1.1 Main Body

1.1.1 List of Replacement Parts

imagePRESS C6010 / imagePRESS C7010VP / imagePRESS C6010VP / imagePRESS C7010VP FS / imagePRESS C7010VP PSU / imagePRESS C6010VP FS
/ imagePRESS C6010VP PSU / imagePRESS C6010 FS / imagePRESS C6010 PSU
Category 1 Category 2
Process unit Developing rail unit
Developing drive unit
Remove the drum patch sensor
shutter solenoid unit
Intermediate Registration patch sensor unit
transfer unit
ITB upper frame unit
Leading edge registration detection
uUnit
Hopper/waste Sub hopper unit
toner collection
Hopper unit
unit
Toner feed unit
Waste toner buffer unit
Pickup unit Deck unit
Pickup assembly
Vertical path Vertical path unit
unit
Upper feed unit Feed unit (upper)
Feed unit (lower)
Registration feed unit
Pre-fixing feed unit 1
Pre-fixing feed unit 2
Secondary transfer unit
T-1-1
Parts Name Parts No.
Developing drive shaft FM2-2107
Input gear FU6-0368
Cylinderone-way gear FU6-0369
Developing drive unit FM4-2573
Remove the drum patch sensor FM4-2563
shutter solenoid
Registration patch sensor FM4-2564
ITB drive roller FC9-5798
Leading edge registration patch FM4-2564
sensor
Sub hopper FM2-2097
Hopper unit (Y) FM4-7152
Hopper unit (M) FM4-7153
Hopper unit (C) FM4-7154
Hopper unit (Bk) FM4-7155
Toner feed pipe unit FM4-7438
Waste toner buffer FM2-2053
Deck lifter mootr FK2-2972
Pickup feed belt FC5-8146
Deck pickup solenoid FL2-1785
Deck pull-out roller FL2-9438
Vertical path feed roller FC9-9468
Lower feed roller 4
Right deck merge roller FC9-9470
External merge roller FC69-9469
Transparency sensor RH7-7129
Pre-registration feed roller 1 FC9-9476
Pre-registration feed roller 2
Pre-registration feed roller 3
Feed roller 1 FC9-9475
Registration roller FC5-9624
Pre-fixing Feed Belt Cleaning FL3-2902
Brush
Fixing feed belt (front) FC6-8098
Fixing feed belt (rear)
Pre-fixing feed suction fan FL2-6885
(front)
Pre-fixing feed suction fan
(rear)
Fixing feed belt (front) FC6-8098
Fixing feed belt (rear)
Pre-fixing feed suction fan FL2-6885
(front)
Pre-fixing feed suction fan
(rear)
Torque limiter FC5-9332
Q'ty Replacemen Remarks
t interval
4 9 million 4 color
4 9 million 4 color
4 9 million 4 color
4 9 million It is possible even by the
exchange of single parts (gears).
4 color
4 9 million
3 9 million
1 9 million
1 9 million
4 9 million 4 color
1 9 million
1 9 million
1 9 million
1 9 million
1 9 million
1 9 million
2 9 million
6 9 million 3 piece/deck (right,left)
Spread grease on the inner part of
the bearing.(super lube oil)
2 9 million 1 piece/deck (right,left)
2 9 million 1 piece/deck (right,left)
Spread grease on the inner part of
the bearing.(super lube oil)
2 9 million 1 piece/deck (right,left)
1 9 million Spread grease on the inner part of
the bearing.(super lube oil)
1 9 million Spread grease on the inner part of
the bearing.(super lube oil)
2 14 million
3 9 million Spread grease on the inner part of
the bearing.(super lube oil)
1 9 million Spread grease on the inner part of
the bearing.(super lube oil)
1 9 million Spread grease on the inner part of
the bearing.(super lube oil)
1 9 million
4 9 million
2 9 million
4 9 million
2 9 million
1 9 million
