- Page 1 580ST 590ST 695ST Stage IIIB Tractor Backhoe Loader SERVICE MANUAL Part number 47847146 English June 2015 Replaces part number 84568047A © 2015 CNH Industrial America LLC. All Rights Reserved.
- Page 2 SERVICE MANUAL 580ST T4 590ST T4 695ST T4 47847146 24/06/2015...
- Page 3 Link Product / Engine Product Market Product Engine Europe 580ST T4 F5HFL413C*A001 Europe 590ST T4 F5HFL413B*A002 695ST T4 Europe F5HFL413B*A002 47847146 24/06/2015...
- Page 4 Contents INTRODUCTION Machine completion and equipment ..........05 [05.102] Machine completion ..............05.1 Engine..................
- Page 5 [27.100] Powered rear axle..............27.1 [27.106] Rear bevel gear set and differential .
- Page 6 [39.140] Ballasts and supports ............. . 39.2 Steering..................
- Page 7 [82.100] Arm ................. 82.1 [82.300] Bucket .
- Page 8 INTRODUCTION 47847146 24/06/2015...
- Page 9 In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer.
-
Page 10: Safety Rules
INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions. -
Page 11: General Safety Rules
INTRODUCTION Safety rules General safety rules Use caution when you operate the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces. - Page 12 SERVICE MANUAL Engine 580ST T4 590ST T4 695ST T4 47847146 24/06/2015...
-
Page 13: Diesel Engine
Engine - Engine and crankcase Engine - General specification Diesel engine 72 kW - 97 Hp HP Engine (580ST) Specifications ( ISO 14396) 72 kW - 97 Hp @ 2200 RPM Model F5HFL413C*A Type Diesel, electronic No. of cylinders Valves per cylinder Bore 99 mm (3.90 in) - Page 14 Engine - Engine and crankcase 82 kW - 110 Hp ENGINE (590ST - 695ST) Specifications ( ISO 14396) 82 kW – 110 Hp @ 2200 RPM Model (B110C-B110CTC-B115C) F5HFL413B*A Type Diesel, electronic No. of cylinders Valves per cylinder Bore 99 mm (3.9 in) Stroke 110 mm (4.33 in) Displacement...
- Page 15 Engine - Engine and crankcase Engine - Component localization LELI12TLB0087GB 1. Bracket RH engine mount 2. Bracket LH engine mount 3. Washer 4. M12 X 35 hex screw 5. Anti-vibration devise 47847146 24/06/2015 10.1 [10.001] / 5...
- Page 16 Engine - Engine and crankcase 6. Washer 7. M16 X 120 hex screw 8. Washer 9. M16 nut [tightening torque 210 - 240 N·m (155 - 177 lb ft)] 47847146 24/06/2015 10.1 [10.001] / 6...
-
Page 17: Preliminary Operations
Engine - Engine and crankcase Engine - Prepare for removal Prior operation: Position the machine on a flat and compact surface. Prior operation: Apply the parking brake and chock the wheels with wedges. Prior operation: Use only the recommended tools. Prior operation: Do not insert hands or extraneous components between parts. - Page 18 Engine - Engine and crankcase Engine - Remove 1. Prepare the engine for removal as explained in Engine - Prepare for removal (10.001). 2. Remove and disconnect compressor electrical connec- tor X-473 (if present). LELI12TLB0038AA 3. Identify, tag and disconnect the high pressure and low pressure air conditioning lines, (if present).
- Page 19 5. Remove the connector X-4 from 2-way air cleaner con- nector. LEPH12TLB0041AA 6. Remove the pipe connecting the air cleaner with tur- bocharger. LEPH12TLB0042AA 7. Remove the aspirator tube. LEPH12TLB0043AA 8. Remove the crank case vent. LEPH12TLB0044AA 47847146 24/06/2015 10.1 [10.001] / 9...
