SITRANS P
Pressure transmitter
SITRANS P200
Compact Operating Instructions
7MF1565
09/2020
A5E03304326-AA
Introduction
Safety instructions
Description
Installing/mounting
Connecting
Commissioning
Service and maintenance
Technical specifications
Dimension drawings
Product documentation and
support
1
2
3
4
5
6
7
8
9
A

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITRANS P Series

Summary of Contents for Siemens SITRANS P Series

  • Page 1 Introduction Safety instructions Description SITRANS P Installing/mounting Pressure transmitter SITRANS P200 Connecting Commissioning Compact Operating Instructions Service and maintenance Technical specifications Dimension drawings Product documentation and support 7MF1565 09/2020 A5E03304326-AA...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ............................5 Purpose of this documentation .................... 5 Checking the consignment....................5 Transportation and storage ....................5 Notes on warranty ....................... 6 Safety instructions ..........................7 Prerequisites for safe use...................... 7 2.1.1 Laws and directives ......................7 2.1.2 Conformity with European directives ..................
  • Page 4 Table of contents Technical specifications ........................25 General technical specifications..................25 Certificates and approvals....................28 8.2.1 Explosion protection ......................28 Dimension drawings ..........................29 Dimensional drawings process connections ................ 29 Dimensional drawings electrical connections..............30 Product documentation and support ....................31 Product documentation .....................

  • Page 5: Introduction

    • Devices/replacement parts should be returned in their original packaging. • If the original packaging is no longer available, ensure that all shipments are properly packaged to provide sufficient protection during transport. Siemens cannot assume liability for any costs associated with transportation damages.

  • Page 6: Notes On Warranty

    The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in the course of further development.

  • Page 7: Safety Instructions

    Safety instructions Prerequisites for safe use This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the device, observe these instructions and all the specifications relevant to safety. Observe the information and symbols on the device. Do not remove any information or symbols from the device.

  • Page 8: Improper Device Modifications

    Note Operation under special ambient conditions We highly recommend that you contact your Siemens representative or our application department before you operate the device under special ambient conditions as can be encountered in nuclear power plants or when the device is used for research and development purposes.
  • Page 9 Safety instructions 2.4 Use in hazardous areas WARNING Use in hazardous area Risk of explosion. • Only use equipment that is approved for use in the intended hazardous area and labelled accordingly. • Don't use devices that have been operated outside the conditions secified for hazardous areas.
  • Page 10 Safety instructions 2.4 Use in hazardous areas SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 11: Description

    Description Application The pressure transmitter is used for measuring the gauge pressure and absolute pressure of gases and liquids in the following industrial areas: • Mechanical engineering • Power engineering • Water supply • Shipbuilding • Chemical industry • Pharmaceuticals Hardware configuration Device structure without explosion protection The pressure transmitter consists of a piezo-resistive measuring cell with a diaphragm installed...

  • Page 12: Layout Of The Nameplate

    Description 3.3 Layout of the nameplate Table 3-1 Overview of the different variants 7MF1565 with plug in 7MF1565 with plug 7MF1565 with cable 7MF1565 with fast-fit accordance with M12x1 (2 m) cable gland EN 175301-803-A • Type • Type • Type •...
  • Page 13 Description 3.3 Layout of the nameplate Code Year 2021 2022 2023 2024 2025 2026 2027 2028 2029 Code Month January February March April June July August September October November December Code 01-31 Day of month 1st to 31st day Conforming to DIN EN 60062 The letter G is not permitted for new applications since it deviates from DIN EN 60062.
  • Page 14 Description 3.3 Layout of the nameplate SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 15: Installing/Mounting

    Refer to the information in Technical specifications (Page 25). Note Material compatibility Siemens can provide you with support concerning selection of sensor components wetted by process media. However, you are responsible for the selection of components. Siemens accepts no liability for faults or failures resulting from incompatible materials.

  • Page 16: Additional Notes On Installation Of Explosion Protection Devices

    Installing/mounting 4.3 Installation Additional notes on installation of explosion protection devices Operation is permitted only when connected to certified intrinsically-safe resistive circuits with the following maximum values: ≤ 30 V ≤ 100 mA ≤ 750 mW Internal inductance Li = 0 nH Internal capacitance Ci = 0 nF A maximum ambient air temperature T of -25 °C to +85 ºC is permitted for the pressure...

  • Page 17: Connecting

    Connecting Basic safety instructions WARNING Unsuitable cables, cable glands and / plug-in connectors Danger of explosion in hazardous areas. • Only use cable glands/plug-in connectors that fulfill the requirements of the relevant type of protection. • Only use cables that have been designed for an ambient temperature of at least 20 K higher. •...
  • Page 18 Connecting 5.1 Basic safety instructions WARNING Unprotected cable ends Risk of explosion through unprotected cable ends in hazardous areas. • Protect unused cable ends in accordance with IEC/EN 60079-14. WARNING Connecting device in an energized state / Disconnecting device from power supply in an energized state Risk of explosion in hazardous areas.

  • Page 19: Electrical Connections

    Connecting 5.2 Electrical connections Electrical connections Legend Output current Auxiliary power Output voltage Grounding Load Connecting with current output and connector in accord‐ Connecting with voltage output and connector in accord‐ ance with EN 175301 ance with EN 175301 Connecting with current output and connector M12x1 Connecting with voltage output and connector M12x1 Connecting with current output and cable Connecting with voltage output and cable...
  • Page 20 Connecting 5.2 Electrical connections Connecting with current output and connector in accordance with EN 175301 (Ex) Connecting with current output and connector M12x1 (Ex) SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 21: Commissioning

    Commissioning WARNING Improper commissioning in hazardous areas Device failure or risk of explosion in hazardous areas. • Do not commission the device until it has been mounted completely and connected in accordance with the information in Technical specifications (Page 25). •...
  • Page 22 Commissioning 6.1 Correction of zero point and span SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 23: Service And Maintenance

    WARNING Impermissible repair of explosion protected devices Risk of explosion in hazardous areas • Repair must be carried out by Siemens authorized personnel only. WARNING Use of a computer in a hazardous area If the interface to the computer is used in the hazardous area, there is a risk of explosion.

  • Page 24: Disposal

    Service and maintenance 7.4 Disposal Required forms • Delivery note • Return document (http://www.siemens.com/processinstrumentation/returngoodsnote) with the following information: – Product (item description) – Number of returned devices/replacement parts – Reason for returning the item(s) • Decontamination declaration (http://www.siemens.com/sc/declarationofdecontamination) With this declaration you warrant "that the device/replacement part has been carefully cleaned and is free of residues.

  • Page 25: Technical Specifications

    Technical specifications General technical specifications Mode of operation Measuring range ≥ 1 ... ≤ 60 bar Piezoresistive with ceramic diaphragm Input Measured variable input Measuring range for gauge Overload limit Burst pressure pressure 0 ... 1 bar g ≥ -1 / ≤ 2.5 bar g >...
  • Page 26 Technical specifications 8.1 General technical specifications Input 0 ... 200 psi g ≥ -14.5 / ≤ 550 psi g > 550 psi 0 ... 300 psi g ≥ -14.5 / ≤ 800 psi g > 800 psi 0 ... 500 psi g ≥...
  • Page 27 Technical specifications 8.1 General technical specifications Rated conditions Ambient temperature -25 ... +85 °C (-13 ... +185 °F) Max. 2 000 m above mean sea level • Height Use a suitable power supply at an altitude of more than 2 000 m above mean sea level. 0 ...

  • Page 28: Certificates And Approvals

    Technical specifications 8.2 Certificates and approvals Certificates and approvals Certificates and approvals Classification according to pressure equipment di‐ For gases of Fluid Group 1 and liquids of Fluid rective (PED 2014/68/EU) Group 1; meets the requirements of Article 4 Para. 3 (good engineering practice) 8.2.1 Explosion protection...

  • Page 29: Dimension Drawings

    Dimension drawings Dimensional drawings process connections Figure 9-1 Max. 30 Nm Figure 9-2 Max. 20 Nm Figure 9-3 Max. 20 Nm SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 30: Dimensional Drawings Electrical Connections

    Dimension drawings 9.2 Dimensional drawings electrical connections Figure 9-4 Max. 20 Nm; Pmax ≤ 60 bar Dimensional drawings electrical connections 36 (1.42) M12x1/Fixcon M16x1.5 or 0.5-14 NPT SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...

  • Page 31: Product Documentation And Support

    – "Download as html5, only PC": Open or save the manual in the HTML5 view on your PC You can also find manuals with the Mobile app at Industry Online Support (https:// support.industry.siemens.com/cs/ww/de/sc/2067). Download the app to your mobile device and scan the device QR code. Product documentation by serial number Using the PIA Life Cycle Portal, you can access the serial number-specific product information including technical specifications, spare parts, calibration data, or factory certificates.

  • Page 32: Technical Support

    Additional information on our technical support can be found at Technical Support (http:// www.siemens.com/automation/csi/service). Service & support on the Internet In addition to our technical support, Siemens offers comprehensive online services at Service & Support (http://www.siemens.com/automation/serviceandsupport). Contact If you have further questions about the device, contact your local Siemens representative at Personal Contact (http://www.automation.siemens.com/partner).

  • Page 33: Index

    Index Service and support Internet, 32 Support, 32 Support request, 32 Catalog catalog sheets, 31 Certificates, 7, 31 Customer Support, (Refer to Technical support) Technical support, 32 partner, 32 personal contact, 32 Test certificates, 7 Downloads, 31 Warranty, 6 Hazardous area Laws and directives, 7 Qualified personnel, 8 Hotline, (Refer to Support request)
  • Page 34 Index SITRANS P200 Compact Operating Instructions, 09/2020, A5E03304326-AA...
