SPECIFICATIONS

Operating Frequency Range
U-NII Mid band
Access Method
Signaling Rate
Modulation Type
Carrier to Interference (C/I)
also known as Jitter
Receiver Sensitivity
Operating Range
(All Weather)
Transmitter Power
DC Power
Interface
Protocols Used by Canopy
Protocols Supported by
Canopy
Software Upgrade Path
Network Management
Wind
Temperature
Dimensions
Weight
5.25 to 5.35 GHz and 5.725 to 5.825 GHz
TDD/TDMA
10 Mbps
High Index BFSK
(Optimized for interference rejection)
-4
3dB, 10 BER @ -65 dBm
-4
-83dBm 10 BER
Up to 2 miles with integrated antenna in the 5.2 GHz band. Up to
10 mile with passive reflector in the 5.7 GHz band.
Meets FCC UNII ERP Limit
24 VDC @ 0.3 Amp (active state)
10/100 BaseT, half/full duplex
Rate auto negotiated (802.3 compliant)
IPV4, UDP, TCP, ICMP, Telnet,
HTTP, FTP, SNMP
Switched Layer 2 Transport with support for all common Ethernet
protocols including IPV6, NetBIOS, DHCP, IPX, etc.
Remotely downloaded into FLASH via RF link
HTTP, TELNET, FTP, SNMP
190 km/hr (118 miles/hr)
-40°C - +55°C (-40ºF - +131ºF)
11.75" H x 3.4" W x 3.4" D (29.9 cm H x 8.6 cm W x 8.6 cm D)
1 lb. (.45kg)
