Window Type Room Air Conditioner
CN
窗式空調器
IMPORTANT NOTE:
重 要 提 示 ：
This appliance is using R32 mildly flammable refrigerant.
此設備使用輕度易燃製冷劑R32。
Read this manual carefully before installing or operating your new air conditioning unit.
Make sure to save this manual for future reference.
Please check the applicable models, technical data from the nameplate pasted on the unit.
在安裝或操作新空調機組之前，請仔細閱讀本手冊。請妥善保管本手冊以備將來參考。
適用的型號、技術資料見機身銘牌。
MODEL:
ZWACR0723V ZWACR0923V ZWACR1223V
ZWACR1823V ZWACR2123V
User Manual
2
用戶使用手冊
19
Advertisement
Related Manuals for Zanussi ZWACR0723V
Summary of Contents for Zanussi ZWACR0723V
- Page 1 Window Type Room Air Conditioner User Manual 窗式空調器 用戶使用手冊 MODEL: ZWACR0723V ZWACR0923V ZWACR1223V ZWACR1823V ZWACR2123V IMPORTANT NOTE: 重 要 提 示 ： This appliance is using R32 mildly flammable refrigerant. 此設備使用輕度易燃製冷劑R32。 Read this manual carefully before installing or operating your new air conditioning unit.
- Page 2 Safety Precautions Read Safety Precautions Before Operation and Installation Incorrect installation due to ignore of instructions can cause serious damage or injury. WARNING Installation must be performed by an authorized dealer or professionally trained technician. Installation - Where refrigerant pipes shall be compliance with national gas regulations. - That mechanical connections shall be accessible for maintenance purposes.
- Page 3 Transportation, marking and storage for units Transport of equipment containing flammable refrigerants Compliance with the transport regulations Marking of equipment using signs Compliance with local regulations Disposal of equipment using flammable refrigerants Compliance with national regulations Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer’s instructions. Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
-
Page 4: Table Of Contents
Table of Contents Warning ....................Unit Parts Identification ................ Operation Instructions ............... Care and Maintenance ............... Water Drainage ..................Installation Instructions ..............Troubleshooting .................. Specifications ..................Disposal Requirement in Hong Kong Use authorized disposal sites for your old appliance. Help to keep your country tidy! This appliance is using R32 mildly flammable refrigerant. -
Page 5: Warning
Warning Read Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. CAUTION WARNING This symbol indicates the possibility of This symbol indicates the possibility property damage or serious consequences. - Page 6 ELECTRICAL WARNINGS Only use the specified power cord. If the power cord is damaged, it must be replaced by the manufacturer, its service • agent or similarly qualified persons in order to avoid a hazard. Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty plugs can cause fire •...
- Page 7 WARNING for Using R32 Refrigerant -Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. -The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance) and ignition sourcesor (for example:an operating electric heater) close to the appliance.
- Page 8 Explanation of symbols displayed on the unit(For the unit adopts R32 Refrigerant only): This symbol shows that this appliance This symbol shows that a service used a mildly flammable refrigerant. personnel should be handling If the refrigerant is leaked and exposed WARNING CAUTION this equipment with reference...
- Page 9 9)Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection proced- ures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
- Page 10 When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place. This operation is absolutely vital if brazing operations on the pipe-work are to take place. Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available. 13.Charging procedures In addition to conventional charging procedures, the following requirements shall be followed.
-
Page 11: Unit Parts Identification
Operating temperature When your air conditioner is used outside of the following temperature ranges, certain safety protection features may activate and cause the unit to disable. 18°C-43°C (64°F-109°F) Outdoor Temperature 18°C-52°C (64°F-126°F) (For special tropical models) Cooling operation Indoor Temperature 17°C-32°C (62°F-90°F) -5°C-24°C (23°F-76°F) Outdoor Temperature... -
Page 12: Operation Instructions
Vent Control The vent control is located above the control knobs. The operation method and the shape may vary in different models (see the following figures) For maximum cooling efficiency, CLOSE the vent. It will allow internal air circulation. OPEN the vent to discharge stale air. CLOSE VENT OPEN... - Page 13 SLEEP : Press and hold the "SWING" keypad for 2 seconds or use the remote control to activate the "SLEEP" feature . Press and hold the "SWING" keypad for 2 seconds or use the remote control again to deactivate the "SLEEP" feature. In the Cooling mode, the cooling temperature set point will increase 1℃ per hour after the "SLEEP"...
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE BEFORE CLEANING OR MAINTENANCE ALWAYS TURN OFF YOUR AIR CONDITIONER SYSTEM AND DISCONNECT ITS POWER SUPPLY BEFORE CLEANING OR MAINTENANCE. Cleaning Your Unit IMPORTANT The cabinet and front panel may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. -
Page 15: Installation Instructions
Non-drainage If you choose non-drainage when cooling, both the bottom and the back drain holes of the unit should be plugged with rubber plugs. The condensed water will be sprayed to condenser, and will improve the cooling performance. NOTE: When you choose non-drainage, the air conditioner will be perfect cooling efficiency, but big noise may be caused by spr- aying the condensed water. - Page 16 Model B: 1. Remove one screw securing the chassis fixing bracket, then take down the chassis fixing bracket. Remove two screws located on the back of the cabinet as shown in Fig.5B. 2. Grasp the handle on the chassis and carefully slide the air cond- itioner out of the cabinet.(see Fig.6) Model C: 1.
-
Page 17: Troubleshooting
NOTE: For the unit with power cord comes out from left side, please perform the following steps: 1. Pull the power cord to the left side straightly(See Fig.a & b). 2. Wrap the PVC protecing sheath on the power cord with cable ties in the hole position (see Fig.c). 3. -
Page 18: Specifications
Issue Possible Causes Air movement sound. This is normal. If too loud, turn selector to lower FAN setting. Sound of fan hitting water-moisture removal system. This is normal when humidity is high. Noise when unit is Close doors, windows and registers. cooling Window vibration - poor installation. - Page 19 安裝必須由授權經銷商及受過專業訓練的人員進行...
- Page 20 此符號表示本電器使用輕度易燃製冷劑。如果製冷劑洩漏並暴 警告 露於外部火源，則有著火的風險。 小心 此符號表示應仔細閱讀用戶使用手冊。 小心 此符號表示維修人員應參考安裝手冊處理此設備。 此符號表示用戶使用手冊或安裝手冊提供相關資訊。 小心...
- Page 21 產 品 廢 棄 物 處 理 注 意 事 項 請聯絡授權的棄置點處理您的舊空调器。為保持家園整潔貢獻力量！ 此設備使用輕度易燃製冷劑R32。 產品或其包裝材料中的 符號表示本產品不可作為家庭垃圾處理。 應將其運送至適當的回收點，確保妥善回收電氣電子設備。確保正確棄置本產品，幫助 避免因本產品廢棄物處理不當而導致對環境和人類健康造成潛在有害影響。 有關回收本產品的更多詳情，請聯絡您當地的市政機構、您的家庭垃圾處理服務機構或 您購買本產品的商店。...
- Page 22 此設備使用輕度易燃製冷劑R32。...
- Page 24 輕度易燃製冷劑R32。 輕度易燃製冷劑。...
- Page 25 此符號表示本電器使用輕度易燃製 冷劑。如果製冷劑洩漏並暴露於外 部火源，則有著火的風險。 用戶使用手冊 用戶使用手冊。...
- Page 28 18°C-43°C (64°F-109°F) 18°C ~ 52°C（64°F ~ 126°F） 17°C-32°C (62°F-90°F) -5°C-24°C (23°F-76°F) 0°C-27°C (32°F-80°F) 空氣過濾器。 空氣過濾器...
- Page 29 無線操作: (僅限部分型號) 首次使用WiFi功能時，長按SWING鍵3秒以啟動WiFi連接模式。當LED顯示屏顯示“AP”時，可設置WiFi連接。若在8分鐘內連接（路由器） 成功，設備將自動退出WiFi連接模式，且無線指示燈亮起。若在8分鐘內連接失敗，設備將自動退出WiFi連接模式。...
- Page 30 紫外線 紫外線 ECO功能：(僅限部分型號) 在COOL模式下，按遙控器的ECO鍵，進入節能模式。 空氣過濾器， 空氣過濾器， 空氣過濾器， 空氣過濾器。...
- Page 31 清潔空氣過濾器 空氣過濾器 空氣過濾器 過濾器 空氣過濾器。 空氣清新過濾器。 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器 空氣過 空氣過濾器 濾器 空氣過濾器 過濾器 空氣清新過濾器 空氣過濾器 排水...
- Page 32 空氣過濾器 空氣過濾器 空氣過濾器...
- Page 33 空氣過濾器 空氣過濾器...
- Page 34 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器 空氣過濾器...
- Page 35 445x320x415 5000~6000 450x346x535 450x346x535 0.75 7000~9000 450x346x585 450x350x675 450x346x585 450x350x675 9000~12000 560x400x640 600x380x560 660x428x680 15000~24000 660x428x780...
