UBP-X800 / UBP-UX80 / UBP-X1000ES
SERVICE MANUAL
Ver. 1.2 2017.04
9-930- 450-13
Blu-ray Disc
RDCM
Home Entertainment Business Group
RMT-VB310U / RMT-VB310E
US, Canadian Model
Australian Model
US, Canadian Model
US, Canadian Model
TM
/ DVD Player
SONY
Published by Manual design dept.
US Model
AEP Model
UK Model
UBP-X800
US Model
UBP-UX80
AEP Model
2
UBP-X1000ES
®
2017B6900-1
© 2017.04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UBP-X800 and is the answer not in the manual?

Questions and answers

Vernon umstead
March 21, 2025

Pairing the RMT-VB310U remote to the UBP-UX80 / How do I pair?
