SERVICE MANUAL
DVD&HDD VIDEO RECORDER
2004
10
YD026
DR-MH20SUC, DR-MH20SUJ,
DR-MH30SUS, DR-MH30SUC
DR-MH30SUJ, DR-MH30STW
CABLE/DBS
TV
DVD
STANDBY ON
TV/
OPEN/
DVD
CLOSE
VIDEO
TV/CBL/DBS
HDD
DVD
TV VOLUME
CH
CANCEL
AUX
MEMO/MARK
LIVE
DUBBING
EDIT
PROGRAMME
TV MUTING
TOP MENU
NAVIGATION
ENTER
MENU
RETURN
PREVIOUS
NEXT
SLOW
PLAY/SELECT
SLOW
REC
STOP/
CLEAR
PAUSE
JUMP
REC MODE
DISPLAY
ON SCREEN
HELP
SAT
VPS/PDC
SET UP
PROGRESSIVE
AUDIO
SUBTITLE
ANGLE
SCAN
LIVE CHECK
Since the whole mechanism assembly unit is replaced, the DVD recorder
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
STANDBY/ON
DR-MH20SUC, DR-MH20SUJ [D4HR20]
DR-MH30SUS, DR-MH30SUC, DR-MH30SUJ, DR-MH30STW [D4HR25]

TABLE OF CONTENTS

COPYRIGHT © 2004 Victor Company of Japan, Limited
F1
S-VIDEO
VIDEO
L(MONO)-AUDIO-R
UC -------------------- Canada
UJ ------------ U.S.A. Militaly
TW -------------------- Taiwan
HDD
DVD
PULL - OPEN
DV
DV IN
No.YD026
2004/10
