Texas Instruments LP-EM-CC1354P10-1 Hardware Setup

The BoosterPack™ connector
The pinout to connect BoosterPack accessories (available separately) are shown below.
1 3V3
2 A0 DIO23
3 RXD DIO12
4 TXD DIO13
5 DIO22
6 A1 DIO24
7 SPI_CLK DIO10
8 DIO21
9
I2C_SCL DIO4
I2C_SDA
10 DIO5
5V
21
22 GND
23 A2 DIO25
24 A3 DIO26
25 A4 DIO27
26 A5 DIO28
27 A6 DIO29
28
A7 DIO30
29
DIO43
DIO44
30
UART (DIO12, DIO13), Reset (LP_RST) and JTAG (TMS, TCK, TDO and TDI) are also present in the
LP-EM Debug Connector. Power (GND, 3V3 and 5V) is also provided.
*These functions are not connected to the LaunchPad connector by default.
XDS110 EnergyTrace™ Technology
The LP-EM-CC1354P10-1 is compatible with EnergyTrace technology.
EnergyTrace implements a new method for measuring MCU current consumption. It uses
a DC-DC solution to measure the time density of charge pulses, allowing accuracy on
GND 20
ultra low power measurements. Its high dynamic range (700 nA to 400 mA) and fast
19
DIO19
sampling rate (256 kSPS) captures the complete operational profile of the wireless MCU.
SPI_CS 18
DIO11
DIO14 BTN_2 17
LP_RST DIO40* 16
DIO9 SPI_MOSI 15
EnergyTrace Profile
14
DIO8 SPI_MISO
EnergyTrace Profile runtime and energy data for low power modes along with each
13
DIO42
function run during Active Mode.
12
DIO41
11
DIO15 BTN_1
Graphical Power Data in Code Composer Studio
These two tabs of the EnergyTrace Technology window show a graph over time of
DIO47 40
power and energy.
DIO46 39
Available in the LP-XDS110ET Debug Probe and selected LaunchPads
DIO20 38
DIO45 CTS 37
DIO18 RTS SWO 36
35
DIO40 RESET*
34
TMS
33
TCK
TDO 32
DIO16
TDI 31
DIO17
Find more information at
ti.com/EnergyTrace
