WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.
IMPORTANT NOTICE User's Guide Contents: Install Autodesk DWF Viewer Internet Explorer Settings Operating Environment Functions Provided on Each Drawing Page Using with Network Install Autodesk DWF Viewer Autodesk DWF Viewer is necessary to view drawings and to activate the functions of this system. Please download and install.
Page 4
[My Computer (right-click)] - [Properties] 2. Internet Explorer setting [Tools] - [Internet Options]...
for Windows Vista Operating Environment : Pentium III or higher recommended Monitor : 1024 x 768 or higher resolution recommended Mouse : A mouse with wheel recommended : Microsoft Windows 2000 SP4 / XP / Vista Browser Microsoft Internet Explorer 6.0 / 7.0 Drawing viewer : Autodesk DWF Viewer 6.0 / 7.0 * Use the software following respective license terms and conditions.
Page 7
Functions Provided on Each Drawing Page Parts Information Reference Function When the character string of a part on the drawing is clicked, its information is popped up at the location. You can get any parts information immediately on the screen without referring to the maintenance parts list. Parts Search Function You can search any part within the displayed drawing or within the whole schematic diagram/board view by specifying a location number.
Page 8
Using with Network PRECAUTION To use ZEUS Service Manual Ver.2 with network, the file-path names written on the source files of each ZEUS Engine Program Ver.2 and ZEUS Service Manual Ver.2 are to be modified. Perform the procedure described below. Preparation 1.
Page 9
Procedure of File-Path The zeusFPch is the exclusive program to exchange the file-path names written in both source files of ZEUS Manual and ZEUS Engine program into those applicable to the network use. 1. Whenever changing the file-path of both ZEUS Engine Program and ZEUS Service Manual to use with network, pay the attention to set the "Exchange to"...
Page 10
Run the zeusFPch and set "Exchange to" by referring to the examples below. Example 1 : In the "Exchange to" column shows the relation between ZEUS Service Manual and ZEUS Engine Program. ../ counts the relation between. Thus in this case, it must be ../../zeus/ (2 counts). Example 2 : In this case, it must be ../../../zeus/ (3 counts).
Page 11
2. Run the zeusFPch to change the path in the ZEUS Engine Program Ver.2. 3. Set ZEUS Engine Program in the created folder in the server to the "Target Folder", and then press "START". (This procedure is one time only)
Page 12
4. Run the ZeusFPch to change the path in the ZEUS Service Manual Ver2. 5. Set unzipped ZEUS Service Manual in the created folder in the server to the "Target Folder", and then press "START". (This procedure is required whenever placing service manual.)
Page 13
Confirmation Confirm that service manual on the server can be operated normally by client PC. Note: In case of accessing the ZEUS Manual through WEB site, the small pop-up window appears at the left bottom corner on the screen whenever searching the location links. This is not malfunction.
Page 14
Through WEB, ver. 6.5 has been released but with it, the linking function in this manual may not work properly. If ver. 6.5 has been installed, uninstall it and reinstall ver. 6.0. To get ver. 6.0, click the icon, or contact to the nearest Toshiba Service Centre for further assistance. Freezing windows opened (Cannot close the open windows) This may happen occasionally.
Page 15
The real cause has not been found yet but with this condition, nothing disturbs the service manual operation. Continue to use by operating the windows. Precaution when opening the diagrams While opening the diagrams, the menu in the left frame changes its color to GRAY. This is an indication that the viewer is processing.
Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.
LEAD-FREE SOLDER This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product. WARNING: This product is manufactured using lead free solder.
SAFETY INSTRUCTION WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW. Safety Precaution WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.
Page 19
6. Always use the replacement parts specified for the particular model when making repairs. The parts used in products require special safety characteristics such as inflammability, voltage resistance, etc. therefore, use only replacement parts that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list.
Page 20
Resistance values in orms ( ). V: Voltmeter or oscilloscope (r.m.s. or peak reading) Input resistance : Input capacitance : 200 pF Frequency range : 15 Hz to 1 MHz and d.c. respectively Note: Appropriate measures should be taken to obtain the correct value in case of non sinusoidal waveforms.
- for d.c. : = 1.0 V Note: The limit values of = 0.35 V (peak) for a.c. and = 1.0 V for d.c. correspond to the values 0.7 mA (peak) a.c. and 2.0 mA d.c. Product Safety Notice Many electrical and mechanical parts in this chassis have special safety-related characteristics.
SAFETY INSTRUCTION Handling the LCD Module Safety Precaution In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or drink this fluid. Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid should enter the mouth, rinse the mouth thoroughly with water.
Page 23
because any impact can adversely affect the performance. Also use caution when handling the polarized screen because it can easily be damaged. 3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not remove the soiling, breathe on the surface and then wipe again.
Page 24
6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. 7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an extended period of time.
Page 25
9. Do not disassemble the LCD module. Such actions could result in improper operation. 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity.
Page 26
U06A U01A U05A MAIN POWER U03A AS SW U04A LED U04B RMT...
SCHEMATIC DIAGRAM Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 29
Unless otherwise noted in schematic, all capacitor values less than 1 are expressed in µF, and the values more than 1 in pF. All capacitors are ceramic 50 V, unless otherwise noted as the following marks. = Electrolytic capacitor = Mylar capacitor 3.
ADJUSTMENT Service Mode Entering to Service Mode 1. Set VOLUME to minimum and press button once on remote control. ↓ 2. Press button again and hold button down. ↓ Service Mode display 3. While holding the button, press MENU button on TV set.
Page 153
Displaying the Adjustment Menu Press MENU button on TV. Service Mode Press ↑ ↓ Press Adjustment Mode...
Page 154
Key Function in the Service Mode The following key entry during display of adjustment menu provides special functions. CAUTION: Never try to perform initialization unless you have changed the memory IC. button (on remote control) Test signal selection Selection of the adjustment items (on TV or remote control) Volume +/- (on TV or remote control)
SETTING & ADJUSTING DATA [ SERVICE MODE ] ADJUSTING ITEMS AND DATA IN THE SERVICE MODE: Note: The image system data of RCUT-BDRV is different by each image format. The PAL value is indicated in the table. Never adjust H.POS and V.POS except PAL/WIDE mode. Item Name of adjustment RCUT...
Page 156
OPT2 TV SET OPTION 2 OPT3 TV SET OPTION 3 OPT4 TV SET OPTION 4 (PANEL OPT DATA FOR VENDOR) OPT5 TV SET OPTION 5 (PANEL OPT DATA FOR SIZE) OPT6 TV SET OPTION 6 (HOTEL MODE) OPT7 TV SET OPTION 7 (HOTEL MODE) OPT8 TV SET OPTION 8 (HOTEL MODE) TVOP...
After selecting OPT4 or OPT5, press + or - to set OPT4 or OPT5 value as table below. Panel option data Series Model name Panel vendor OPT4 value OPT5 value XV505D EU Digital 32XV505D/503D/504D (SAM) 0x86 0x45 (IPS) 0x87 0x05 37XV505D/503D/504D (LPL)
Page 159
Backlight Positive Status Logic Negative Backlight Execute Status Check Unexecuted Convert from Bit (Binary) to Hex The table for converting from bit (D7-D0) to hex (0x**). BIT (Binary) High nibble Low nibble E.g. If Bit D7-0 = 0101 1010, Hex data is 0x5A.
Exit from Service Mode Pressing POWER button to turn off the TV once. Initialization of Memory Data of QA02 and Setting Data of Signal Unit After replacing QA02 or signal board, the following initialization is required. CAUTION: Never attempt to initialize the data unless QA02 has been replaced.
Page 161
8) Set I2C check function of TVOP to enable. 9) Check the picture carefully. If necessary, adjust any adjustment item above. Perform "Auto tune" on the owner's manual. MODEL ID (HEX) Model name Panel vendor 0x01 32XV505D/503D/504D 0x02 0x03 37XV505D/503D/504D 0x04 0x05 42XV505D/503D/504D CMO...
Page 162
0x23 0x24 0x25 0x26 0x27 0x28 0x29 0x30 0x31 0x32 0x33 Initializing Data setting flowchart after replacing the Signal Unit...
Test Signal Selection Every pressing of button on the remote control changes the built-in test patterns on screen as described below in Service Mode. Picture Signal Red raster Green raster Blue raster All Black All White Self Diagnostic Function...
Page 165
1. Press "9" button on remote control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC's is executed properly. 2. During diagnosis, the following displays are shown. * Self check display and Item are subject to the models. (1) Firmware : Version information of microprocessor Series name (AAAA) and market area (BB) and software program version (0000)
Page 166
V1 - V9 : VIDEO 1-9 input mode : PC mode : YUV mode : DTV mode (SCART (FULL)) (SCART (S+AV)) (Composite/Component/S) HDMI1 HDMI2 HDMI3 DTV (Digital Only) Version Check Mode 1. Press "9" button twice on remote control during display of adjustment menu in the service mode.
Page 167
(1) MAIN MPU : Version information of microprocessor Series name and Code Program Version (4 figure number) and OSD Version (2 figure number). (2) EEPROM : Version information of EEPROM : Display 1 byte data. (3) SUB MPU : Version information of SUB MPU : Display 1 byte data. Left side means QF01 (for AV-LINK) micon software version.
Page 168
Version information of DB software as Toshiba release. (Only digital model.) (7) MW Ver Left side is Application and UI version information of DB software. (Only digital model.) Right side is Firmware (Driver) version information of DB software. (Only digital model.)
Page 169
Status Check Mode 1. Press "9" button thrice on remote control during display of adjustment menu in the service mode. The status of this model will be checked. 2. During Status Check, the following displays are shown. * Status check display and Item are subject to the models. (1) MAIN : Main source information : Display RF position number (0 - 99) on the main screen, or Input Source...
(5) SUB FORMAT : Display Video and PC format information This item displays only Double window model. (6) SUB PLL : Sub PLL information : Display 1 byte data at five. This item displays only Double window model. (7) SCREEN SIZE : Display the screen size as follows.
OPT2 FUNCTION DESCRIPTION (Normal) D7 (bit7) - (no use) D6 (bit6) Enable mode that TV On will be appeared in Enable Disable forced when turning the main power ON D5 (bit5) FRONT Key Disable Enable D4 (bit4) All keys except input selector key Disable Enable (Video/TV)
Page 172
OPT6 FUNCTION DESCRIPTION 0 (Normal) D7 (bit7) Enable mode that POS or VIDEO program Enable Disable number will be appeared in forced when turn ON the main power D6 (bit6) ~ POS or VIDEO program number 0 ~ 127 [decimal] (Normal: 0) D0 (bit0) POS number: 0 ~ 99 VIDEO number: 100 ~ 127...
LED Indication The Green and Red LEDs on the TV (at the bottom center of the TV) indicate the TV's status, as described below. Red ON (solid) and Green OFF = The TV power cord is plugged in.
Page 174
TECHNICAL BULLETIN File Name Title issuing date...
PANEL IDENTIFICATION Panel Identification If the several panels are alternatively used in the same model without amending the model name, the identification marking will be shown at the last digit of the set serial number on the specification label on the back cover. In servicing, do not alter the panel because several setting and parts are different.
PARTS LIST Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 179
: Carbon Composition : Variable Resistor : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted.
Page 180
PARTS LIST ↓Select Block : Search 1 / 1 Jump Page : Jump Location : Search Parts No. :...
Page 205
PARTS LIST U04A LED (PE0534) Block : Block Location Parts No. Description U04A LED (PE0534) U04A 75011070 PC BOARD ASSY, PE0534A1, LED U04A LED (PE0534) CB06 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z U04A LED (PE0534) CB07 76619157 CAPACITOR, ELECTROLYTIC CHIP, 16V 100UF U04A LED (PE0534) DB01 75009054 DIODE, LED, SML-020MLT T86...
Page 207
PARTS LIST U05AS MAIN (PE0535) Block : Loading ...
Page 208
Block Location Parts No. Description U05AS MAIN (PE0535) U05AS 75011361 PC BOARD ASSY, PE0535B, MAIN U05AS MAIN (PE0535) B320 75011088 ACCESSORY FOR SCREW U05AS MAIN (PE0535) B321 75011088 ACCESSORY FOR SCREW U05AS MAIN (PE0535) C1002 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C1003 75009867...
Page 209
U05AS MAIN (PE0535) C1060 75009870 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C1064 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C1065 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C1066 75010712 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C1067 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 210
U05AS MAIN (PE0535) C2004 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2005 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2006 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2007 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2008 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 211
U05AS MAIN (PE0535) C2410 75009866 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2411 75009872 CHIP ALUMINUM ELECTROLYTIC CAP U05AS MAIN (PE0535) C2700 75009864 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2701 75009869 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C2702 75009869 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 212
U05AS MAIN (PE0535) C3803 75009862 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535) C3804 75009862 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535) C3805 75009862 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535) C3806 75005813 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C3807 75009862 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535)
Page 213
U05AS MAIN (PE0535) C4257 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4258 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4259 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4260 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4261 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 214
U05AS MAIN (PE0535) C4511 75009852 CAPACITOR CHIP CERA 25V 104S 3 U05AS MAIN (PE0535) C4512 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4513 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4514 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4515 75009867 CHIP CERAMIC CAPACITOR (1005)
Page 215
U05AS MAIN (PE0535) C4558 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4559 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4582 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4583 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4584 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 216
U05AS MAIN (PE0535) C4813 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4814 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4815 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4817 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C4900 75009863 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 217
U05AS MAIN (PE0535) C5208 75009868 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C5209 75007603 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C5211 75008325 CHIP CERAMIC CAPACITOR (2012) U05AS MAIN (PE0535) C5212 75011078 CHIP ALUMINUM ELECTROLYTIC CAP U05AS MAIN (PE0535) C5400 75009860 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535)
Page 218
U05AS MAIN (PE0535) C6034 75009867 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6035 75009870 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6036 75007614 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6037 75005813 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6038 75006004 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 219
U05AS MAIN (PE0535) C6116 75009853 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C6117 75009853 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C6118 75009853 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C6119 75006010 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C6120 75009927 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535)
Page 220
U05AS MAIN (PE0535) C6413 75010771 CHIP ALUMINUM ELECTROLYTIC CAP U05AS MAIN (PE0535) C6415 75005754 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C6491 75009866 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6492 75009866 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C6501 75009866 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 221
U05AS MAIN (PE0535) C8005 75010710 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C8006 75010710 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C8007 75010711 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C8008 75010711 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C8009 75007603 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 222
U05AS MAIN (PE0535) C9520 75009881 CHIP CERAMIC CAPACITOR (2012) U05AS MAIN (PE0535) C9521 75009866 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C9523 75011121 CHIP ALUMINUM ELECTROLYTIC CAP U05AS MAIN (PE0535) C9524 75009861 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C9525 75002271 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535)
Page 223
U05AS MAIN (PE0535) C9682 75010865 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535) C9683 75010865 CHIP CERAMIC CAPACITOR (3216) U05AS MAIN (PE0535) C9685 75009853 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535) C9687 75007604 CHIP CERAMIC CAPACITOR (1005) U05AS MAIN (PE0535) C9689 75009856 CHIP CERAMIC CAPACITOR (1608) U05AS MAIN (PE0535)
Page 224
U05AS MAIN (PE0535) D6102 23362140 KDS160/P U05AS MAIN (PE0535) D6103 23362140 KDS160/P U05AS MAIN (PE0535) D6104 23362140 KDS160/P U05AS MAIN (PE0535) D6105 23362140 KDS160/P U05AS MAIN (PE0535) D6106 23362140 KDS160/P U05AS MAIN (PE0535) D6107 23362140 KDS160/P U05AS MAIN (PE0535) D6111 23362140 KDS160/P U05AS MAIN (PE0535)
Page 225
U05AS MAIN (PE0535) FL421 75003115 FILTER CHIP BEAD INDUCTOR 220O U05AS MAIN (PE0535) FL441 75003114 FILTER CHIP BEAD INDUCTOR 120O U05AS MAIN (PE0535) FL442 75003113 FILTER CHIP BEAD INDUCTOR 120O U05AS MAIN (PE0535) FL443 75003114 FILTER CHIP BEAD INDUCTOR 120O U05AS MAIN (PE0535) FL450 75003117...
Page 226
U05AS MAIN (PE0535) FL903 75010774 CHIP COMMON MODE FILTER U05AS MAIN (PE0535) FL904 75010774 CHIP COMMON MODE FILTER U05AS MAIN (PE0535) FL905 75010774 CHIP COMMON MODE FILTER U05AS MAIN (PE0535) FL951 75008351 CHIP BEADS INDUCTOR (1608) U05AS MAIN (PE0535) FL954 75009837 CHIP JUMPER 1608TYPE U05AS MAIN (PE0535)
Page 227
U05AS MAIN (PE0535) IC605 23085415 BD4746G-TR U05AS MAIN (PE0535) IC611 75009908 DUAL AUDIO OP AMP U05AS MAIN (PE0535) IC612 75009908 DUAL AUDIO OP AMP U05AS MAIN (PE0535) IC614 75009908 DUAL AUDIO OP AMP U05AS MAIN (PE0535) IC641 75004445 U05AS MAIN (PE0535) IC651 75009908 DUAL AUDIO OP AMP...
Page 228
U05AS MAIN (PE0535) L6103 75008364 COIL CHOKE 22MMH M 1.7A U05AS MAIN (PE0535) L6104 75008364 COIL CHOKE 22MMH M 1.7A U05AS MAIN (PE0535) L6105 75010718 CHIP BEADS INDUCTOR U05AS MAIN (PE0535) L6106 75010718 CHIP BEADS INDUCTOR U05AS MAIN (PE0535) L6201 75009887 CHIP BEADS INDUCTOR U05AS MAIN (PE0535)
Page 229
U05AS MAIN (PE0535) PV201 75010369 PLUG U05AS MAIN (PE0535) PV202 75010369 PLUG U05AS MAIN (PE0535) PV230 75010880 CONNECTOR U05AS MAIN (PE0535) PV240 75011082 JACK U05AS MAIN (PE0535) PV320 75006017 CONNECTOR U05AS MAIN (PE0535) PV321 75011085 CONNECTOR CSS5019-4K31F U05AS MAIN (PE0535) PV322 75011085 CONNECTOR CSS5019-4K31F...
Page 230
U05AS MAIN (PE0535) Q3304 75010152 NPN TRANSISTOR U05AS MAIN (PE0535) Q3305 75009815 NPN TRANSISTOR U05AS MAIN (PE0535) Q3306 75010152 NPN TRANSISTOR U05AS MAIN (PE0535) Q3307 75009815 NPN TRANSISTOR U05AS MAIN (PE0535) Q3401 75010152 NPN TRANSISTOR U05AS MAIN (PE0535) Q3402 75009897 PNP TRANSISTOR U05AS MAIN (PE0535) Q3403...
Page 231
U05AS MAIN (PE0535) Q9682 75002029 TRANSISTOR U05AS MAIN (PE0535) R1001 75009847 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1002 75009847 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1003 75009851 CHIP JUMPER 1005TYPE U05AS MAIN (PE0535) R1004 75009847 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1005 75009847 CHIP RESISTOR (1005)
Page 232
U05AS MAIN (PE0535) R1075 75009842 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1076 75009842 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1077 75009919 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1078 75009919 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1079 75009842 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R1080 75009842...
Page 233
U05AS MAIN (PE0535) R2014 75009835 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2015 75009835 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2016 75009835 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2017 75009835 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2018 75009847 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2019 75009842...
Page 234
U05AS MAIN (PE0535) R2139 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2140 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2141 75007598 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2142 75007598 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2143 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2144 75007601...
Page 235
U05AS MAIN (PE0535) R2424 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2425 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2426 75009840 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2427 75009840 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2429 75009850 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2704 75005809...
Page 236
U05AS MAIN (PE0535) R2970 75010700 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2971 75007600 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2972 75007600 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2974 75009848 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2975 75007600 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R2976 75007600...
Page 237
U05AS MAIN (PE0535) R3404 75008532 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3405 75007599 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3406 75008532 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3407 75007596 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3408 75007596 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3409 75009850...
Page 238
U05AS MAIN (PE0535) R3817 75009850 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3818 75010119 CHIP RESISTOR (1608) U05AS MAIN (PE0535) R3819 75005994 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3820 75009849 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R3821 75009849 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R4000 75008336...
Page 239
U05AS MAIN (PE0535) R4503 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4504 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4505 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4506 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4507 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4508 75010708 CHIP RESISTOR(1005) U05AS MAIN (PE0535) R4509...
Page 240
U05AS MAIN (PE0535) R5012 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5013 75009834 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5014 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5015 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5017 75009834 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5020 75009840...
Page 241
U05AS MAIN (PE0535) R5915 75009840 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5932 75009846 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5933 75009834 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5955 75009834 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5968 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R5969 75009844...
Page 242
U05AS MAIN (PE0535) R6051 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6052 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6053 75009844 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6060 75005985 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6061 75007600 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6062 75005804...
Page 243
U05AS MAIN (PE0535) R6172 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6173 75009847 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6174 75007601 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6175 75005986 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6176 75005986 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6191 75010698...
Page 244
U05AS MAIN (PE0535) R6510 75011115 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6511 75011117 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6512 75005994 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6513 75009851 CHIP JUMPER 1005TYPE U05AS MAIN (PE0535) R6514 75009848 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R6515 75008013...
Page 245
U05AS MAIN (PE0535) R9001 75009829 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9002 75009829 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9003 75009829 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9004 75009829 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9005 75009829 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9006 75009829...
Page 246
U05AS MAIN (PE0535) R9513 75009851 CHIP JUMPER 1005TYPE U05AS MAIN (PE0535) R9514 75009923 CHIP RESISTOR (2012) U05AS MAIN (PE0535) R9515 75009850 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9516 75009848 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9517 75009850 CHIP RESISTOR (1005) U05AS MAIN (PE0535) R9523 75005809...
Page 248
PARTS LIST Miscellaneous Block : Search 1 / 1 Jump Page : Jump Location : Search Parts No. : Block Location Parts No. Description Miscellaneous B001A 75011217 LCD PANEL, G8SEC32FHD, LTA320HA02 Miscellaneous H001 75010735 TUNER, ENG37E05KF Miscellaneous MZ01A 75011506 WIRE HARNESS, MF0132 Miscellaneous P801 23372353 POWER CORD, UK 250V3A FL/FUSE13...
Page 249
PARTS LIST Accessory Block : Search 1 / 1 Jump Page : Jump Location : Search Parts No. : Block Location Parts No. Description Accessory Y101 75011201 OWNERS MANUAL, ENGLISH Accessory Y101E 75011203 OWNERS MANUAL, EURO Accessory Y101N 75011204 OWNERS MANUAL, NORDIC Accessory Y110 75011202 OWNERS MANUAL, QSUG...
Page 250
PARTS LIST Cabinet Block : Search 1 / 1 Jump Page : Jump Location : Search Parts No. : Block Location Parts No. Description Cabinet A201A 75011501 PANEL FRONT BEZEL ASSEY, FRONT BEZEL ASSEY Cabinet A201B 75011500 CABINET/RACK DECO PANEL ASSY, DECO PANEL ASSY Cabinet A342 75011097 BUTTON ASSY, POWER...
Page 251
PARTS LIST Packing Block : Search 1 / 1 Jump Page : Jump Location : Search Parts No. : Block Location Parts No. Description Packing A701 75011504 CARTON CASE TPO, CASE TPO Packing A702A 75011502 PAD TOP PACKING, TOP PACKING Packing A702B 75011503 PAD BOTTOM PACKING, BOTTOM PACKING...
FUNCTION AND OPERATION Controls and Input Connections A wide variety of external equipment can be connected to the input sockets on the side of the television. Whilst all the necessary adjustments and controls for the television are made using the remote control, the buttons on the television may be used for some functions. Switching On...
Page 256
Using the Remote Control Using the Controls and Connections...
FUNCTION AND OPERATION Tuning Digital Television Before switching on the television put your decoder and media recorder to Standby if they are connected. To set up the television use the buttons on the remote control. Tuning for the First Time...
