Control ................... 45 JPWRLED1: LED power input ................45 Installing OS, Drivers & MSI Center ..............46 Installing Windows® 10 ..................46 Installing Drivers ....................46 MSI Center ......................46 UEFI BIOS ......................

  • Page 15: Specifications

    ∙ Supports Dual-Channel mode ∙ Supports non-ECC mode, un-buffered memory ∙ Supports Intel® Extreme Memory Profile (XMP) * Please refer www.msi.com for more information on compatible memory. ∙ 3x PCIe x16 slots ▪ Support x16/ x4/ x4 ▪ PCI_E1 (From CPU) ▫...
  • Page 16 ** SATA5 & SATA6 will be unavailable when installing M.2 SSD in the M2_3 slot. *** Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. ∙ Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA...
  • Page 17 Continued from previous page ∙ Intel® Z590 Chipset ▪ 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel ▪ 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A port on the back panel and 2 ports are available through the internal connectors) ▪...
  • Page 18 Continued from previous page ∙ 1x 24-pin ATX main power connector ∙ 2x 8-pin ATX 12V power connectors ∙ 1x 6-pin ATX PCIE power connector ∙ 6x SATA 6Gb/s connectors ∙ 3x M.2 slots (M-Key) ∙ 1x USB 3.2 Gen 2 10Gbps Type-C port ∙...
  • Page 19 ∙ ACPI 6.2, SMBIOS 3.0 ∙ Multi-language ∙ Drivers ∙ MSI Center ∙ Intel® Extreme Tuning Utility ∙ MSI APP Player (BlueStacks) Software ∙ Open Broadcaster Software (OBS) ∙ CPU-Z MSI GAMING ∙ Google Chrome™, Google Toolbar, Google Drive ∙ Norton™ Internet Security Solution ∙...
  • Page 20 Continued from previous page ∙ Audio ▪ Audio Boost 4 ▪ Sound Tune ∙ Network ▪ 2.5G LAN ▪ LAN Manager ▪ Intel® WiFi (For MPG Z590 GAMING EDGE WIFI only) ∙ Cooling ▪ M.2 Shield Frozr ▪ K7 thermal pad Special Features ▪...
  • Page 21 ▪ Dual CPU Power ▪ Server PCB ▪ 2oz Copper thickened PCB ∙ Protection ▪ PCI-E Steel Armor ▪ Pre-installed I/O Shielding ∙ Experience ▪ MSI Center ▪ Frozr AI Cooling ▪ Click BIOS 5 ▪ Flash BIOS Button Specifications...

  • Page 22: Package Contents

    Package contents Please check the contents of your motherboard package. It should contain: Motherboard MPG Z590 GAMING EDGE WIFI / MPG Z590 GAMING PLUS User manual Documentation Quick installation guide Application USB drive with drivers & utilities SATA 6G cables (2 cables/pack)

  • Page 23: Block Diagram

    Block Diagram PCI_E1 PCIe x16 DDR4 2Channel DIMM A1,A2 M2_1 DIMM B1,B2 PCI_E2 & PCI_E4 PCI_E3 USB 3.2 Gen 2x2 20Gbps PCI_E5 M2_2 SATA2 USB 3.2 Gen 2 10Gbps SATA5/6 M2_3 USB 3.2 Gen 1 5Gbps SATA1/3/4 USB 2.0 Hub-GL850G Intel LAN 2.5G WiFi AX210 (optional) HD Audio...

  • Page 24: Rear I/O Panel

    Rear I/O Panel Wi-Fi Antenna connectors USB 3.2 Gen 1 5Gbps Type-A Audio Ports 2.5 Gbps LAN DisplayPort USB 2.0 Flash BIOS Button Optical USB 3.2 Gen 2 S/PDIF-Out 10Gbps Type-A USB 3.2 Gen 2x2 20Gbps Type-C Flash BIOS Port (For MPG Z590 GAMING EDGE WIFI only) ∙...

  • Page 25: Realtek Audio Console

    Realtek Audio Console After Realtek Audio Console is installed. You can use it to change sound settings to get better sound experience. Application Enhancement Device Selection Main Volume Connector Settings Jack Status ∙ Device Selection - allows you to select a audio output source to change the related options.
  • Page 26 Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Rear I/O Panel...

  • Page 27: Installing Antennas (For Mpg Z590 Gaming Edge Wifi Only)

    Installing antennas 1. Screw the antennas tight to the antenna connectors as shown below. 2. Orient the antennas. Rear I/O Panel...

  • Page 28: Overview Of Components

    Overview of Components Processor Socket PUMP_FAN1 CPU_PWR2 CPU_FAN1 JRAINBOW2 CPU_PWR1 JRGB2 DIMMB2 DIMMB1 SYS_FAN6 DIMMA2 DIMMA1 ATX_PWR1 JUSB4 M2_1 SYS_FAN1 PCI_E1 SATA ▼ 1 ▲ 2 SATA ▼ 3 ▲ 4 M2_2 PCI_E2 SATA ▼ 5 ▲ 6 PCI_E3 JTPM1 M2_3 SYS_FAN5 PCI_E4...
  • Page 29 Component Contents Port Name Port Type Page CPU_FAN1, PUMP_FAN1, Fan Connectors SYS_FAN1~6 CPU_PWR1~2, ATX_PWR1, Power Connectors PCIE_PWR1 CPU Socket LGA1200 DIMMA1, DIMMA2, DIMMB1, DIMM Slots DIMMB2 JAUD1 Front Audio Connector JBAT1 Clear CMOS Jumper JCI1 Chassis Intrusion Connector JFP1, JFP2 Front Panel Connectors JPWRLED1 LED power input...

  • Page 30: Cpu Socket

    Always unplug the power cord from the power outlet before installing or removing the CPU. ∙ Please retain the CPU protective cap after installing the processor. MSI will deal with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.

  • Page 31: Dimm Slots

    It is recommended to use a more efficient memory cooling system for full DIMMs ∙ installation or overclocking. ∙ The stability and compatibility of installed memory module depend on installed CPU and devices when overclocking. Please refer www.msi.com for more information on compatible memory. ∙ Overview of Components...

  • Page 32: Pci_E1~5: Pcie Expansion Slots

    PCI_E5: PCIe 3.0 x4 (From Z590 chipset) ⚠ Important If you install a large and heavy graphics card, you need to use a tool such as MSI ∙ Gaming Series Graphics Card Bolster to support its weight to prevent deformation of the slot.

  • Page 33: M2_1~3: M.2 Slots (Key M)

    M2_1~3: M.2 Slots (Key M) ⚽ Video Demonstration Watch the video to learn how to Install M.2 SSD. https://youtu.be/2UeWMgjwogU M2_1 M2_2 M2_3 ⚠ Important Intel® RST only supports PCIe M.2 SSD with UEFI ROM. ∙ Intel® Optane™ Memory Ready for M2_2 and M2_3 slots. ∙...
  • Page 34 3. Secure the supplied M.2 standoff according to your M.2 SSD length if need. 4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 5. Secure the M.2 SSD in place with the supplied M.2 8.5H screw. ⚠...

  • Page 35: Sata1~6: Sata 6Gb/S Connectors

    SATA1~6: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 ⚠ Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result during ∙...

  • Page 36: Jfp1, Jfp2: Front Panel Connectors

    JFP1, JFP2: Front Panel Connectors These connectors connect to the switches and LEDs on the front panel. Buzzer JFP2 Speaker Speaker - Buzzer + Buzzer - Speaker + Power LED Power Switch JFP1 Reserved HDD LED Reset Switch HDD LED + Power LED + HDD LED - Power LED -...

  • Page 37: Cpu_Pwr1~2, Atx_Pwr1, Pcie_Pwr1: Power Connectors

    CPU_PWR1~2, ATX_PWR1, PCIE_PWR1: Power Connectors These connectors allow you to connect an ATX power supply. CPU_PWR1~2 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V...

  • Page 38: Jusb4: Usb 3.2 Gen 2 Type-C Connector

    JUSB4: USB 3.2 Gen 2 Type-C Connector This connector allows you to connect USB 3.2 Gen 2 10Gbps Type-C connector on the front panel. The connector possesses a foolproof design. When you connect the cable, be sure to connect it with the corresponding orientation. USB Type-C Cable JUSB4 USB Type-C port on...

  • Page 39: Jusb1~2: Usb 2.0 Connectors

    In order to recharge your iPad,iPhone and iPod through USB ports, please install ∙ MSI® Center utility. JTPM1: TPM Module Connector This connector is for TPM (Trusted Platform Module). Please refer to the TPM security platform manual for more details and usages.

  • Page 40: Cpu_Fan1, Pump_Fan1, Sys_Fan1~6: Fan Connectors

    CPU_FAN1, PUMP_FAN1, SYS_FAN1~6: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. The auto mode fan connectors can automatically detect PWM and DC mode.

  • Page 41: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.

  • Page 42: Jbat1: Clear Cmos (Reset Bios) Jumper

    JBAT1: Clear CMOS (Reset BIOS) Jumper There is CMOS memory onboard that is external powered from a battery located on the motherboard to save system configuration data. If you want to clear the system configuration, set the jumpers to clear the CMOS memory. Keep Data Clear CMOS/ (default)

  • Page 43: Jrgb1~2: Rgb Led Connector

    (12V/G/R/B) with the maximum power rating of 3A (12V). Always turn off the power supply and unplug the power cord from the power outlet ∙ before installing or removing the RGB LED strip. Please use MSI’s software to control the extended LED strip. ∙ Overview of Components...

  • Page 44: Jrainbow1~2: Addressable Rgb Led Connectors

    (5V). In the case of 20% brightness, the connector supports up to 200 LEDs. ∙ Always turn off the power supply and unplug the power cord from the power outlet before installing or removing the RGB LED strip. Please use MSI’s software to control the extended LED strip. ∙ Overview of Components...

  • Page 45: Onboard Leds

    Onboard LEDs EZ Debug LED These LEDs indicate the debug status of the motherboard. CPU - indicates CPU is not detected or fail. DRAM - indicates DRAM is not detected or fail. VGA - indicates GPU is not detected or fail. BOOT - indicates the booting device is not detected or fail.

  • Page 46: Installing Os, Drivers & Msi Center

    MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed.

  • Page 47: Uefi Bios

    UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’s capabilities.

  • Page 48: Bios Setup

    * When you press F10, a confirmation window appears and it provides the modification information. Select between Yes or No to confirm your choice. BIOS User Guide If you’d like to know more instructions on setting up the BIOS, please refer to http://download.msi.com/manual/mb/Intel500BIOS.pdf or scan the QR code to access. UEFI BIOS...

  • Page 49: Resetting Bios

    Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: 1. Insert the USB flash drive that contains the update file into the USB port.
  • Page 50 1. Please download the latest BIOS file that matches your motherboard model from the MSI® website. 2. Rename the BIOS file to MSI.ROM, and save it to the root of your USB flash drive. 3. Connect the power supply to CPU_PWR1 and ATX_PWR1. (No need to install CPU and memory.)

  • Page 51: Raid Configuration

    All the information/ volumes/ pictures listed in your system might differ from the illustrations in this appendix. Intel RAID User Guide If you’d like to know more instructions on how to set up Intel RAID, please refer to http://download.msi.com/manual/mb/IntelRAID.pdf or scan the QR code to access. RAID Configuration...

  • Page 52: Intel® Optane™ Memory Configuration

    Optane™ memory, please note that it requires Windows 10 64-bit operating system. Intel® Optane™ Memory User Guide If you’d like to know more instructions on how to enable or remove Intel® Optane™ Memory, please refer to http://download.msi.com/manual/mb/Optane.pdf or scan the QR code to access. ⚠ WARNING After you enable Intel®...

  • Page 53: Troubleshooting

    Troubleshooting Lost BIOS password Before sending the motherboard for RMA repair, try to go over troubleshooting ∙ Clear the CMOS, but that will cause guide first to see if your got similar you to lose all customized settings in the symptoms as mentioned below.
  • Page 54 NOTE Troubleshooting...
  • Page 55 제조년월: 2021년 products. R-R-MSI-10-7D07 제조자 및 제조국가: MSI/중국 y Visit the MSI website and locate a nearby distributor y MPG Z590 GAMING PLUS for further recycling information. 상호: (주)엠에스아이코리아 y Users may also reach us at gpcontdev@msi.com for 제품명: 메인보드...
  • Page 56 MSI will comply with the product take entregar a una empresa autorizada para la recogida de back requirements at the end of life of MSI-branded estos residuos.
  • Page 57 Products can be operated without del suo ciclo di vita. MSI si adeguerà a tale Direttiva maintaining a separation distance unless otherwise ritirando tutti i prodotti marchiati MSI che sono stati indicated in instructions specific to the product.
  • Page 58 Copyright © 2021 All rights reserved. contact your place of purchase or local distributor. The MSI logo used is a registered trademark of Alternatively, please try the following help resources Micro-Star Int’l Co., Ltd. All other marks and names for further guidance.
