Parts List - Clarke RACER 55 Operation & Maintenance Instructions Manual

PARTS LIST

NO. DESCRIPTION
1 BOLT
2 FRONT SHIELD
3 KEY
4 BEARING
5 ROTOR
6 BEARING
7 CASE
8 STATOR
9 REAR SHIELD
10 NUT
11 FAN
12 FAN COVER
13 SCREW & WASHER
14 PROTECTOR NUT
15 PROTECTOR
16 SCREW & WASHER
17 CAPACITOR HOLDER
18 SCREW & WASHER
19 TERMINAL BOX TOP PART FN026050000
20 RUNNING CAPACITOR
21 TERMINAL BOX BOTTOM PART
22 CABLE GLAND
50 TANK
51 WHEEL
52 CIRCLIP
53 DRAIN VALVE
54 CUSHION
55 PLUG
56 NUT
57 WASHER
58 SPACER
SPARE PARTS AND SERVICE
For Spare Parts and Service, please contact your nearest dealer, or Clarke
International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
PARTS: Parts@clarkeinternational.com
SERVICE:
PART NO.
FN140021300
FN025047000
FN018035000
FN033155000
FN034145000
FN033155000
FN140100013
FN031137000
FN025050000
FN014003003
FN024086000
FN025052000
FN014001102
FN014004017
FN008424000
FN014013007
FN015143000
FN014012130
FN009200090
FN026052000
FN026093000
FN170047002
FN020001001
FN015024000
FN022021000
FN020093000
FN011008000
FN014003001
FN014005010
FN199763000
or e-mail as follows:
Service@clarkeinternational.com
25
NO. DESCRIPTION
59 KNOB
60 LOCKNUT
61 DELIVERY PIPE
62 COMPASS
63 RILSAN TUBE
64 SEAL
65 TAPERED SPRING
66 O-RING
67 CHECK VALVE
68 SAFETY VALVE
69 BIG GUAGE
70 NIPPLE
71 NIPPLE
72 SMALL GAUGE
73 PRESSURE REDUCER
74 SCREW
75 MOTOR 230~240V/50HZ
76 POWER CABLE
77 PRESSURE SWITCH
78 MOTOR CABLE
79 SQUARE WASHER
80 SCREW
81 TAPPING SCREW
82 PLASTIC DOWEL FOR BELT GUARD
83 BELT GUARD
84 GUARD SUPPORT
85 WASHER
86 SCREW
87 SKM10 PUMP
88 BELT
89 PULLEY
PART NO.
FN127HQ0130
FN199437000
FN113172011
FN011304000
FN046001000
FN047113001
FN047113002
FN010041000
FN347043000
FN047206000
FN330007000
FN199110140
FN011017000
FN330006000
FN319117000
FN014001042
FN540C001605
FN117HA0203
FN321028000
FN139915003
FN014005007
FN014013045
FN014013042
FN020025000
FN199688001
FN113172010
FN014005002
FN014001047
FN5131720000
FN045082000
FN140055004
