Summary of Contents for Beko BDI1420
- Page 1 Dishwasher User’s Manual BDI1420 15 8686 0100_AC_BEKO_E9AU_EN/ 11-11-22.(10:00)
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
Compliance with RoHS Directive ..6 rack ............24 Package information ......6 Collapsible upper basket wires ..25 Height setting with empty basket .. 25 2 MODEL BDI1420 Ceiling cutlery basket ......26 Ceiling cutlery basket ......26 3 DISHWASHER Overview ..........8 6 OPERATING THE PRODUCT 27 Technical specifications .......9... -
Page 4: Instructions For Safety And Environment
instructions for safety and environment This section contains safety Never touch the plug with • instructions that will help to get wet hands! Never unplug by protected from risk of personal pulling on the cable, always injury or property damage. Failure pull out by grabbing the plug. -
Page 5: Children's Safety
instructions for safety and environment Children’s safety This appliance is intended • to be used in household and Electrical products are • similar applications such as: dangerous for the children. - Staff kitchen areas in shops, Keep children away from the offices and other working product when it is in use. -
Page 6: Compliance With Weee Directive And Disposing Of The Waste Product
instructions for safety and environment Package information 1. Unplug the product before transporting it. Packaging materials of the 2. Remove water drainage and product are manufactured from water supply connections. recyclable materials in accordance with our National Environment 3. Drain the remaining water in Regulations. -
Page 7: Model Bdi1420
Mandatory Warnings Model BDI1420 The appliance is not intended for use by persons (including children) • with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instruction concerning use of the appliance by a responsible person for their safely. -
Page 8: Dishwasher Overview
Dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid (depends on model) 12. Upper basket rail 13. -
Page 9: Technical Specifications
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 10: Installation
Installation Appropriate installation Refer to the nearest Authorised Service Agent for installation of your product. To location make the product ready for use, make sure Place the product on a solid and flat • that the electricity, tap water supply and floor that has sufficient load carrying water drainage systems are appropriate capacity! The product must be installed... -
Page 11: Connection To The Drain
Installation Permitted water temperature: floor. A discharge hose longer than 4 meters up to 25°C ( 60°C for products causes dirty washing. equipped with Aquasafe+; please Attach the water discharge hose to the refer toAquasafe+ section ) drainpipe without bending it. Tightly fix the water discharge hose to the drainpipe in The dishwasher should be connected to cold order to prevent any dislocation of the water... -
Page 12: Aquasafe
Installation Aquasafe+ Power cable plug must be within easy • reach after installation. (depends on model) The Aquasafe+ system protects against Unplug the product after the water leaks that may occur at the hose inlet. washing programme is over. Water contact with the valve box of the system must be avoided to prevent damage The voltage and allowed fuse or •... -
Page 13: Preparation Tips For Energy Saving
Preparation Tips for energy saving Following information will help you use the product in an ecological and energy-efficient manner. Wipe away any coarse food remnants on the dishes before putting them in the product. Operate the product after filling it 2. -
Page 14: Tablet Detergents
Preparation Contact the detergent manufacturer if your dishes are wet and/or if you notice limescale spots particularly on your glasses after the washing programme is over when using a tablet detergent. Rinse aid The rinse aid used in dishwashers is a special combination that aims to increase drying efficiency and prevent water or lime stains... -
Page 15: Items Not Suitable For Washing In The Dishwasher
Preparation Decorative prints of chinaware as well as aluminium and silver items may get discoloured or tarnished after washing in the dishwasher just as it happens in handwashing as well. Some delicate glass types and crystals may become dull in time. We strongly recommend you to 4. - Page 16 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware /41 EN...
-
Page 17: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 18: Collapsible Lower Basket Tines
Preparation Collapsible lower basket Bringing the tines to the tines horizontal position by holding them from the tips may cause (depends on model) them to bend. Therefore, it will There are foldable tines (A) located at the be appropriate to bring the tines in the middle to horizontal or lower basket of the machine are designed vertical position by holding them... -
Page 19: Tray Wash Supports
Preparation SoftTouch Accessory (depends on model) The SoftTouch Accessory found in the lower basket of your machine enables a safe washing for your fragile glasses. Bringing the tines to the horizontal position by holding them from the tips may cause them to bend. -
Page 20: Lower Basket Multipurpose / Height
Preparation Lower basket multipurpose Make sure that the impeller does / height adjustable service not touch the dishes you placed rack on the racks. (depends on model) To close the racks: This accessory located at the lower basket Fold the rack (A). of your machine allows you to easily wash 2. -
Page 21: Lower Basket Bottle Wire
Preparation Lower basket bottle wire Upper basket multipurpose service rack (depends on model) The bottle wire is designed for easier (depends on model) washing of long pieces with wide mouths. This accessory located at the upper basket You may take out the bottle wire from the of your machine allows you to easily wash basket when not in use by pulling it out from pieces such as extra long ladles and bread... -
Page 22: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the To lower the basket, while it is in the uppermost position; upper basket Hold the upper basket wires with both (depends on model) hands, slightly lift up the basket and The upper basket height adjustment simultaneously push and release the mechanism has been designed for you to latches shown in the figure (B). -
Page 23: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the Repeat the same operation if the height is not adequate. upper basket (depends on model) Upper basket height adjustment mechanism is designed so that you can create wide spaces on the upper or lower compartment of the machine by adjusting the basket upwards or downwards either while it is empty or full. -
Page 24: Upper Basket Multi-Function Service Rack
Preparation Tray Washing Support Upper basket multi-function (depends on model) service rack You may use the tray washing supports (depends on model) if you want to wash a tray on your lower Thanks to the upper basket multi-function service basket. rack on the upper basket of your appliance, you may Refer to the Additional Functions section to load and wash long service-ware and kitchen-ware... -
Page 25: Collapsible Upper Basket Wires
Preparation Height setting with empty Collapsible upper basket basket wires (depends on model) (depends on model) In this model, the height setting of the upper You can use collapsible wires when you need basket may be changed using the wheels a larger space for your dishes in the upper which are mounted at two different heights. -
Page 26: Ceiling Cutlery Basket
Preparation Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 27: Operating The Product
Operating the product On / Off Key 7. Function Selection Keys Hygiene Intense function 2. Menu Key SteamGloss Function 3. Time Delay Selection / Menu Direction Selection Keys TrayWash Function 4. Selection / Confirmation Key Fast+ Function 5. Display 6. Start / Pause / Cancel Key 8. -
Page 28: Programme Selection / Programme Cancel Key
Operating the product On/Off Key Programme selection When you press the On/Off key, the indicator Press the On/Off button to turn on your lights illuminate on the display for ON machine. position. The lights turn off in OFF position. 2. Check the Salt and Rinse Aid indicators and add salt and/or rinse aid if needed. - Page 29 Operating the product 29 / 41 EN...
-
Page 30: Auxiliary Functions
Operating the product Functions in Settings Menu Auxiliary functions (depends on the model) Washing programmes of your dishwasher Under the settings menu of your product, are designed to obtain the best cleaning there are some additional functions that effect, considering the type of the soiling, depend on the model. -
Page 31: Scheduling The Washing Time
Operating the product IonGuard Function Off/On 3. Set the desired time by pressing the Time Delay key. Time will increase with increments of 30 minutes up to 6 hours and after that in 1 hour increments up to 24 hours every time you press the key. 4. -
Page 32: Adjusting The Amount Of Rinse Aid
Operating the product Your machine performs water Rinse Aid indicator ( ) softening depending on the Please check the rinse aid indicator on the hardness level of the supply display to see whether there is adequate water. Washing time can amount of rinse aid in the dishwasher or change while the programme not. -
Page 33: Water Cut-Off Warning
Operating the product End of Programme indicator will light up assured, E:01 icon will disappear. If E:01 does when the washing programme is over. not disappear, there is a permanent fault. In Open the door of the machine. this case the authorised service should be contacted. -
Page 34: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in order cleaned at regular intervals. for the machine operates efficiently. Check if Unplug the product and turn off food residues are left on the filters. -
Page 35: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 36: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Upper impeller Clean the impellers at least once a week in Check if the holes on the upper impeller (1) order for the machine operates efficiently. are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to Lower impeller remove the upper impeller. -
Page 37: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 38 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 39 Troubleshooting • Water hardness setting is low or salt level is insufficient >>> Measure the hardness of the supply water appropriately and check the water hardness setting. • Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole while adding salt.
- Page 40 Troubleshooting they should not be washed in dishwashers. • Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust on a corroded item can migrate to other stainless steel surfaces and cause corrosion on those surfaces as well. Such items should not be washed in dishwashers. Detergent remains in detergent dispenser.
- Page 41 Troubleshooting surfaces. A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid.
