Non-Sound Decoders Specifications
Operational Modes
Bluetooth BLE Supported
DCC Supported
DC Supported (Motor Control Only)
Electrical Limits
Track Voltage Maximum
Motor Current Maximum Continuous
Motor Current Peak
Function Output HFO1, 2 Voltage and Maximum Current
Decoder SUM Current Maximum Continuous
Physical
Dimensions
Termination
Check Decoder Types for full information re the availability of HFO/AUX connections per Decoder... note they are not all the same!!!
To be added...
HM7000-18 R7401 ... Next18 Non-Sound Decoder
HM7000-21 R7402 ... 21pin Non-Sound Decoder
... physical size to be confirmed.
KBW/CR
Version R1.0
140323
HM7000-8
In DCC mode only... In Bluetooth mode the decoder waits for a valid Bluetooth Signal
-14VDC @ 100mA (All Decoders) Note: HM7000-6 only supports HFO1 & HFO2
8mm x 21.5mm x4 mm
8mm x 22.5mm*** x 4mm
NEM 652 8 pin
Take me back to Top....
HM7000-6
All Decoders
All Decoders
27V (All Decoders)
1000mA (All Decoders)
1500mA (All Decoders)
1000mA (All Decoders)
*** including pin length, pcb length is 17mm
NEM651 6 pin
Page 128 of 130
