ITEM #1130001/1160325
80 V LITHIUM-ION BRUSHLESS
STRING TRIMMER
MODEL #KST 2580-06/KST 1680-06
Español p. 22
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
PH18678
1
Advertisement
Table of Contents
Related Manuals for Kobalt KST 2580-06
Summary of Contents for Kobalt KST 2580-06
- Page 1 ITEM #1130001/1160325 80 V LITHIUM-ION BRUSHLESS STRING TRIMMER MODEL #KST 2580-06/KST 1680-06 Español p. 22 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents......................... Hardware Contents....................... Symbols..........................Safety Information......................... Preparation ........................... Assembly Instructions ......................Operating Instructions ......................Care and Maintenance ......................Troubleshooting........................Warranty..........................Replacement Parts List ......................PRODUCT SPECIFICATIONS SPECIFICATIONS Type Cordless, battery-powered Speed 6,200 RPM ± 10％ Cutting Path 14 / 16 in. -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Battery Release Button Spool (preassembled to Spool Trigger Housing) Lock-off Lever Eyelet Speed Switch (preassembled to Spool Front/Auxiliary Handle Housing) Coupler Spool Housing Motor Housing (preassembled to Lower Guard Tube） Upper Tube Bump knob Lower Tube String Head... -
Page 4: Hardware Contents
HARDWARE CONTENTS (not shown actual size) Screw (preassembled Bolt Fastening Knob to the Guard (H)) Qty. 1 Qty. 1 Qty. 2 = 0.095” (2.4mm) Cutting Line (10 ft) Hex Wrench Bracket Qty. 1 Qty. 1 Qty. 1... -
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS DESIGNATION EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) - Page 6 SYMBOLS Save these Instructions The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will DANGER result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.
-
Page 7: Safety Information
SAFETY INFORMATION WARNING Read and understand all instructions before using this product. Failure to follow all instructions listed • liquids, gases, or dust. Power tools create sparks that may ignite the dust or fumes. • Do not allow children or untrained individuals to use this unit. •... - Page 8 • Remove or disconnect battery before servicing, cleaning or removing material from the gardening appliance. • Use only Kobalt 80-volt batteries. (KB 280C-06, KB 2580C-06, KB 380C-06, KB 280-06, KB 2580-06, KB 380-06) Use only Kobalt 80-volt charger. (KRC 80-06, KRC 0280-06) •...
- Page 9 SAFETY INFORMATION Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of gloves and substantial footwear is recommended when working outdoors. Wear protective hair covering to contain long hair. Use the Correct Appliance – Do not use appliance for any job except that for which it is intended. When battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another.
-
Page 10: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: ASSEMBLY INSTRUCTIONS WARNING •... - Page 11 ASSEMBLY INSTRUCTIONS 2. Connect upper/lower trimmer tubes Push in the release button located on the lower tube (K). Align the release button with the positioning hole on the upper tube (J) and slide the Release button two tubes together. Rotate the lower tube until the release button locks into the positioning hole.
- Page 12 ASSEMBLY INSTRUCTIONS Cutting line on the trimmer. When the cutting line needs replacing, rewind new line onto existing spool. CAUTION: To avoid injury, always remove the battery before installing the guard, changing a cutting line, or making any adjustments. To remove the cutting line : Remove the battery from the trimmer.
- Page 13 ASSEMBLY INSTRUCTIONS 5. To Install the cutting line For 0.080 in. (2.0 mm) nylon line, do not put Note: more than 13 feet of cutting line in at a time. For 0.095 in. (2.4 mm) nylon line, do not put more than 10 feet of cutting line in at a time.
- Page 14 ASSEMBLY INSTRUCTIONS To replace the bump knob Remove the battery pack. Turn the string trimmer over to access the spool. Remove the spool cover (L) by pressing on the two tabs parallel to each other on the sides of the spool cover (L).
- Page 15 ASSEMBLY INSTRUCTIONS 8. Battery IMPORTANT: The battery is not charged when it is purchased. Before using the trimmer for and charge. 8a. To install: Align the battery (Q) with the cavity in the string trimmer housing. Insert the battery into the handle until the battery release button (A) locks into place.
-
Page 16: Operating Instructions
OPERATING INSTRUCTIONS WARNING To avoid injury: • Do not squeeze the trigger while the string trimmer is inverted. • Do not carry the string trimmer with your finger on the switch. Avoid unintentional starting. 1. To turn on/off: a. Slide the speed switch (D) to the desired operating speed. - Page 17 OPERATING INSTRUCTIONS Trimmer tips Before each use: • Make sure the protective guard is tightly installed. If not, tighten the guard screws. • Before trimming, inspect the area for string, wire, branches or other material that may become entangled in the cutting line and thrown. Storage tips: •...
-
Page 18: Care And Maintenance
CARE AND MAINTENANCE Trimmer Guard and Motor Maintenance Note: Before performing maintenance, remove battery from the tool. 1. Remove dirt and debris from guard using a paint brush (not included). 2. Clean dirt and debris off of motor cover and connection joints. -
Page 19: Troubleshooting
If you still have questions or an unresolved issue after going through this troubleshooting guide, or just want to speak to a Kobalt product expert, please call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday – Friday. -
Page 20: Warranty
5-YEAR LIMITED WARRANTY This Kobalt 80 V String Trimmer is warranted to the original purchaser from the original purchase date This Kobalt 80 V String Trimmer is warranted for the original user to be free from defects in material and workmanship. -
Page 21: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION PART # 341201444 Fastening knob Bolt 322051444 329011444 Hex wrench 341191444 Front/auxiliary handle 33304877B Bracket 311062489 Guard String head...
