Designed for Panasonic DVD Home Theater Sound Systems that
are compatible with the SH-FX67.
Dear customer
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully.
Before connecting, operating or adjusting this product, please read
the instructions completely.
Please keep this manual for future reference.
System
Digital transmitter
Wireless system
P
PC
SH-FX67
SH-FX67T
SE-FX67
Operating Instructions
Model No.

Table of Contents

Introduction
IMPORTANT SAFETY INSTRUCTIONS................................................3
Accessories............................................................................................4
Use
Setup......................................................................................................5
Connections ........................................................................................6
Making the wireless link ......................................................................8
Using the surround back speakers......................................................9
Reference
Product service ....................................................................................10
Maintenance ........................................................................................ 10
Troubleshooting guide ..........................................................................10
Specifications.......................................................................................11
Limited Warranty (ONLY FOR U.S.A.)..................................................12
Limited Warranty (ONLY FOR CANADA) .............................................14
Wireless System
SH-FX67
RQTX0125-1P

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SH-FX67

Summary of Contents for Panasonic SH-FX67

  • Page 1: Table Of Contents

    Designed for Panasonic DVD Home Theater Sound Systems that are compatible with the SH-FX67. Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Before connecting, operating or adjusting this product, please read the instructions completely.
  • Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Responsible Party: Panasonic Corporation of North America One Panasonic Way Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company Telephone No.: 1-800-211-7262...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. Read these instructions. Keep these instructions. Heed all warnings.

  • Page 4: Accessories

    The model number and serial number of this product can be found on either the back or the bottom of the unit. Please note them in the space provided below and keep for future reference. MODEL NUMBER SH-FX67 SERIAL NUMBER...

  • Page 5: Setup

    Wireless system Surround speaker cables (included) Surround speakers and surround back speakers are not included. This placement offers 7.1-channel playback. Your home theater unit must be capable of 7.1-channel playback. LS: Surround (left), RS: Surround (right) ≥Place on the side of the seating position.

  • Page 6: Connections

    When this happens, the wireless link indicator (“ [W1] ” or an indicator) flashes on the home theater unit, and there is a brief interruption in audio coming from the surround speakers. This is the normal operation of the product working to assure the best possible performance of your home theater unit.
  • Page 7 ∫ Preparation If the surround speaker cables (with a blue connector and a grey connector) have already been connected, disconnect the surround speaker cables from your home theater unit. Connecting the speakers to the wireless system SPEAKERS Connect to terminals of the same color.

  • Page 8: Making The Wireless Link

    ≥ Make sure that the speaker and AC cord connections are completed, and the surround selector is set to the “SURR” position (➜ page 7). ≥ Turn on the home theater unit and SH-FX85, and then reduce the volume. Turn on SE-FX67.

  • Page 9: Using The Surround Back Speakers

    Using the surround back speakers [Compatible model: e.g. SC-BT100] To activate the additional SH-FX67 for 7.1ch-setup, it is necessary to be paired to work with the other SH-FX67. Use only the SH-FX67T transmitter card. Wireless system is originally paired to work with the SH-FX67T transmitter card that comes along with it.

  • Page 10: Product Service

    For product information or assistance with product operation: In the U.S.A., refer to “Customer Services Directory” on page 13. In Canada, contact the Panasonic Canada Inc. Customer Care Centre at 1-800-561-5505, or visit the website (www.panasonic.ca), or an authorized Servicentre closest to you.

  • Page 11: Specifications

    Specifications AMPLIFIER SECTION Output power RMS output power 125 W per channel (3 ≠), 1 kHz, 10 % THD Surround Ch Total RMS power FTC output power 34 W per channel (3 ≠), 120 Hz to 20 kHz, 1 % THD Surround Ch Total FTC power GENERAL...

  • Page 12: Limited Warranty (Only For U.s.a.)

    Carry-In or Mail-In Service For Carry-In or Mail-In Service in the United States call 1-800-211-PANA (1-800-211- 7262) or visit Panasonic web site: http://www.panasonic.com For assistance in Puerto Rico call Panasonic Puerto Rico, Inc. (787)-750-4300 or fax (787)-768-2910. Panasonic Puerto Rico, Inc.
  • Page 13 Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST. For hearing or speech impaired TTY users, TTY : 1-877-833-8855 Accessory Purchases Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com...

  • Page 14: Limited Warranty (Only For Canada)

    Limited Warranty (ONLY FOR CANADA) Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to replace the product for a period as stated below from the date of original purchase. Panasonic Portable / Clock Radio (without Tape, CD, MD)
  • Page 15 Memo...
  • Page 16 If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. Panasonic Consumer Electronics Company, Division of Panasonic Corporation of North America One Panasonic Way Secaucus, New Jersey 07094 http://www.panasonic.com...
