- Page 1 OptiXstar W826E Quick Start Issue Date 2021-09-07 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
OptiXstar W826E Quick Start Contents Contents 1 Product Appearance........................ 1 2 Installing the Device....................... 3 3 Connecting Cables........................8 4 Description of Indicator......................9 5 Technical Specifications....................... 10 6 FAQs............................11 Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Product Appearance
Interfaces Description /Buttons Power Connecting the power adapter PoF (optical/electrical composite cable) power input 10/100/1000 Mbit/s for wired Ethernet connection Used for phone connections Reserved Optical Supports XGS-PON upstream access. port Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. - Page 5 ● The device supports PoF power supply and DC power supply. ● Use a power adapter that meets the safety requirements or has obtained the CCC certification. Otherwise, the device may be damaged. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
-
Page 6: Installing The Device
● Do not install the equipment in an environment with high temperature, dust, harmful gases, flammable, explosive, electromagnetic interference (large Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. - Page 7 Drill holes at the anchor points with a depth of 35 mm to 40 mm using a 6 mm electric drill bit, and install expansion coils to ensure that the expansion coils are flush with the wall. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
- Page 8 Determine the type of the T-shaped keel. The following figure shows the specifications of the T-shaped keel supported by the mounting kit. This installation method uses a 24 mm flat T-shaped keel as an example. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
- Page 9 Clip the keel mount a into the T-keel and slide b inward along the slot until the T-keel is clamped. Route the M3X8 screws through the holes marked "24" in the figure, and tighten the keel mounting kit b. Tighten the keel mounting stop screw M3x6.2. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
- Page 10 Ensure that the device is properly installed on the mounting bracket to prevent it from falling off. Ensure that the installation space meets the preceding requirements for future maintenance. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
-
Page 11: Connecting Cables
If the DC power supply is used, use the delivered power adapter adapter. Otherwise, the device may be damaged. Optical Optical/electrical composite cables are used to connect port optical fibers and support XGS-PON upstream transmission. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. -
Page 12: Description Of Indicator
The red The PON upstream network is not connected or the indicator is system is starting. steady on. The red Equipment failure. indicator blinks slowly (once/1s) extinguished The device is not running. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. -
Page 13: Technical Specifications
Project Specifications Dimensions (W x D 230 mm × 230 mm × 35 mm x H) Operating Ambient -10°C - 50°C Temperature Operating ambient 5% RH to 95% RH, non-condensing humidity Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd. -
Page 14: Faqs
10 seconds. After all indicators are off, release the button to restore factory settings. After the device is restored to factory settings, the device configuration parameters are cleared and you need to set the Internet connection again. Issue 01 (2021-09-07) Copyright © Huawei Technologies Co., Ltd.
