- Page 1 FLOOR GLUTE HAMSTRING DEVELOPER GBFGHD 400939 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 ASSEMBLY PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION MAIN FRAME FIXING FRAME BASE FRAME ADJUSTABLE FRAME SUPPORT FRAME FOAM BAFFLE CROSS CONNECTION CUSHION FRAME CONNECTION FRAME SEMICIRCLE CUSHION PEDAL FOAM...
- Page 3 HARDWARE PACK...
- Page 4 HARDWARE PACK...
- Page 5 ASSEMBLY INSTRUCTIONS STEP 1 1. Assemble Base Frame (2) with Main Frame (1), Using Flat Washer Φ11*Φ20*2 (35), Spring Washer Φ10 (31) and Hex Bolt M10*25 (26). 2. Connect Support Frame (3) with Base Frame (2) and Main Frame (1), Using Flat Washer Φ11*Φ34*3 (36), Flat Washer Φ11*Φ20*2 (35), Nut M10 (33) and Hex Bolt M10*95 (29).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 2 1. Remove the Plastic Sleeve (17) from the Vertical Connection Frame (5), then assemble Vertical Connection Frame (5) with Support Frame (3), reinstall the Plastic Sleeve (17) and fixing by Hexagon socket head bolt M6*10 (22). 2.
- Page 7 ASSEMBLY INSTRUCTIONS STEP 3 1. Connect the Cushion (13) to Support Frame (3), using Flat Washer Φ11*Φ20*2 (35), Spring Washer Φ10 (31) and Hex Bolt M10*70 (28). 2. Connect the Semicircle Cushion (14) to Cross Connection Frame (4), using Flat Washer Φ11*Φ20*2 (35), Spring Washer Φ10 (31) and Hex Bolt M10*60 (27).
-
Page 8: Rubber Mat
APPENDIX - FULL ASSEMBLY/EXPLODED VIEW/ FULL PARTS LIST DESCRIPTION DESCRIPTION MAIN FRAME HOLLOW SLEEVE BASE FRAME END CAP 40*40*2MM SUPPORT FRAME END CAP 50*75*2MM CROSS CONNECTION HEX SOCKET HEAD BOLT M6*10 FRAME CONNECTION FRAME HEX SOCKET HEAD BOLT M6*20 PEDAL PAN HEAD, HEX BOLT M8*20 FIXING FRAME HEX BOLT M8*45... - Page 9 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 10 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
