INSTRUCTION MANUAL
FLOOD SENSOR SHV1 – OUTR
The flood sensor is made as a two-state controller designed for monitoring
and indicating fault conditions related to water leakages.
SENSIT s.r.o.
Školní 2610, 756 61 Rožnov pod Radhoštěm, Company ID 64087484, VAT ID CZ64087484, Tel.: +420 571 625 571, Fax: +420 571 625 572
The company is registered in the Commercial Register administered by the Regional Court in Ostrava, Section C, Entry 13728, sensit@sensit.cz, www.sensit.cz
5302.1
10.16
Replaces
Advertisement
Related Manuals for Sensit SHV1
Summary of Contents for Sensit SHV1
- Page 1 Školní 2610, 756 61 Rožnov pod Radhoštěm, Company ID 64087484, VAT ID CZ64087484, Tel.: +420 571 625 571, Fax: +420 571 625 572 The company is registered in the Commercial Register administered by the Regional Court in Ostrava, Section C, Entry 13728, sensit@sensit.cz, www.sensit.cz 5302.1...
- Page 2 SENSIT s.r.o. laboratory (according to EN ISO/IEC 17025 standard) or in an Accredited laboratory. Sensor use: The flood sensors SHV1 are designed for indicating fault conditions (e.g. water leakage) in operations of heat exchange stations and boiler rooms, in production floors, residential houses and offices. Sensors act on the conductivity principle and are capable of detecting fluids with a conductivity higher than 2 mS/m, which enables their use for standard applications with surface water with a conductivity of 5 mS/m and higher.
- Page 3 • EN 61326-1, EN 55011 Declaration of conformity: SENSIT s.r.o. provides the product with the EU Declaration of Conformity issued according to Act No. 90/2016 Coll. and Act No. 22/1997 Coll., as subsequently amended. The product is in accordance with the following directives: •...
- Page 4 Wiring diagram: Technical parameters: Power supply U 15 to 30 VDC/VAC; recommended 24 VDC/VAC Temperature range 0 to 80°C around the head max 100 °C around the sensing electrodes Output signal ON/OFF --- relay output Max. consumption without load approx. 15 mA Max.
-
Page 5: Guarantee Certificate
• That is claimed without the Warranty Certificate or nameplate. Rights and obligations regarding the rights arising from defective performance will be governed by the applicable legislations and the applicable Business Terms and Conditions of SENSIT s.r.o. and this Warranty Certificate. Date of sale confirmation:...
