20
To charge the communicator battery with the desktop stand
1 Plug the Performance Travel Charger into the stand.
2 Place the communicator in the desktop stand connector end first.
3 Plug the charger into a mains outlet.
To charge a spare battery with the desktop stand
1 Plug the Performance Travel Charger into the stand.
2 Insert the battery in the second slot the golden contacts first. Push the
battery slightly backwards, see figure 11. Ensure that the battery clicks
into place.
3 Plug the charger into a mains outlet. Check that the light on the left of the
stand is on. The red light indicates charging, and the steady green light
indicates that the battery is charged.
Note: If the communicator is also
charging in the desk stand, the charging
of the spare battery will cease until the
battery in the communicator is charged.
4 To remove the battery, reverse the procedure shown in figure 11.
To connect to a PC
With the communicator in the desktop stand, you can connect to a PC with
the RS-232 adapter cable DLR-2.
1 Plug the adapter cable into the connector at the back of the stand.
2 Connect the other end of the cable to the PC.
Figure 11
