Technical Specification - Redexim Rapidcore 1600 Operator And Parts Manual

1.0 TECHNICAL SPECIFICATIONS.
Model
Working width
Working depth
Tractor speed @540 rev's at PTO
Hole spacing 55 mm (2-1/8")
Hole spacing 110 mm (4-3/8")
PTO speed
Weight
Hole spacing side-to-side
Hole spacing in driving direction
Recommended minimum tractor size
Capacity (maximum)
Spacing 55 mm (2-1/8")
Spacing 110 mm (4-3/8")
Shipping dimensions
Maximum tine size
Three point linkage
Transmission oil
Lubrication grease
Standard items
1600
1.65 m (65")
Up to 125 mm (5")
Up to 1.8 km-h (1.2 mph)
Up to 3.6 km-h (2.4 mph)
Up to 540 rpm
640 Kg (1410 lbs)
55 mm ( 2-1/8")
25-110 mm (1-4 3/8")
25 Hp with lift capacity of minimum 770 kg
(1700 lbs)
Up to 2880 m²-h (26200 sq ft-hour)
Up to 5700 m²-h (52000 sq ft-hour)
1730 x 800 x 970 mm
(69" x 32" x 39")
Solid 12x150 mm (1/2"x5")
Hollow 19x150 mm (3/4"x5")
3-point CAT1-2
SAE 90 W
EP 2
Set hollow tines 16/125 (5/8"x6")
Front roller scraper
PTO
Manual
5
