Philips HNF901 Mounting Instruction

HNF901
Mounting instruction
ta
25°
Type Number
产品型号
HNF901 Narrow
HNF901 Wide
HNF901 Narrow BKT
196
Warning: For SON-T 1000W lamp, only use to fit into 230V/ 240V/ 50Hz.
警 告：当供应电压是230V/50Hz时，SON-T1000W光源的寿命是8500小时。
1
3 When using Lamp from
250W to 400W, make
this LH BKT to adjust
centre of light source.
当光源从250W变换到
400W时,利用图示灯座
支架来调整光源中心
For heavy duty
对于重载安装支架
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: No. 2688, Huyi Road, Jiading, Shanghai, China
Postalcode: 201801
飞利浦灯具（上海）有限公司
地址：中国上海市嘉定区马陆镇沪宜公路2688号
邮编：201801
安装说明
ta
IP55
35°
0.131m²
Lamp
光源
SON-T250W
SON-T400W
HPI-T250W
HPI-T400W
SON-T1000W
382
494
When supply voltage to be 230V/50Hz, the lamp's life is 8500 hours.
For Heavy duty BKT spec
对于重载安装支架
For normal spec
对于普通安装支架
2- Ø12
M10(2×)
45N.m
M20
130N.m
Referect
m
反射器
Narrow bean
1m
2m Wide bean
（1000W）
Narrow bean
2
Ø22
M10(2×)
45N.m
Ø14
100
3
M12
60N.m
>20m
Bracket
安装支架
Standerd
Standerd
Heavy duty
1000W
2
4 1
8
8
9
<400W
M6(3×)
18N.m
