- Page 1 PLASMA DISPLAY TV Chassis : D68A(N)_Napoleon_Anynet Model : HPP4271X/XAA (HP-P4271) SERVICE Manual PLASMA DISPLAY TV CONTENTS Specifications Alignment and Adjustments Exploded View and Parts List Service Item Schematic Diagrams...
- Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. JUL. 2004 This Service Manual is a property of Samsung Electronics Co.,Ltd. Printed in Korea Any unauthorized use of Manual can be punished under applicable AA82-01837A International and/or domestic law.
- Page 3 COMPONENT2 (480i/480p/720p/1080i) PC (MINI D-SUB 15P) DVI-D AV2 / S-VIDEO1 AV3(Side) / S-VIDEO2(Side) AUDIO Intput COMPONENT1, COMPONENT2 DVI-D Monitor Output VIDEO, AUDIO(L/R) Speaker Output 15W + 15W (8Ω ) Remote Control/AAA Batteries, Power Cord Accessory Antenna Cable, Owner's Instructions Samsung Electronics...
- Page 4 MEMO Samsung Electronics...
- Page 5 To increase and decrease the data of the selected items (ENTER) Confirm your choice(Store OR Enter) SOURCE button Change input source While in Tuner mode, the direct access buttons can be used to select and change channels. ♣ ♣ Samsung Electronics...
- Page 6 The video signal uses the video port when there is no other input signal. However, signal uses the graphic port in PIP mode, which includes other input signals (PC, DVI, Component, etc.), Video adjustment should be performed with Video portand Graphic port separately. Samsung Electronics...
- Page 7 - PC - PC - Video - Video Analog PC Graphic - Component(DTV) - Component(DTV) - Auto Color Port (A-RGB) value(RGB) DTV Mode SIL169 (D-RGB) Different adjustment values will be applied to DVI, PC ,DTV(Component) and Video mode. Samsung Electronics...
- Page 8 Input Modes ☞ Motion Enhancing Adjustment 06. Motion ▶ ☞ DNIe Registers 07. DNIe ▶ ☞ DNIe Registers 08. DNIe Additional ▶ ☞ Logic Registers of the Panel 09. Logic ▶ ☞ Picture Size Registers 10. Picture Size ▶ Samsung Electronics...
- Page 9 DNIe 08.Sub Brightness 09.R Gain 10.G Gain 11.B Gain 12.R/Cr Offset AD9883 13.G/Y Offset 14.B/Cb Offset 15.Auto color on/off ※ Input modes require respective storing the changes after adjustment. 01~06 : Logic 07~08 : DNIe 09~15 : AD9883 Samsung Electronics...
- Page 10 Mode-4 01.U-Saturation 02.V-saturation 03.RGB/YUV U-SAT VSP9437 04.RGB/YUV V-SAT 05.RGB/YUV Tint 06.FLI-saturation FLI2310 07.R Gamma 08.G Gamma ASI510 09.B Gamma 10.Gain-Sel 11.Cr Gain CXA2151Q 12.Cb Gain 13.Y Gain 01~05 : VSP9437 07~09 : ASI510 : FLI2310 10~13 : CXA2151 Samsung Electronics...
- Page 11 03.Cont/Bri Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.Contrast 02.Brightness VSP9437 03.RGB/YUV Contrast 04.RGB/YUV Brightness 05.FLI-Contrast FLI2310 06.FLI-Brightness 07.R Contrast 08.G Contrast 09.B Contrast ASI510 10.R Brightness 11.G Brightness 12.B Brightness 01~04 : VSP9437 07~12 : ASI510 05~06 : FLI2310 Samsung Electronics...
- Page 12 Initial Values of Input Modes ITEM Relevant IC Video Component 04.Detail Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.VAPGAIN 02.VAPINV uPD64083 03.YPFT 04.YPFG 05.APK-1st-BPM 06.APK-2nd-BPM 07.Denoise-BPM VSP9437 08.APK-1st-HPM 09.APK-2nd-HPM 10.Denoise-HPM 11.HenhGain 12.HLEGain FLI2310 13.HChrEnGain 01~04 : uPD64083 05~10 : VSP9437 11~13 : FLI2310 Samsung Electronics...
- Page 13 01.Picture Improve ⇒ 06.Motion Enhancing Adjustment Initial Values of Input Modes ITEM Relevant IC Video Component 06.Motion Mode-1 Mode-2 Mode-3 Mode-4 01.SLLTHD_RF3CH VSP9437-M 02.SLLTHD_ETC VSP9437-S 03.V-motion Tresh FLi2310 04.ISHFTM 05.ISHFTS 01 : VSP9437-M 02 : VSP9437-S 03 : FLI2310 Samsung Electronics...
- Page 14 17. R CORING TH1 18. R CORING TH2 19. R CORING TH3 20. BLACK GAIN 2800 2800 2800 2800 2800 21. WHITE GAIN 5000 5000 5000 5000 5000 22. WTE GAIN 23. CTE GAIN 01~23 : DNIe 2-10 Samsung Electronics...
- Page 15 Relevant IC Video Component 08. DNIe Additional Mode-1 Mode-2 Mode-3 Mode-4 01. R D ALPHAU 02. R BLACK GAIN MAX 03. R BLACK TILT DNIe 04. R WHITE GAIN MAX 05. DNIe GAMME 06. R GAIN 3 X Samsung Electronics 2-11...
- Page 16 03.B DRIVE 04.R CUTOFF 05.G CUTOFF 06.B CUTOFF 07.GAMMA 08.GTS SET 09.ERD MODE Logic 10.RANDOM NOISE 11.DIFF FILTER 12.APC 13.APC SET 14.APC VALUE 15.ACTIVE VPOS 16.ACTIVE HPOS 17.VSYNC POS 18.HSYNC POS 19.VSYNC WIDTH 20.HSYNC WIDTH 01~20 : Logic 2-12 Samsung Electronics...
- Page 17 04. Custom 02.Initial Setting ⇒ 02.P-Mode Value ⇒ 02. P-Mode Value Current Input Mode Available options for the PC/DVI Mode are High,Middle, Low and Custom. 01. Dynamic ▶ 02. Standard ▶ 03. Movie ▶ 04. Custom ▶ Samsung Electronics 2-13...
- Page 18 ※ Available Settings for the PC Mode are 01. Cool2 Custom,Color Tone 1, Color Tone 2, Color Tone 3 02. Cool1 03. Normal ※ Available options for the DVI Mode are 04. Warm1 ColorTone1, ColorTone2, ColorTone3 05. Warm2 2-14 Samsung Electronics...
- Page 19 10.PIP FILTER UC 11. LOG PATTERN Logic 12. LOG HIGH LEVEL ASI510 13. LOG LOW LEVEL 14. ASI COLORRBAR 01~10 : ASI510 11~14 : Logic ASI510 ☞ Note : On items 01-10, a PIP Box appears on the screen. Samsung Electronics 2-15...
- Page 20 ◀ 4 ▶ 07. Fli Memory Clock ◀ 11 ▶ 08. DNIe DEMO ◀ On ▶ 09. PILOT HIGH ◀ 21 ▶ 10. PILOT LOW ◀ 16 ▶ 11. CHECKSUM ◀ 0000 ▶ 12. DRC-Level ◀ 0 ▶ 2-16 Samsung Electronics...
- Page 21 ⑤ ASSY PDP P-E BUFFER BN96-01201A M3,SPD-42AH4,D55A,LJ92-00895A,NTSC/PAL,E BUFFER BOARD ⑥ ASSY PDP P-F BUFFER BN96-01202A M3,SPD-42AH4,D55A,LJ92-00896A,NTSC/PAL,F BUFFER BOARD ⑦ ASSY MISC P-SMPS BN96-01047A SPD-42P4H,100~240V ⑧ ASSY PCB DIGITAL BN94-00612A HPP4271X/XAA,D68A ⑨ ASSY PCB TUNER BN94-00517H HPP5071X/XAA,D68B,NAPOLEON ⑩ Samsung Electronics 2-17...
- Page 22 1. When the SMPS-PCB is replaced, the Va, Vsc, Vs, Ve and Vset voltages must be checked and adjusted to the proper levels indicated on the panel sticker. 2. Whenever the SMPS is changed the 18V line(Vamp) must be checked and adjusted to the proper level. 2-18 Samsung Electronics...
- Page 23 T0074 T0268 T0001 BN96-01031B ASSY COVER P-BACK;42P4H,AL,ASIA FT532 2901-001278 FILTER-EMI AC LINE;250V,6A,-,1000PF,50X2 T0456 BN67-00105A GLASS-FILTER EMI;42P3,MESH,48%,984*584,T FT532 T0132 BN94-00612A ASSY PCB MISC-DIGITAL;HPP4271X/XAA,D68A S.N.A T0091 T0091 BN94-00517E ASSY PCB MISC-SIDE A/V;PS42P4HX/XSA,D68A T0132 T0555 M0145 BN96-00878A ASSY BOARD P-FUNCTION;SPD-50P4HD,FUNCTIO T0008 T0714 BN96-01034A ASSY BOARD P-IR;SPD-42P4HD,IR...
- Page 24 TUNER;TMQH6-003B,PDP-NELSON,NTSC,181CH,4 T0074 BN59-00435B REMOCON;GAIA,TM77,47,SMV-3012,NT,EX T0091 BN94-00517E ASSY PCB MISC-SIDE A/V;PS42P4HX/XSA,D68A T0152 BN94-00517H ASSY PCB MISC-TUNER;HPP5071X/XAA,D68B,NA T0132 BN94-00612A ASSY PCB MISC-DIGITAL;HPP4271X/XAA,D68A T0452 BN95-00368A ASSY SUB PCB-SOUND;PS42P4A,D68A,NAPOLEON M0145 BN96-00878A ASSY BOARD P-FUNCTION;SPD-50P4HD,FUNCTIO M0003 BN96-00997K ASSY COVER P-FRONT;42P4H,SEA,ABS V0,ACRY T0001 BN96-01031B ASSY COVER P-BACK;42P4H,AL,ASIA...
- Page 25 MEMO Samsung Electronics...
- Page 26 Schematic Diagrams 5. Schematic Diagrams 5-1 VIDEO SW (Digital PCB) This Document can not be used without Samsung’s authorization. NTSC OPTION PAL OPTION R238 R239 R243 R244 (TV OUT) R240 NTSC OPTION VIDEO3, S-VIDEO3 : SIDE AV Samsung Electronics...
- Page 27 Schematic Diagrams 5-2 3D COMB (Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 28 Schematic Diagrams 5-3 VSP9437(Digital PCB) This Document can not be used without Samsung’s authorization. NTSC OPTION PAL OPTION R456 R457 R415 R458 R459 R460 R461 R432 Samsung Electronics...
- Page 29 Schematic Diagrams 5-4 PCIN_9883_2151 (Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 30 Schematic Diagrams 5-5 DVI_SIL169 (Digital PCB) This Document can not be used without Samsung’s authorization. DELETE OPTION R623 R624 R630 BD602 Samsung Electronics...
- Page 31 Schematic Diagrams 5-6 FLI2310 (Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 32 Schematic Diagrams 5-7 JACK INPUT (Digital PCB) This Document can not be used without Samsung’s authorization. (PHONE JACK) COMP1_INPUT COMP1_SOUND PC_SOUND COMP2_INPUT COMP2_SOUND MONITOR_OUT DVI_SOUND VIDEO1_INPUT S-VIDEO2_INPUT BOARD TO BOARD CONNECTOR VIDEO2_INPUT VIDEO3_INPUT SIDE AV JACK Samsung Electronics...
- Page 33 Schematic Diagrams 5-8 POWER (Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 34 Schematic Diagrams 5-9 DNIe_PRO_MEM (Digital PCB) This Document can not be used without Samsung’s authorization. +3.3V +3.3V FT1101 FT1102 SGM32F1E104-2A SGM32F1E104-2A FT1103 SGM32F1E104-2A C1125 C1126 C1127 C1128 C1129 C1130 100uF 100nF 47uF 100nF 47uF 100nF +3.3V C1101 C1102 C1103 C1104...
- Page 35 Schematic Diagrams 5-10 Tuner This Document can not be used without Samsung’s authorization. R120 2.4Kohm 1/10W 5-10 Samsung Electronics...
- Page 36 Schematic Diagrams 5-11 ASI510 (Digital PCB) This Document can not be used without Samsung’s authorization. ASI510 Samsung Electronics 5-11...
- Page 37 Schematic Diagrams 5-12 SDA6001 (Digital PCB) This Document can not be used without Samsung’s authorization. ANYNET PHONE JACK 5-12 Samsung Electronics...
- Page 38 Schematic Diagrams 5-13 DNIe3 (Digital PCB) This Document can not be used without Samsung’s authorization. SNI_DQ(0:63) SNI_ADDR(0:10) +3.3V +3.3V_SNI SNI_BANK(0:1) FT1001 SGM32F1E104-2A R1032 SNI_DCLK R1033 SNI_DQM R1034 SNI_NCAS R1035 SNI_NRAS R1036 SNI_NWE C1001 C1002 C1003 C1004 C1005 C1006 100uF 10uF...
- Page 39 Schematic Diagrams 5-14 AUDIO (Digital PCB) This Document can not be used without Samsung’s authorization. IF NOT USE SOUND DELAY CIRCUIT, APPLY R1444 IF USE SOUND DELAY CIRCUIT, REMOVE R1444 NSP6241 5-14 Samsung Electronics...
