Page 1: Operating Instructions
PR ES ET /AU TO Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. Digital Disk Recorders Operating Instructions WJ-HD309 WJ-HD316 Model Nos. ST OP PL AY PA US E...
Page 2 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCK- ET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
Page 3: Table Of Contents
PREFACE ... 4 FEATURES ... 4 PRECAUTIONS ... 5 TRADEMARKS AND REGISTERED TRADEMARKS ... 6 ABOUT THESE OPERATING INSTRUCTIONS ... 6 LIMITATION OF LIABILITY ... 6 MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS ... 7 I Front View ... 7 I Rear View ... 9 I On Monitor 1 (To display only live image) ...
Page 4: Preface
While monitoring a multi-screen, each camera picture will be displayed as a moving image. HD316 directly (up to 9 cameras to the WJ-HD309) and it is possible to record their camera pictures. It is also possible to display four or more camera pictures on a single monitor, to switch camera pictures, and to operate cameras using this unit.
Page 5: Precautions
PRECAUTIONS • Refer all work related to the installation of these products to qualified service personnel or system installers. • Do not operate the appliances beyond their speci- fied temperature, humidity, or power source ratings. Use the appliance at temperatures within +5 °C - +45 °C (41 °F - 113 °F) and humidity below 85 %.
Page 6: Trademarks And Registered Trademarks
ABOUT THESE OPERATING INSTRUCTIONS There are 3 sets of operating instructions for the WJ- HD316/WJ-HD309 as follows. • Operating Instructions (book, these operating instruc- tions) • Network Operating Instructions (PDF) •...
Page 7: Major Operating Controls And Their Functions
Toggles the functions of the camera selection buttons. !0 Camera Selection Buttons ([1] - [10/0], [11] - [16] for the WJ-HD316, [1] - [9], [0] for the WJ-HD309) Pressing a button displays live or playback images of the selected camera. The LED in the button indicates the status as follows.
Page 8 When the shift button is lit, these buttons work as the toggled function buttons. (The buttons available as the toggled function buttons will light green when the shift button is lit.) !1 Pan, Tilt, Latest Recorded Image Playback Button (PAN/TILT, GO TO LAST) Pans/tilts the selected camera, or plays back the latest recorded image.
Page 9: I Rear View
To connect combination cameras, connect them to the CAMERA IN 1 - 8 connectors of the WJ-HD316, or the CAMERA IN 1 - 6 of the WJ-HD309 (accept coaxial communication). r Video Output Connectors (CAMERA OUT 1 - 16 for...
Page 10: I On Monitor 1 (To Display Only Live Image)
VGA monitor supports a refresh rate of 50 Hz. If your VGA monitor does not support 50 Hz (or if you are not sure), then turn off your VGA monitor before turning on WJ-HD316/WJ-HD309 when using your television as a dis- play. o Alarm Connector (ALARM) Connect an external device such as a sensor or a door switch with this D-Sub 25-pin connector.
Page 11: (To Display Live Or Recorded Image)
50 Hz. If your VGA monitor does not support 50 Hz (or if you are not sure), then turn off your VGA monitor before turning on WJ-HD316/WJ-HD309 when using your tele- vision as a display. 1. Camera Title Displays the edited camera title.
Page 12 Note: When the camera title and the task bar are lay- ered in this mode, only the task bar will be dis- played. Mode 2 Displays the status on the main bar, the left bar and the right bar. Mode 3 Displays the status only on the main bar, and does not display information on the left bar and the right bar.
Page 13 G Status on the Task Bar • On the Main Bar q Status Display Area q Status Display Area Indicated Item Live Indicates the live image display status Playback Indicates that playback is currently being performed with the displayed playback speed Recording Indicates that recording is currently being performed Search...
Page 14 FAN: The fan is faulty *: Camera number (1 - 16 for the WJ-HD316, 1 - 9 for the WJ-HD309) #: Abbreviation that indicates partition nn: Available disk size n: Number of connector that an external recording device is connected to Note: Refer to page 56 for further information about error types and what to do when an error has occurred.
Page 15 • On the Left Bar Indicated Item Camera Indicates recording and displaying status Grey: Camera currently not displayed or not con- nected to the respective channel Green: Camera displayed on the monitor Orange: Camera currently being recorded Blue: Camera currently being recorded and dis- played on the monitor •...
Page 16: Startup
It is also possible to enter numbers by pressing the camera selection buttons ([1] - [10/0] for the WJ-HD316, [1] - [9], [0] for the WJ-HD309). To move the cursor, press the arrow buttons. Use the same method to enter or edit characters attached to images.
Page 17: Clock Adjustment
CLOCK ADJUSTMENT It is recommended to check the clock periodically and put the clock right if it shows the wrong time. Adjust the clock when displaying a live image. STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO SEARCH TILT LAST SHIFT PAN/TILT SLOW ZOOM/...
Page 18: Shutdown
SHUTDOWN To shutdown the unit, do the following. When recording is being performed, press the REC button for 2 or more seconds. Recording will stop and the indica- tor on the REC button will go off. When playback is being performed, press the STOP button. Playback will stop and the indicator on the PLAY/PAUSE button will go off.
Page 19: Recording (Manual Recording)
RECORDING (Manual Recording) Do the following to record manually. Refer to a system administrator about the required settings for manual recording. STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO SEARCH TILT LAST SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0...
Page 20: Recording Time
G Recording Time The possible recording durations on the following table are just the average values. (Refer to the important notice below the table.) Recording rate for a single camera channel (Recording without audio) Recording Rate [ips] 19 000 9 500 6 300 4 700 3 800...
Page 21: Recording (Emergency Recording)
RECORDING (Emergency Recording) Record manually using an external switch at an emergency event occurrence. For example, install an external switch at the reception counter, and start recording with it when a suspicious indi- vidual appears. Refer to a system administrator about the required settings for emergency recording.
Page 22: Playback
PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT /AUTO [WJ-HD309] STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT TEXT ZOOM/ FOCUS REPEAT DISK SELECT COPY MARK IRIS LISTED PRESET...
Page 23 LAST It is possible to display recorded images in multi-screen format (4/7/9/10/13/16 for the WJ-HD316, 4/7/9 for the WJ-HD309). q Press the SHIFT button. The SHIFT indicator will light. w Press a camera selection button (1 - 6 for the WJ-HD316, 1 - 3 for the WJ-HD309) to select a desired multi-screen.
Page 24 1. Press the SHIFT button. The SHIFT indicator will light. Mark 2. Press the camera selection button 12 (9 for the WJ-HD309) (MARK) at a desired point to be marked during playback. Up to 100 points can be marked. When more than 100 points are...
Page 25: Playback Image On A Designated Disk
The SHIFT indicator will light. normal schedule recording Press the camera selection button 9 (7 for the Recording area for WJ-HD309) (DISK SELECT). event recording and emergency recording The DISK SELECT window will be displayed on monitor 2 and the VGA monitor.
Page 26 STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO Select a disk to be played using the jog dial and move the cursor to "OK" using the arrows button.
Page 27: Playback From A Designated Time And Date
PLAYBACK FROM A DESIGNATED TIME AND DATE It is possible to play recorded images from a designated time and date without stopping recording. Playback images will be displayed on monitor 2 and the VGA monitor. STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO SEARCH...
Page 28: Search And Play
SEARCH AND PLAY There are 3 ways to search for a recorded image and play it. • Search for a recording event and play it (Recording event search) • Search for a motion detected time and date from the recorded images and play it (VMD search) •...
Page 29 Search filter buttons: Filter cancel button: Time and date: Camera channel: Recording event: Text information: Time range of the listed data: Number of the listed data: Search information: G Recording Event Thumbnail Window Time and date: Camera channel/Recording event: Number of the listed data: Note: Some images displayed in the thumbnail window may not match with their respective displayed recorded time due to playing of compressed recorded images.
Page 30 STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO Press the SEARCH button repeatedly until the recording event list window is displayed. TIME&DATE CAMERA REC EVENT TIME&DATE REC EVT 25.APR.03*12:34:56 AM...
Page 31 CANCEL : [ ESC ] Select camera channel numbers (1 - 16 for the WJ-HD316, 1 - 9 for the WJ-HD309) using the arrows button to apply fil- tering. It is possible to select camera channels using the camera selection buttons [1] - [16] for the WJ-HD316 ([1] - [9] for the WJ-HD309).
Page 32: I Search For A Motion Detected Time And Date From Recorded Images And Play It (Vmd Search)
STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO BUSY To stop playback, press the STOP button. The indicator on the PLAY/PAUSE button will go off and playback will be stopped.
Page 33 STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO BUSY cn xvn Press the SET button. I SELECT CAMERA & DATE CAMERA CAM1 START...
Page 34 STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO m.⁄0 Move the cross cursor using the arrows button to a point to be determined as the end point of the motion detection area.
Page 35 ⁄6 ⁄3 ⁄ 5 STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO BUSY ⁄2 ⁄2 Move the cursor to select a detection mode using the arrow buttons and rotate the jog dial to check the radio button next to the selected detection mode.
Page 36: I To Delete The Motion Detection Area
I To delete the motion detection area STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO Rotate the jog dial to select "DELETE AREA" on the status bar. Note: To delete all the motion detection areas, select "DELETE ALL AREA"...
Page 37: I Search For A Marked Point And Play From That Point (Marking Search)
I Search for a marked point and play from that point (Marking search) Display the recording time of the recorded images with a marked point in a list or a thumbnail and select the desired recording time to play. Refer to page 24 for further informa- tion about marking.
Page 38: Monitor Live Images
PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT /AUTO [WJ-HD309] STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT TEXT ZOOM/ FOCUS REPEAT DISK SELECT COPY MARK IRIS LISTED PRESET...
Page 39: I Displaying On A Multi-Screen
I Displaying on a Multi-screen It is possible to display images on a multi-screen (4, 7, 9, 10, 13, 16 for the WJ-HD316, 4, 7, 9 for the WJ-HD309). [WJ-HD316] STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH...
Page 40: I Sequential Display
PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT /AUTO [WJ-HD309] STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT TEXT ZOOM/ FOCUS REPEAT DISK SELECT COPY MARK IRIS LISTED PRESET...
Page 41: Control Cameras
Camera will move slowly by pressing the arrows button while holding the PAN/TILT SLOW button down. Press the camera selection button ([1] - [16] for the WJ-HD316, [1] - [9] for the WJ-HD309) respective to the controlled camera channel to quit the panning/tilting operation.
Page 42: I Iris
Press the arrows button (B) to shift the focus nearer. Auto focus is available by pressing the SET button. Press the camera selection button ([1] - [16] for the WJ-HD316, [1] - [9] for the WJ-HD309) respective to the controlled camera channel to quit the focusing operation.
Page 43: I Move A Camera To The Preset Position
AUTO PAN window will be displayed. Press a camera selection button ([1] - [10/0] for the WJ-HD316, [1] - [9], [0] for the WJ-HD309) to select a desired preset posi- tion. Pressing the camera selection button [10/0] ([0] for the WJ- HD309) moves a camera to the home position.
Page 44: I Auto Function (Auto Pan, Etc)
Note: To move the camera to another registered preset position, press the SET button after selecting a desired preset position number in step 2. The PRESET/AUTO PAN window will not close and it is possible to select another preset number. I Auto Function (Auto Pan, etc) Moves a camera with an auto function set in advance.
Page 45: About The Event Function
ABOUT THE EVENT FUNCTION The event action will be performed when the following events occur. • Motion detection: When motion is detected by the motion detection function (see below), this is stated as an event of motion detection. • Video Loss: When a video signal supply is stopped because of a cable disconnection or malfunction of a camera, this is stated as an event of video loss.
Page 46: I Alarm Function
I Alarm Function G Blinks the ALARM indicator on the front panel ALARM ALARM SUSPEND OPERATE G Switches from the images displayed on monitor 1 and monitor 2 to the images from the location of the alarm occurrence (on a single screen) G Displays the event information in the alarm display area on monitor 1 and the camera...
Page 47: I Cancel The Alarm Action
I Cancel the Alarm Action When an alarm has occurred, this unit will start the alarm action according to the selected alarm action mode. To cancel the alarm action, press the ALARM RESET but- ton. When "ON" is selected for "Alarm Auto Reset" (on the "Alarm Setup"...
Page 48: Copying (Duplicate)
PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT /AUTO [WJ-HD309] STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT TEXT ZOOM/ FOCUS REPEAT DISK SELECT COPY MARK IRIS LISTED PRESET...
Page 49 STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO SEARCH TILT LAST SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET LOGOUT LOGOUT EL-ZOOM /AUTO BUSY Select the "OK" button using the arrows button and press the SET button. The DATA COPY window will be closed and data copy will start.
Page 50: Delete Data On The Disk
DELETE DATA ON THE DISK Perform the settings for the built-in hard disk of the unit, the optional extension unit and the DVD-RAM disk. These are the descriptions of how to delete recorded images on the hard disk and how to format a DVD-RAM disk. Refer to a system administrator for further information about the other disks.
Page 51 STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO BUSY Move the cursor to "Manual Delete for Normal Recording Area" or "Manual Delete for Event Recording Area"...
Page 52: Format (Initialize) A Dvd-Ram Disk
FORMAT (INITIALIZE) A DVD-RAM DISK To copy (duplicate) recorded images onto the DVD-RAM disk, formatting (initializing) the DVD-RAM disk is required in advance. To delete images recorded on the DVD-RAM disk, format- ting (initialization) of the DVD-RAM disk is also required. Important: All data on the disk will be deleted if formatted (initial- ized).
Page 53 STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH SHIFT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT LOGOUT /AUTO BUSY Press the SET button to select "FORMAT". The confirmation dialog window will be displayed. All of data in the COPY1 is going to be erased.
Page 54: Display/Edit Text Information
PAN/ GOTO TILT LAST SHIFT ZOOM/ FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED PRESET EL-ZOOM LOGOUT /AUTO [WJ-HD309] STOP MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SHIFT TEXT ZOOM/ FOCUS REPEAT DISK SELECT COPY MARK IRIS LISTED PRESET...
Page 55 SEARCH SHIFT PAN/TILT ZOOM/ SLOW FOCUS REPEAT DISK SELECT COPY TEXT MARK 10/0 IRIS LISTED EL-ZOOM LOGOUT PRESET /AUTO BUSY [WJ-HD309] STOP PLAY PAUSE MONITOR1 MONITOR2 PAN/ GOTO TILT LAST SEARCH SHIFT TEXT PAN/TILT SLOW ZOOM/ FOCUS REPEAT DISK SELECT...
Page 56: Error/Warnings
ERROR/WARNINGS • The "error" status When a fatal error (one that might cause the system to go down) has occurred, the ERROR indicator will blink red and the error indication will be displayed on the monitor 2. • The "warning" status When an error (even though it has not caused the system trouble yet, but which may become a fatal error) has occurred, the ERROR indicator will blink orange.
Page 57 Indication Status THERMAL Warning POWER Warning #-nn% (available Error disk space is run- Warning ning out) #-FULL (no avail- able disk space) MEDIUM-n Warning REMOVE Error Warning * : Camera number # : Partition number (Refer to page 14.) nn : Available disk space (percentage) n : COPY port number to which an external recording device is connected Note: The available disk space warning will be given only once when the available disk space has reached the set value.
Page 58: Operation Using A System Controller
Note: To perform the operation with buttons with the shadowed background ( troller to light the SHIFT indicator on the right side of the SHIFT button. Item WJ-HD316/WJ-HD309 Open/Close the SETUP MENU Select an item Change the set para-...
Page 59 Item WJ-HD316/WJ-HD309 SETUP Close the search win- /ESC ALARM Alarm reset RESET Alarm suspension ALARM RESET REC - REC STOP Manual recording Press for 2 REC - REC STOP Stop manual recording seconds or more Stop playback/manual – recording PLAY...
Page 60 Filtering off Filtering on Mark a point SHIFT (For the WJ-HD316) Mark a point SHIFT (For the WJ-HD309) Select the normal recording area/event SHIFT recording area of the HDD (For the WJ- HD316) Select the normal recording area/event...
Page 61 Electronic zoom SHIFT (For the WJ-HD309) Text information display ON (For the WJ-HD316) SHIFT Text information display ON (For the WJ-HD309) SHIFT Display the DATA COPY SHIFT menu (For the WJ-HD316) Display the DATA COPY SHIFT menu (For the WJ-HD309)
Page 62: Operation Using A Pc
OPERATION USING A PC It is possible to perform the settings or operate the unit using a web browser installed on a PC when this unit is connected to a network. The available features and the system requirements of a PC are as follows.
Page 63: Operation Of The Unit In The Cascade Connection
OPERATION OF THE UNIT IN THE CASCADE CONNECTION When connecting multiple units (up to 4 units) in the cascade connection, it is possible to monitor images from all of the WJ- HD316/309 in the cascade connection using a monitor. It is necessary in advance to perform the settings to operate the unit in the cascade connection.
Page 64: Installation In The Rack
INSTALLATION IN THE RACK 1. Remove the rubber legs (6 pcs.) on the bottom of the unit. • Use a flat-blade screwdriver and remove the screws. 2. Install the rack mounting brackets on both sides of the unit. • Using the mounting screws (4 pcs.) for the rack mount- ing brackets, fix them firmly.
Page 65: Management Of Users/Hosts
MANAGEMENT OF USERS/HOSTS It is necessary in advance to register users and PCs (hosts) who access this unit via a network such as a LAN. Up to 32 users and 8 hosts can be registered. The following information can be registered as user information and host information. Item Description User name...
Page 66 Notes: • When a user is operating this unit using a PS·Data compatible controller, this user can log in automatically as a PSD user set for "PSD User" of "System" on the SETUP MENU. • When a user logged into this unit using a PS·Data compatible controller and didn’t operate the unit for around 2 minutes, this PSD user will be forced to log out.
Page 67: Operating The Unit For The First Time
OPERATING THE UNIT FOR THE FIRST TIME Important: When connecting an optional extension unit (the WJ- HDE300 series), turn on the power of the extension unit before turning on the power of this unit. Turn on the POWER switch. Press the SET button when the system check complete window is displayed.
Page 68: Preparation For Maintenance (Hdd Replacement, Installation, Etc.)
The camera selection buttons (1 - 16 for the WJ-HD316, 1 - NORMAL 1ips 1ips EXTENDED 1ips 1ips 9, 0 for the WJ-HD309) will light green and orange (for 2 seconds each) alternately. The following window will be displayed after around 30 sec- onds. Event Schedule LIVE...
Page 69 SAFETY MODE window (as shown below) will be displayed. The camera selection buttons on the front panel (1 - 16 for the WJ-HD316, 1 - 9, 0 for the WJ-HD309) will light green and orange (for 2 seconds each) alternately.
Page 70: Connections
CONNECTIONS Important When connecting the Panasonic matrix switcher or the data multiplex unit to this unit, the looped through output signal for every video input signal from them must be supplied to the video input connectors of this unit directly.
Page 71: I Connections With An Extension Unit
I Connections with an extension unit An example of connections is shown below when the unit is used together with an optional extension unit. This unit can be connected with up to seven extension units. Connect the EXT IN port on the rear panel of the extension unit and the EXT STORAGE port on the rear panel of this unit using the cable provided with the optional extension unit.
Page 72: I Connections With Dvd-Ram, Cd-R, And Dvd-R Drives
I Connections with DVD-RAM, CD-R, and DVD-R drives This is an example of connection when the unit is used together with the designated DVD-RAM, DVD-R and CD-R drive. Connect the designated DVD-RAM, DVD-R and CD-R drive and the COPY1 port on the rear panel or the COPY2 port inside the connectors cover on the front panel of this unit using an USB cable (not included).
Page 73: I Connections With The Vtr
I Connections with the VTR When it is necessary to copy the recorded images to a video tape using a VTR, connect the VTR to the S-VIDEO connector (or the VIDEO OUT connector) and the AUDIO OUT connector inside the connectors cover on the front panel of this unit as below. MONITOR1 MONITOR2 TIMER...
Page 74: I Connections With Ps·data Systems
I Connections with PS·Data systems This is an example of connection when the unit is used together with the PS·Data devices. If a connected system controller is PS·Data compatible, it is possible to operate this unit or connected devices using the sys- tem controller.
Page 75 G When installing this unit between a controller and a system device Controller Termination: ON Unit Address : 1 CASCADE AUDIO IN AUDIO OUT G When connecting this unit with a system device SERIAL CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN MONITOR (VGA) ALARM/CONTOROL VIDEO...
Page 76: I Cascade Connection Of Multiple Units
I Cascade connection of multiple units Up to of four units can be connected. For the cascade connection, connect the CASCADE IN connector and the CASCADE OUT connector on the rear panel of each unit as below. Important: • When connecting the unit in the cascade connection, set "Cascade" of "PS·Data Setup" in "Comm" on the SETUP MENU to "ON".
Page 77 G When the PS·Data compatible device is connected to the first unit Monitor 2 CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN BNC Cable (Locally procured) CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN BNC Cable (Locally procured) CASCADE AUDIO IN AUDIO OUT...
Page 78 G When the PS·Data compatible device is connected to the third unit Monitor 2 CASCADE AUDIO IN AUDIO OUT BNC Cable (Locally procured) CASCADE AUDIO IN AUDIO OUT BNC Cable (Locally procured) CASCADE AUDIO IN AUDIO OUT MODE SERIAL ALARM MONITOR OUT CASCADE IN MONITOR (VGA) ALARM/CONTOROL...
Page 79 G When the PS·Data compatible devices are connected to the first and third units Monitor 2 CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN BNC Cable (Locally procured) CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN BNC Cable (Locally procured) CASCADE AUDIO IN...
Page 80: I Connection With The Rs485 Camera
I Connection with the RS485 camera This is an example of connection when the unit is used together with the RS485 devices. Up to eight cameras can be connected using a single RS485 (CAMERA) port. Important: • Terminate both devices on both ends of the connection. Refer to the respective operating instructions for the descriptions of how to terminate.
Page 81 G Daisy connection Multiple cameras can be connected to the RS485 (CAMERA) port. Example: When cameras 1 - 4 are connected to one of the RS485 (CAMERA) port and cameras 9 - 12 are connected to the other RS485 (CAMERA) port. Unit No.
Page 82: I Mode Switch
I Mode Switch RS485 interface is used to communicate between this unit and the PS·Data compatible system device. In this case, it is neces- sary to terminate both devices on both ends of the RS485 connection. The settings of the mode switch will be different depending on whether this unit is used as a receiver or a controller. When an RS 485 camera is connected to this unit, it is necessary to terminate both devices on both ends of the connection.
Page 83: I How To Use The Terminals Of The Alarm/Control Connector
+5 V output Operation Alarm signal output at an event occurrence Only for the WJ-HD316 (Not available for the WJ-HD309) Canceling the alarm display Starting emergency recording disk space a sig- nal input Generation of signal output for disk space alarm-...
Page 84 Synchronizing side (Slave): Set at "EXT" (functioning as an input terminal) (Earth) (Emergency record input) ALARM/CONTOROL (Earth) (External recording mode) ALARM/CONTOROL (Earth) (Sequence changeover output) ALARM/CONTOROL WJ-HD316/WJ-HD309 (First unit) External switch External switch (Earth) (Sequence changeover input) ALARM/CONTOROL WJ-HD316/WJ-HD309 (Second unit)
Page 85 G Connection for the Auto Adjust Time function • When "Auto Adjust Time" of "System" on the SETUP MENU is set to "MASTER" "Time Adjust Output" becomes available and the clock of this unit can be applied to other units. (Earth) (Time adjust output) ALARM/CONTOROL...
Page 86 G Connection with the Uninterruptible Power System (UPS) This is an example of connection with the uninterruptible power system (UPS) to be installed to protect from a power outage. When a signal is supplied to the outage detection I/O terminals from the uninterruptible power system (UPS), internal process- ing (stops recording safely) will be started to shut off the power supply for this unit.
Page 87: I How To Use The Terminals Of The Alarm Connector
Alarm signal will be supplied at an event occurrence Event action will be performed according to the setting. Only for the WJ-HD316 (Not available for the WJ-HD309) Alarm signal will be supplied at an event occurrence Remarks Non-voltage make contact/–100 mA,...
Page 88: Alarm Connection
G Alarm connection When a signal is supplied to the alarm input terminals of CH 1-16, recording and displaying of camera images will be per- formed according to the settings. When an alarm device such as a buzzer, a lamp, etc., is installed outside, connect them to the alarm output terminals (pin nos. 9 - 12, pin nos.
Page 89: I How To Use The Serial Connector
(Female) CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN (Locally procured) 7 (RTS) 8 (CTS) 3 (TXD) 5 (GND) 2 (RXD) WJ-HD316/WJ-HD309 Connection example of cross cable SIGNAL GND MODE COPY 1 SERIAL ALARM POWER MONITOR (VGA) ALARM/CONTOROL DATA...
Page 90: Setup
SETUP To operate this unit, it is necessary to set each item of the SETUP MENU in advance. Perform the settings for each item of the SETUP MENU by displaying the SETUP MENU on monitor 2. Settings items are as below. I Item list of the SETUP MENU Settings menu Maintenance...
Page 91 Settings menu Switcher Monitor1 Perform the settings for the image switching on monitor 1 such as the setting of the sequential display or the screen to be displayed at login on monitor 1. Monitor 2 Perform the settings for the image switching on monitor 2 such as the setting of the sequential display or the screen to be displayed at login on monitor 2.
Page 92: I About The Setup Menu
I About the SETUP MENU SET UP MENU REC Rate Disk Info Version Info Disk End Mode Disk Capacity Date Delete Event Log Error Log Access Log Main menu: These menus are always displayed on the SETUP MENU. Live image: Live images from the camera channel that was selected just before the SETUP MENU was displayed. Main area: The setting items of the selected submenu will be displayed in this area.
Page 93: I Basic Operation With The Setup Menu
I Basic Operation with the SETUP MENU z Press the SETUP/ESC button for 2 seconds or more when displaying live images. [Screenshot 1] The top page of the SETUP MENU will be displayed. SET UP MENU Maintenance Recording Event Schedule Switcher Display Comm...
Page 94: I [Maintenance] Functions For Maintaining
I [Maintenance] Functions for Maintaining Perform the settings for the hard disk drives. It is possible to check the histories (log) of event occur- rence, error occurrence and access. SET UP MENU Maintenance Recording Switcher Display MANU SCHE PRE EVT REC Rate CAM 1 AUTO...
Page 95 G [Disk End Mode] Set actions to be taken when the available hard disk space has run Select an action from the following to be taken when the available space of the built-in hard disk (normal recording area, event recording area, copy area) or the external recording device (DVD-RAM, CD-R or DVD-R disk drive) connected to the copy port (COPY1, COPY2) is running out.
Page 96 G [Event Log] Check the event log The event log (time and date at an event occurrence, details) will be displayed in list form. Refer to page 45 for further information about each event. SETUP MENU Maintenance Recording Switcher Display Time&Date REC Rate Status 25.MAR.03 11:50:11 PM...
Page 97 Indication SMART X-Y PWR LOSS H.METER X-Y PROTECT -# NO DISK -# MEDIUM -# UNFORMATTED -# W-ERR (MEDIUM-#) PWR RECOVER G [Access Log] Check the access log The time, user name and IP addresses when logging in/out to/from this unit will be displayed in list form. SETUP MENU Maintenance Recording...
Page 98: I [Recording]
I [Recording] Perform the settings for the basic recording (REC Setup) and the emergency recording. SETUP MENU Maintenance Recording Switcher Display REC Setup Recording Power ON Manual REC Emergency REC Manual Recording Channel Embedded REC(Title) Embedded REC(Time&Date) REC Priority PRIORITY Audio Allocation AUDIO Audio1...
Page 99 Important: • When a live image from the audio assigned camera channel is displayed on a single screen on monitor 2, audio will be heard. When displaying on a multi-screen, audio will not be heard. • When images from the audio assigned camera channel are displayed on a single screen, recorded audio will be heard.
Page 100: I [Event] Function For Events
I [Event] Function for Events Perform the settings for event actions of each event type (motion detection, video loss, command alarm and terminal alarm). SETUP MENU Maintenance Recording Switcher Display Event Setup Video Loss VMD Setup Terminal/Command Alarm Alarm Setup Terminal Setup G [Event Setup] Settings for the alarm output duration and the buzzer duration...
Page 101 [Screenshot 2] The "VMD Setup" window will be displayed. x Rotate the jog dial to select "SETUP AREA" on the status bar. Note: To set all areas on the monitor as the motion detection area, select "ALL AREAS" and press the SET button.
Page 102 x Move the cross cursor onto an area to be deleted using the arrows button and press the SET button. c To complete the settings, rotate the jog dial to select "EXIT" on the status bar. → The "VMD Setup" window will be closed. 8 Set the sensitivity Set the sensitivity for the created motion detection area.
Page 103 <DURATION> Move the cursor to the parameter box of each area using the arrows button (B) and select a moving dura- tion for an object in each area from the following using the arrows button (C D). --/5 s/10 s/20 s/30 s/40 s/50 s/1 m c To complete the settings, rotate the jog dial to select "EXIT"...
Page 104 8 Alarm Disarm Time The following are possible for the alarm disarm. 2 s - 10 s (in 1 second intervals) G [Terminal Setup] Perform the settings for the alarm terminal polarity. Select how to supply the signal to the alarm terminal. SETUP MENU Maintenance Recording...
Page 105: I [Schedule] Settings For The Recording/Event Action Schedule
I [Schedule] Settings for the recording/event action schedule Perform the settings for the recording schedules of record- ing and event action by designating a day of the week and time. A day can be divided into up to 6 time zones, and record- ing programs and event action programs can be assigned to each time zone to create a recording schedule.
Page 106 8 Recording Rate and Image Quality for Each Camera Channel Perform the settings for recording rate, image quality and recording duration for each camera channel (only for pre- event recording and post-event recording). Perform the settings for each recording mode. Assign the recording rate for each camera channel as described in "Recording Rate for Each Recording Mode"...
Page 107 • When a pre-recording area is created in an optional extension unit (WJ-HDE300 series), it is possible to per- form pre-event recording for up to 60 minutes accord- ing to the resolution, recording rate and disk space for pre-event recording. Refer to page 135 for descriptions of how to create the pre-recording area.
Page 108 8 Terminal/command alarm Perform the settings of an event action at a terminal/com- mand alarm occurrence or the settings of the auto copy function. The contents to be set are the same as the settings for "VMD" above. SETUP MENU Maintenance Recording Switcher...
Page 109 n Select OK using the arrows button and press the SET button. Notes: • The start time and end time can be set in 15 min- utes intervals. • To copy a timetable that is set for a different day of the week, select "Copy the Other Time Table"...
Page 110: I [Switcher] Settings For The Switcher Function
1 - 4 on a 4-split screen. 5 - 8: Displays images from camera channels 5 - 8 on a 4-split screen. 9-9 (only for the WJ-HD309): Displays an image from camera channel 9 on the upper left area on a 4-split screen.
Page 111 4-split screen. QUAD5 - 8: Displays images from camera channels 5 - 8 on a 4-split screen. QUAD9 (only for the WJ-HD309): Displays an image from camera channel 9 on the upper left area on a 4-split screen.
Page 112 G [Monitor 2] Switcher function of monitor 2 Perform the settings for the switcher function of monitor 2. SETUP MENU Maintenance Recording Switcher Display Live Sequence Monitor 1 Sequence Timing Monitor 2 Auto Skip Login Screen 8 Live Sequence The settings for "Live Sequence" are the same as for "Monitor1".
Page 113: I [Display]
I [Display] Perform the display settings for monitors 1 and 2 connected to the unit. SETUP MENU Maintenance Recording Event Schedule Switcher Display Comm System Camera Title SETUP OSD Setup Time & Date Display Position L-UPPER Monitor 1 Camera Title Display Position R-LOWER Monitor 2 Line Color on the Multi Screen...
Page 114 3. Move the cursor to "OK" using the arrows button and press the SET button. The camera title will be copied. • The following characters can be entered for a cam- era title: 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h i j k l m n o p q r s t u v w x y z À...
Page 115 8 Camera Title Display Select ON and OFF whether or not to display the camera title. ON: Displays the camera title. OFF: Does not function. 8 Alarm Display Select ON and OFF whether or not to activate the alarm dis- play at an event occurrence.
Page 116: I [Comm] Settings For Communication With Other Devices
• When using the coaxial communication to control cam- eras, connect cameras to the VIDEO IN connectors 1 - 8 for the WJ-HD316 (1 - 6 for the WJ-HD309) (coaxial communication compatible). When controlling cameras connected to other VIDEO IN connectors with coaxial communication, use a coaxial communication unit (WJ- MP204).
Page 117 8 Baud Rate Select the communication speed for data transmission with a connected device from the following. 2 400/4 800/9 600/19 200/38 400 bps 8 Data Bit It is impossible to change the value for this setting. 8 bit 8 Parity Select a method to check a transmission error at communi- cation from the following.
Page 118 8 Baud Rate Select the communication speed for data transmission with a connected device from the following. 4 800/9 600/19 200 bps 8 Control Camera CH It is possible to assign camera channels to the RS485 ports 1 and 2 as shown below. [Screenshot 1] Start operation from the "RS485 Setup"...
Page 119 8 Data Bit Select a data length for communication from the following. 7/8 bit 8 Parity Select a method to check a transmission error at communi- cation from the following. NONE: No parity check EVEN: Even parity ODD: Odd parity 8 Stop Bit Select a stop bit from the following.
Page 120 8 DNS Select "MANUAL" or "AUTO" to enable searching for an IP address by its host name using DNS. When "OFF" is select- ed for "DHCP" (no use of the DHCP server), select "MANU- AL" and enter the domain name and the DNS server address.
Page 121: I [System] Settings On System
I [System] Settings on System Perform the following system settings required to operate this unit. G [Basic Setup] Basic system settings Perform the following settings for basic operation. SETUP MENU Maintenance Recording Event Schedule Switcher Display Comm System ADMIN Password Basic Setup ***** Time &...
Page 122 8 Shutdown Time Select a waiting time before starting the internal processing against the power outage after an outage detection signal has been supplied to the unit from the following. 10 s/20 s/30 s/1 m/2 m/3 m/4 m/5 m 8 Auto Copy ON or OFF whether or not to copy recorded images to the copy area on the hard disk automatically.
Page 123 4-split screen. QUAD5 - 8: Displays images from camera channels 5 - 8 on a 4-split screen. QUAD9 (only for the WJ-HD309): Displays an image from camera channel 9 on the upper left area on a 4-split screen.
Page 124 CAM16 EDIT QUAD5 - 8: Displays live images from camera channels 5 - QUAD9 (only for the WJ-HD309): Displays an image from QUAD9 - 12 (only for the WJ-HD316): Displays live QUAD13 - 16 (only for the WJ-HD316): Displays live...
Page 125 9SCREEN10 - 16 (only for the WJ-HD316): Displays images from camera channels 10 - 16 on a 9-split screen. 16SCREEN (only for the WJ-HD316): Displays images from camera channels 1 - 16 on a 16-split screen. SEQ: Images will be displayed in the sequential display. 8 Camera Partitioning Select a controllable range for each camera channel from the following.
Page 126 G Functions that can be enabled/disabled The following functions can be enabled/disabled according to the user level. Function WJ-HD300 Setup WJ-HD300 Setup Status Camera Setup Event Log Status Error Log Status Access Log Status Alarm Reset Alarm Suspend Copy Normal Recording Erase Event Recording Erase Manual REC Operation Playback Operation...
Page 127: Display Setup Menu Of Camera
Press any one of the PAN/TILT button, the ZOOM/FOCUS button, the IRIS button, the PRESET/AUTO button and the cam- era selection buttons 4 - 16 for the WJ-HD316 (4 - 9 for the WJ-HD309) to complete the camera setting.
Page 128: Disk Management
DISK MANAGEMENT I Notes on the hard disk Camera images are recorded into the built-in hard disk of this unit. There are two hard disks in this unit. In case one of them malfunctions during recording, it is possible to keep record- ing with the other hard disk (mirror function).
Page 129 2. Remove the cable from the front panel. Front panel connector 3. Remove the screws fixing the mounting unit, and then pull the hard disk drive mounting angle toward you. Hold these tabs and pull Screws Only the upper and lower holes on both sides will be used when fixing by screws even though there are 3 holes each on both sides.
Page 130 When replacing the hard disk drive without turning off the power of the unit. z Close the SETUP MENU after selecting "ON" for "HDD Safety Mode" of "Disk Info" on the "Maintenance" menu. → The HDD SAFETY MODE window will be displayed. x The procedures are different between the replacement of the hard disk of the unit and the replacement of the hard disk of the optional extension unit.
Page 131: I About The Hdd Disk Menu
I About the HDD DISK MENU The operations regarding the hard disk can be performed by displaying the "HDD DISK MENU" on monitor 2. The "HDD DISK MENU" will be displayed when the SET button is pressed while displaying the system check complete window. The "HDD DISK MENU"...
Page 132: I Raid 5 Function Of The Extension Unit
I RAID 5 Function of the Extension Unit Summary of the RAID 5 function (Redundant Arrays for Independent Disks, independent data disks with distributed parity blocks) It is possible to use the RAID 5 function with an optional extension unit. RAID level 5 regards 3 or more drives as one drive, and it is possible to read data by attaching error correction data even though one of the drives is broken automatically.
Page 133: I Formatting (Initialization) The Hard Disk
Enter the password for an administrator by rotating the jog dial. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 134 Information of recording areas : [SETUP/ESC] OK : [SET] istrator. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 135 [Screenshot 4] The "DISK SELECT" menu will be displayed. When using the RAID 5 function, the "UNIT SELECTION" menu will be displayed. HDD DISK MENU Digital Disk Recorder WJ-HD300 THE CANDIDATE FOR A FORMAT DISK SELECT Select HDD to be formatted,and press [SET]key. MAIN 160GB M 160GB M...
Page 136 [Screenshot 7] The "PRE RECORDING AREAS" menu will be displayed. Digital Disk Recorder HDD DISK MENU WJ-HD300 DISK SETTING METHOD 10CH 11CH 12CH 13CH HDD Total capacity:160GB RETURN: [SETUP/ESC] OK : [SET] ⁄0 Select the camera channel for pre-event recording using the arrows button and assign the disk space to the selected pre-recording area by rotating the jog dial.
Page 137: I Setting For Mirroring
Enter the password for an administrator by rotating the jog dial. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for the password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 138 Information of recording areas : [SETUP/ESC] OK : [SET] jog dial. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 139 Enter the password for an administrator by rotating the jog dial. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 140 Enter the password for an administrator by rotating the jog dial. The camera selection buttons ([1] - [10/0] for the WJ- HD316, [1] - [9], [0] for the WJ-HD309) are available to enter numbers for password. The same method is used to enter, insert and delete characters as for attaching text information to images.
Page 141: Serial (Rs232C) Connector Command Reference
SERIAL (RS232C) CONNECTOR COMMAND REFERENCE I SERIAL (RS232C) Communication Protocol With the SERIAL (RS232C) interface, you can control functions of this unit by transferring the specified commands from a per- sonal computer (PC) to this unit. Notes: • This unit does not support the communication converted between the SERIAL (RS232C) and USB interface. •...
Page 142 • When an ANSWER command is required The unit sends back the status or data, as shown in the figure. Transmission command (→ The unit) [STX] Status inquiry command Transmission command (→ The unit) [STX] Version inquiry command • About ACK code After receiving a command from the PC, the unit sends back the ACK code to the PC in 20 ms or less.
Page 143 (9) (PC -> This unit) Logout. [STX]AD001;OLO [ETX] When receiving the command above, the user logged in via SERIAL (RS232C) (ADMIN) will log out. (10) (This unit - > PC) Response against (9). [STX]AD001;OLO[ETX] Note: The character code of [STX], [ETX] and [SP] are as follows. [STX]: 02h [ETX]: 03h [SP] (space): 20h...
Page 144 CASCADE AUDIO IN AUDIO OUT MONITOR OUT CASCADE IN MONITOR (VGA) ALARM/CONTOROL DATA VIDEO This unit As viewed from the rear of the WJ-HD316/WJ-HD309 Pin No. D-sub Pin 9 (Female) SIGNAL GND MODE COPY 1 POWER RS485(CAMERA) 10/100BASE-T EXT STORAGE...
Page 145 Basic Operation Item Transmission command (ASCII) Forward a field Rewind a field Pause during playback Play Manual recording ZMR:nn:ddd ... ddd Manual recording with text Stop OSP:n Skip & play forward OSF:n Skip&play reversely OSR:n Record No. Search and ZPR:rrrrrrrrrrrrrrrr:mm playback Time &...
Page 146 Item Transmission command (ASCII) Electronic zooming OZM:m Start sequence OQT:01F Stop sequence OQS:0 Disk selection ZDS:k Marking Alarm Control Item Transmission command (ASCII) Alarm input OAI:b Alarm input with text ZAI:b nn:ddd ... ddd Alarm reset OAL;n Alarm suspension MAD:n Alarm change information –...
Page 147 Data Control Item Transmission command (ASCII) Copy by specifying ZCR:rrrrrrrrrrrrrrrr:m record Copy by specifying date ZCT:y & time :s:ccc:m Data copy completed – Cancel data copy Erase log ZLC:k Log data total number ZLQ:k:y inquiry Log readout ZLR:yyyymmdd hhnn:mmmmmmmm Record list acquisition ZGR:yyyymmddnn :nnnnnnnn Text acquisition...
Page 148 HDD normal recording sector p=2 HDD event recording sector p=3 HDD copy sector p=4 Disk connected to COPY 1 p=5 Disk connected to COPY 2 sss: Additional disk space (%) QID:WJ-HD309 QID:WJ-HD316 QIB:WJ-HD309 QIB:WJ-HD316 QIC:2 QLD:n n=0 (No alarm)
Page 149 Item Transmission command (ASCII) Response command (ASCII) Recording mode inquiry Monitor status inquiry Recording status inquiry Record number informa- – tion Camera SYNC status QSY:a1a2a3a4a5 inquiry :b1b2b3b4b5 Parameter (ASCII) zqm: Monitor status: camera CH: Playback time Monitor status n=0 Live n=1 Live sequence n=2 Playback n=3 Other statuses...
Page 150 Item Transmission command (ASCII) Response command (ASCII) Record information ZGP:rrrrrrrrrrrrrrrr inquiry Communication Item Transmission command (ASCII) Communication check Parameter (ASCII) ZGP:rrrrrrrrrrrrrrrr: rrrrrrrrrrrrrrrr: Record number ccc:q:nnnn:yyyymmdd ccc: Camera CH hhnnss:nnss:t:ssssss q: picture quality (0 (Very Fine), 1 (Fine), 2 (Normal), 3 (Extended)) nnnn: Recording rate yyyymmddhhnnss: Recording start date and time...
Page 151: Flowchart Of The Setup Menu
FLOWCHART OF THE SETUP MENU Maintenance Recording REC Rate REC Setup Maintenance Recording Disk Info Emergency REC Maintenance Version info Maintenance Disk End Mode Maintenance Disk Capacity Maintenance Disk Delete Maintenance Event Log Maintenance Error Log Maintenance Access Log Maintenance Monitor 1 OSD Setup Monitor 1...
Page 152: Parameters And The Default Settings Of The Setup Menu
PARAMETERS AND THE DEFAULT SETTINGS OF THE SETUP MENU These are the setting parameters and the default settings of the items on the SETUP MENU. Refer to these as reference. Setup Menu Setup Item Maintenance Disk Info Warning for Disk Life Time HDD Safety Mode Disk End Mode Normal Recording Area...
Page 153 Setup Menu Setup Item Event Setup Buzzer Monitor1 Action Monitor2 Action VMD Setup (SETUP AREA) (SETUP ALL AREA) (DELETE AREA) (DELETE ALL AREA) (SENSITIVITY) (VMD MODE) (EXIT) Alarm Setup Alarm Auto Reset Alarm Disarm Time Terminal Setup Terminal Setup Schedule Time Table Period REC PROGRAM...
Page 154 Time & Date Display Position Camera Title Display Position Line Color on the Multi Screen Parameter 1/1 to 12/31 MON/TUE/WED/THU/FRI/SAT/SUN [Operating with the buttons of the unit] WJ-HD316: 1/2/.../16/1-4/5-8/9-12/13-16/1-9/10-16/-- WJ-HD309: 1/2/.../9/1-4/5-8/9-9/1-9/-- [Operating via a network] WJ-HD316: CAM1/CAM2/.../CAM16/QUAD1-4/QUAD5-8/ QUAD9-12/QUAD13-16/9SCREEN1-9/ 9SCREEN10-16/-- WJ-HD309: CAM1/CAM2/.../CAM9/QUAD1-4/QUAD5-8/ QUAD9/9SCREEN/-- --/1/2/.../64...
Page 155 Setup Menu Setup Item Monitor1 Time & Date Display Camera Title Display Alarm Display Monitor2 Display Mode T&D and Status Display Position Camera Title Display Comm Camera Control COMP TYPE PS·Data Setup Unit Address(System) Unit Address(Controller) Cascade Baud Rate Data Bit Parity Stop Bit Retry Timing...
Page 156 Setup Menu Setup Item NW Setup2 User Name User Password Access Interval Host Name Domain Name Network SNMP COMMUNITY Setup CONTACT SYSTEM NAME LOCATION NTP Setup Time Adjustment Time Zone NTP Server Address Refresh Interval Network FTP Setup FTP Server Address User Name User Password Mode...
Page 157 Event Recording Erase Manual REC Operation Playback Operation N/W Access Parameter YY.MM.DD/MMM.DD.YY/DD.MMM.YY 24 h/12 h ON/OFF 0:00/1:00/.../23:00 1/2/3 1/2/.../16 WJ-HD316 CAM1/CAM2/.../CAM16/QUAD1-4/QUAD5-8/ QUAD9-12/QUAD13-16/7SCREEN/9SCREEN1-9/ 9SCREEN10-16/10SCREEN/13SCREEN/ 16SCREEN/SEQ WJ-HD309 CAM1/CAM2/.../CAM9/QUAD1-4/QUAD5-8/ QUAD9/7SCREEN/9SCREEN/SEQ --/View/View/Operate 1/2/3 1/2/.../16 WJ-HD316 CAM1/CAM2/.../CAM16/QUAD1-4/QUAD5-8/ QUAD9-12/QUAD13-16/7SCREEN/9SCREEN1-9/ 9SCREEN10-16/10SCREEN/13SCREEN/ 16SCREEN/SEQ WJ-HD309 CAM1/CAM2/.../CAM9/QUAD1-4/QUAD5-8/ QUAD9/7SCREEN/9SCREEN/SEQ --/View/View/Operate LV1,LV2,LV3...
Page 158: Troubleshooting
TROUBLESHOOTING Check the following before requesting repair. Contact your dealer if a problem cannot be solved even after checking and trying the solution or a problem is not described below, and when having a problem with installations. Problem Power is not turned on. The HDD SAFETY MODE win- dow is displayed after turning on the power of the unit.
Page 159 Coaxial communication control is available for cam- eras connected to VIDEO IN 1 to 8 for the WJ-HD316 (1 to 6 for the WJ-HD309). • Check if the camera you are going to control is a combina- tion camera.
Page 160 Problem Alarm operations are not acti- vated. "VIDEO LOSS" appears on the monitor. "THERMAL" appears on the monitor. The clock does not keep cor- rect time. When you turn on the power of the unit, the HDD DISK MENU is displayed. Check item/Remedy •...
Page 161 Problem The additional disk space of HDD is not displayed. The available disk space of HDD is not displayed on the right bar. Cannot establish a connection via the network. Response or Image update takes time. Rebooting of the unit occurs while displaying the splash startup screen.
Page 162: Specification
SPECIFICATION General Power source: Power consumption Ambient operating temperature Ambient operating humidity Dimensions Weight Input/Output Video Video input connectors Cascade input connector Video output connectors Monitor output connectors Monitor output connector (VGA) S-video output connector Video output connector (front panel) Audio Audio input connectors Audio output connectors...
Page 163: Standard Accessories
STANDARD ACCESSORIES CD-ROM* ... 1 Operating Instructions (this manual) ... 1 The following are for installation: Power Cord ... 2 Rack Mounting Bracket ... 2 Screw for Rack Mounting Bracket ... 4 Cable Clamp ... 1 Screw for Cable Clamp ... 1 Hard Disk Drive Fixing Screw ...
Page 164 Matsushita Electric Industrial Co., Ltd. Osaka, Japan http://www.panasonic.co.jp/global/ NM0104-2034 3TR001707CAA Printed in Japan 2004 © Matsushita Electric Industrial Co., Ltd. All rights reserved.

This manual is also suitable for:

Wj-hd316

Panasonic WJ-HD309 Operating Instructions Manual

Quick Links

Operating Instructions

Related Manuals for Panasonic WJ-HD309

Summary of Contents for Panasonic WJ-HD309

This manual is also suitable for:

Table of Contents
