- Page 1 Versa M340/E2000 Disassembly Manual...
-
Page 2: Table Of Contents
Removing the LCD Module ..........................15 Removing the LCD Panel.............................17 Removing the Top Cover .............................19 Removing the Touch Pad.............................20 Removing the Main Board............................21 Removing the Speaker Assembly ........................23 DIP Switch Settings ..............................24 Screws..................................25 Notice ...................................26 NEC Versa M340/E2000 Disassembly Manual Page 2... -
Page 3: Overview
Furthermore, the screws that are removed are shown next to the image of the parts themselves. NEC reserves the right to make changes to the Versa M340/E2000 chassis without notice. Technician Notes Only technicians authorized by NEC Computers International BV should attempt to repair this equipment. -
Page 4: Hazardous Voltage
Inside the power supply are hazardous avviare il sistema senza aver prima messo a voltages that can cause serious personal injury. Always posto il coperchio return a defective power supply to your dealer. NEC Versa M340/E2000 Disassembly Manual Page 4... -
Page 5: Removing The Battery
Removing the Battery Perform the following steps to remove the battery: 1. Make sure to power off the Versa M340/E2000. 2. Turn the unit upside down. 3. Unlock the battery and slide it out of its place as the arrow shows in Fig. 1 Fig. -
Page 6: Removing The Memory Module
Fig. 2 Removing the screw retaining the memory module slot cover 2. Unclip the memory module as shown in Fig. 3 Fig. 3 Removing the memory module 3. Remove the memory module from its slot and put it aside. NEC Versa M340/E2000 Disassembly Manual Page 6... -
Page 7: Removing The Hard Disk Drive
2. Release the screws that secure HDD module as shown in Fig. 5 and carefully pull the HDD module out from the base unit. M3x5 Black Fig. 5 Screw retaining the HDD module NEC Versa M340/E2000 Disassembly Manual Page 7... -
Page 8: Removing The Keyboard
1. Release the keyboard cover from the rear of the system by pulling it from the gaps on LCD hinge as shown in Fig. 6 Fig. 6 Releasing the keyboard cover 2. Lift up the keyboard cover carefully as shown in Fig. 7 Fig. 7 Lifting up the Keyboard Cover NEC Versa M340/E2000 Disassembly Manual Page 8... -
Page 9: Removing The Optical Disk Drive
Battery) and remove the Keyboard (see Removing the Keyboard) then perform the following steps: 1. Remove the screws retaining the optical drive as shown in Fig. 9 M2.5x5 Black Fig. 9 Releasing the optical drive NEC Versa M340/E2000 Disassembly Manual Page 9... - Page 10 2. Flip over the unit, release screw retaining ODD module and then push it out from the base unit as shown in Fig. 10 M2.5x5 Black Fig. 10 Pushing the optical drive out from the base unit NEC Versa M340/E2000 Disassembly Manual Page 10...
-
Page 11: Removing The Wlan Card Module
A = M2.5x5 Silver B = M2.5x5 Black Fig. 11 Heat Plate 4. Remove the wireless antenna connector and release the WLAN Card Module as shown in Fig. 12 Fig. 12 Wireless Card Module NEC Versa M340/E2000 Disassembly Manual Page 11... -
Page 12: Removing The Mdc Modem
Fig. 13 Heat Plate 2. Release screws and disconnect cable on MCD Modem as shown in Fig. 14 M2.5x5 Black Fig. 14 MDC Modem 3. Lift up the MDC modem and put it aside. NEC Versa M340/E2000 Disassembly Manual Page 12... -
Page 13: Removing The Cpu
B = M2.5x5 Black Fig. 15 Removing the screws retaining Heat Plate 2. Remove the CPU Fan screws, disconnect the CPU Fan connector and remove the CPU Fan. M2.5x5 Silver Fig. 16 CPU Fan NEC Versa M340/E2000 Disassembly Manual Page 13... - Page 14 CPU die. When install heat sink, screws must be secured in ascending order (1 2 3 4). 4. Unlock the CPU from the CPU socket and lift up the CPU carefully. Fig. 18 Unlocking the CPU NEC Versa M340/E2000 Disassembly Manual Page 14...
-
Page 15: Removing The Lcd Module
Fig. 20 Removing the screws retaining the LCD Module 3. Release the screws on the system rear side as shown in Fig. 21 M2.5x8 Black Fig. 21 Removing the screws retaining the LCD Module NEC Versa M340/E2000 Disassembly Manual Page 15... - Page 16 4. Open up the LCD lid, release the two LCD cable connector on Main Board. Fig. 22 LCD Cable Connector 5. Carefully lift up the LCD Module. NEC Versa M340/E2000 Disassembly Manual Page 16...
-
Page 17: Removing The Lcd Panel
Fig. 23 Removing the rubber covers & screws on the LCD Module 3. Release the inverter board by remove the screw and disconnect all connectors as shown in Fig. 24 M2x3 Silver Fig. 24 Removing the Inverter Board NEC Versa M340/E2000 Disassembly Manual Page 17... - Page 18 5. Remove the screws at both sides of the LCD panel in order to release the LCD hinges as shown in Fig. 26 M2x3 Silver Fig. 26 Removing the LCD Panel hinges 6. Carefully separate LCD panel from LCD cable and LCD hinges and place it safe place. NEC Versa M340/E2000 Disassembly Manual Page 18...
-
Page 19: Removing The Top Cover
Module) then perform the following steps: 1. Remove all screws on the bottom of the base unit as shown in Fig. 27 A = M2x3 Silver B = M2.5x8 Black Fig. 27 Bottom Cover NEC Versa M340/E2000 Disassembly Manual Page 19... -
Page 20: Removing The Touch Pad
1. Unscrew the screws on the Top Cover as shown in Fig. 29 M2x3 Silver Fig. 29 Touch Pad 2. Carefully separate the Touch Pad module from Top cover. NEC Versa M340/E2000 Disassembly Manual Page 20... -
Page 21: Removing The Main Board
1. Remove the Hex screws from the VGA Port as shown in Fig. 30 M2.5x10 Silver Fig. 30 VGA Port 2. Unscrew those screws on HDD holder as shown in Fig. 31 and separate it carefully from Main Board. M2.5x7 Silver Fig. 31 HDD Holder NEC Versa M340/E2000 Disassembly Manual Page 21... - Page 22 Fig. 32 Connectors on Main Board 4. Unscrew the screws on Main Board encircled in Fig. 33 and disconnect Dip switch connector A = M2.5x11 Silver B = M2.5x5 Black Fig. 33 Screws on Main Board NEC Versa M340/E2000 Disassembly Manual Page 22...
-
Page 23: Removing The Speaker Assembly
Board) then perform the following steps: 1. Remove the screws holding Speaker Assembly as shown in Fig. 35 M2.5x5 Black Fig. 35 Speaker Assembly 2. Carefully remove the Speaker assembly from Bottom Cover and place it aside. NEC Versa M340/E2000 Disassembly Manual Page 23... -
Page 24: Dip Switch Settings
ON: USB 1.1 (Win98/Win2K) Bit 7 Reserve MB ID Bit 8 Reserve MB ID Bit 1 Bit 2 Keyboard code OFF JP Keyboard (Lavie) OFF US Keyboard UK Keyboard JP Keyboard (Versa Pro) NEC Versa M340/E2000 Disassembly Manual Page 24... -
Page 25: Screws
Screws M2.5x5 Black M2.5x11 Silver M2.5x7 Silver M2.5x5 Silver M2.5x10 Silver M2x3 Silver M2.5x8 Black M2.5x11 Black M3x5 Black NEC Versa M340/E2000 Disassembly Manual Page 25... -
Page 26: Notice
This guide contains information protected by copyright. No part of this guide may be photocopied or reproduced in any form or by any means without prior written consent from NEC Computers International BV. NEC COMPUTERS INTERNATIONAL BV SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN;...
