Video Cassette Player
Hookup Pages
Read this manual first!
Congratulations on purchasing this Philips product.
We've included everything you need to get started.
If you have any problems, Philips Representatives can
help you get the most from your new product by explaining:
• Hookups,
• First Time Setup, and
• Feature Operation.
Do not attempt to return this product to the store.
Thank you for making Philips a part of your home!
For fast help, call us first!
1-800-531-0039
VP115CAT

Advertisement

Table of Contents
loading

Related Manuals for Philips VP115CAT

Summary of Contents for Philips VP115CAT

  • Page 1 • Hookups, • First Time Setup, and • Feature Operation. Do not attempt to return this product to the store. Thank you for making Philips a part of your home! For fast help, call us first! 1-800-531-0039 VP115CAT...

  • Page 2: Hookups Without A Cable Box

    6 Hookups Without a Cable Box The basic VCP/TV connection – antenna/cable to VCP to TV – is shown below. If you have a Cable Box, please refer to pages eight-nine. If you have a Stereo TV, please go to page 10. To use the VCP in an automobile, go to page 11.
  • Page 3 Connect the RF coaxial cable (supplied) to the ANT(enna) OUT jack on the back of the VCP and to the ANTENNA IN Jack on the TV. (You may use either a snap-on type or screw-on type of coaxial cable, whichever you prefer. A snap-on type is supplied.) AUDIO OUTPUT...

  • Page 4: Hookups With A Cable Box

    8 Hookups With a Cable Box This connection allows you to view any channel. You must select channels at the Cable Box. 1. Connect the Cable signal to the IN Jack on the Cable Box. 2. Use the RF coaxial cable (supplied) to connect the OUT Jack on the Cable Box to the ANT(enna) IN...
  • Page 5 This connection differs from the one shown on page eight. You may still view any channel (selecting channels at the Cable Box), but the instructions for playing a tape are different. 1. Connect a Cable signal to the VCP’s ANT(enna) IN Jack.

  • Page 6: Helpful Hints

    To get stereo sound, use the connections on pages six-nine and select channels at the TV or the Cable Box (with the VCP off). VIDEO OUTPUT jacks to connect the VCP to other equipment - such as a VCR if you want to copy tapes.

  • Page 7: Mobile Connections

    When passengers in your vehicle want to watch a video program, hook up the VCP by following the steps below. Do not start your vehicle until all connections are complete. Make sure your vehicle has a 13.2-volt, negative ground electrical system.

  • Page 8: Front Panel

    14 Front Panel STOP/EJECT Button Press once to stop the tape. When tape playback is stopped, press to eject the tape. F.FWD (Fast Forward) Button When tape playback is stopped, press to fast forward the tape at high speed. During tape playback, press to fast forward the tape while the picture stays on the screen.

  • Page 9: Rear Panel

    AUDIO OUTPUT Jack Use an audio cable (not supplied) to connect this jack to the Audio In jack of a TV, camcorder, VCR, or audio system. Details are on page 10. DC 13.2V Jack Connect the car battery cord here when you use the VCP in your vehicle.
