Panasonic WV-CM1020 Specifications

Rack-mountable Compact Color CRT Monitor
The WV-CM1020 is a compact CRT monitor offering a 22 cm viewable size screen and 300 TV lines of horizontal
resolution. Using multiple units can form a Multiscreen with superior picture quality to Quad or 16 split screen using a
digital screen splitter. It is also a perfect choice for a console-mounted monitor, a space-saving solution for multi-
camera installations. The metal cabinet is ideal for heavy-duty environments, and with the optional Rack Mount
Bracket WV-Q52A, it fits perfectly into an EIA 19 inch Rack, enabling use in a machine room for maintenances etc.
The On Screen Display makes image adjustment easy with a choice of English, French or German.
Its picture quality, reliability and installation flexibility make it one of the well-accepted CCTV monitors in the market.
Key Features
• CRT size: 25 cm (10") diagonal
• Viewable size: 22 cm (9") diagonal
• Horizontal Resolution: 300 TV lines at center
• Scanning: Interlace, Horizontal 8 %, Vertical 6 % over scan (typical)
• Color temperature: 9,300 °K (NTSC), 6,500 °K (PAL)
• Composite Video input: 2x Composite Video Inputs (BNC) with auto
termination loop through outputs (BNC)
• Audio input: 1x –8 dB / Hi-Z, (RCA pin jack) with loop through output
(RCA pin jack)
• Speaker: 0.5 W
• Adjustment using OSD setup menu: BRIGHT, CONTRAST,
PICTURE, COLOR, TINT (NTSC only) by setup menu
• Multi-language setup menus: English, French, German (PAL only),
Spanish (NTSC only)
• Heavy duty metal cabinet
• Rack-mountable using optional rack mount bracket WV-Q52A.
22 cm (9") Color CRT Monitor
WV-CM1020
WV-CM1020
(120 V AC)
Standard Accessories
• Operating Instructions .................. 1 pc.
• Power Cord .................................. 1 pc.
Optional Accessory
EIA19 inch Rack Mount Bracket
WV-Q52A
(up to two monitors)
WV-CM1020
(220 ~ 240 V AC)
